T1410242000-000

4 THIS DRAWING IS UNPUBLISHED. C COPYRIGHT 20 2 3 1 20 RELEASED FOR PUBLICATION REVISIONS ALL RIGHTS RESERVED. BY - P A FOR FG "T1410242000-100" SEAL FIXED BY GLUE D DESCRIPTION LTR DATE INITIAL RELEASE DWN APVD DL 12JUN2015 CW D 108 4.4 SCALE 104 35 32 27 4- 1:2 4-M3 130 C C 29.8 ( 48.2 ) PANNEL CUT OUT NOTES: 1. TECHNICAL CHARACTERISTICS: BODY MATERIAL: DIE CAST ALUMINIUM ALLOY SURFACE TREATMENT: POWDER-COATED, GRAY OPERATION TEMPERATURE: -40-+125 $ C DEGREE OF PROTECTION: IP65 (MATED) 45.7 142.2 : 1. : : : , : -40-+125 $ C : IP65( ) B 4.4 (4PL) T1410242000-000 32 T1410242000-100 ASSEMBLY PART NUMBER THIS DRAWING IS A CONTROLLED DOCUMENT. TOLERANCES UNLESS OTHERWISE SPECIFIED: DIMENSIONS: mm 130 A MATERIAL 1470-19 (3/13) 0 1 2 3 4 PLC PLC PLC PLC PLC ANGLES - FINISH - - DWN 12JUN2015 CHK 12JUN2015 APVD 12JUN2015 DAVID LI CHRIS WANG XU XIANG PRODUCT SPEC B - H24B-AG SEAL FIXED BY GLUE ASSEMBLY PART DESCRIPTION REMARK TE Connectivity NAME H24B-AG A 108-137013 APPLICATION SPEC - 114-137013 WEIGHT CUSTOMER DRAWING SIZE A3 CAGE CODE - DRAWING NO RESTRICTED TO T1410242000X00 SCALE 3:4 SHEET - 1 OF 1 REV A
