T2040103101-000

4 THIS DRAWING IS UNPUBLISHED. C COPYRIGHT 1 20 RELEASED FOR PUBLICATION REVISIONS ALL RIGHTS RESERVED. BY - 20 2 3 P A 64 D DESCRIPTION LTR B B1 33.8 C 34.1 : 1. : : : : : : : : : : 1.2 ( 21.1 ) 19.1 4X M3 SCREW RECOMMENDED TIGHTENING TORQUE 0.5Nm 4 X M3 , 0.5Nm 5 48 : 36 14 27 27 B 57 4X T2040103101-001 HE-010-MS T2040103101-000 HE-010-MS .3 THIS DRAWING IS A CONTROLLED DOCUMENT. PANEL CUT OUT FOR INSERTS FOR USE WITHOUT HOODS/HOUSING TOLERANCES UNLESS OTHERWISE SPECIFIED: DIMENSIONS: mm A MATERIAL 0 1 2 3 4 PLC PLC PLC PLC PLC ANGLES - 08APR2015 GY CW ECR-15-013759 29SEP2015 DW CW ECR-16-009892 13JUL2016 RL CW ECR-21-106515 09JUL2021 SQ CW FINISH - - DWN 08APR2015 CHK 08APR2015 APVD 08APR2015 Chris.Wang Xiang.Xu C B PART DESCRIPTION Gino.Yao STAINLESS STEEL STAINLESS STEEL STEEL STEEL FIXING SCREW MAT'L GROUND CONTACT SCREW MAT'L TE Connectivity NAME PRODUCT SPEC HE-010-MS A 108-137044 APPLICATION SPEC - 114-137044 WEIGHT - D PC 500V 16A >=400M ^ 6KV 3 UL94V-0 500 0.5mm²~2.5mm² (AWG20-AWG14) : HE-010 MALE INSERT, SPRING CLAMP HE-010 , Customer Drawing 1470-19 (3/13) APVD INITIAL RELEASE HE-010 MALE INSERT, WIIH STAINLESS STEEL SCREW, SPRING CLAMP HE-010 , , PART NUMBER n3 57 DWN NOTES: 1. TECHNICAL CHARACTERISTICS: INSULATION MATERIAL: PC RATED VOLTAGE: 500V RATED CURRENT: 16A INSULATION RESISTANCE: >=400M ^ RATED IMPULSE VOLTAGE: 6KV POLLUTION DEGREE: 3 FLAMMABILITY: UL94V-0 MATING CYCLES: 500 CYCLES WIRE RANGE: 0.5mm²~2.5mm² (AWG20-AWG14) CONTACT FINISH: SILVER PLATED CONTACT TYPE: SPRING CLAMP M4 SCREW, RECOMMENDED TIGHTENING TORQUE 1.2Nm M4 , 1.2Nm C DATE SIZE CAGE CODE A3 00779 DRAWING NO RESTRICTED TO - T2040103101000 SCALE 1:1 SHEET 1 OF 1 REV C Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: TE Connectivity: T2040103101-000
