T2040164101-000

4 THIS DRAWING IS UNPUBLISHED. C COPYRIGHT 20 1 20 RELEASED FOR PUBLICATION REVISIONS ALL RIGHTS RESERVED. BY - P 5 84.5 D 2 3 A 68.5 B B1 ( 21.1 ) 19.1 PANEL CUT FOR INSERTS FOR USING WITHOUT HOODS/ HOUSINGS 1.2 34.1 .3 n3 C DWN APVD INITIAL RELEASE 15APR2015 GY CW ECR-15-013759 12OCT2015 DW CW ECR-16-015492 16NOV2016 QY CW ECR-21-106515 19JUL2021 SQ CW NOTES: 1. TECHNICAL CHARACTERISTICS: INSULATION MATERIAL: PC RATED VOLTAGE: 500V RATED CURRENT: 16A INSULATION RESISTANCE: >=400M ^ RATED IMPULSE VOLTAGE: 6KV POLLUTION DEGREE: 3 FLAMMABILITY: UL94V-0 MATING CYCLES: 500 CYCLES WIRE RANGE: 0.14mm²~4mm² (AWG26-AWG12 ) CONTACT TYPE: CRIMP CONTACT 2. CONTACTS NEED TO BE ORDERED SEPARATELY. (ORDER No. REFER TO DRAWING:T20300X10XX000) 4X 4X M3 SCREW,RECOMMENDED TIGHTENING TORQUE 0.5Nm 4X M3 , 0.5Nm DATE D 36 14 33.8 27 C 77.5 DESCRIPTION LTR : 1. : : : : : : : : : : : M4 SCREW,RECOMMENDED TIGHTENING TORQUE 1.2Nm M4 , 1.2Nm 2. 27 B C PC 500V 16A >=400M ^ 6KV 3 UL94V-0 500 0.14mm²~4mm² (AWG26-AWG12) ( . : T20300X10XX000) B 77.5 THIS DRAWING IS A CONTROLLED DOCUMENT. TYPE-1,T2040164101-000,TE LOGO -1,T2040164101-000,TE LOGO mm A MATERIAL 1470-19 (3/13) TOLERANCES UNLESS OTHERWISE SPECIFIED: DIMENSIONS: 0 1 2 3 4 PLC PLC PLC PLC PLC ANGLES - FINISH - - DWN 15APR2015 CHK 15APR2015 APVD 15APR2015 Gino.Yao Chris.Wang Xiang.Xu PRODUCT SPEC TE Connectivity NAME HE-016-MC A 108-137044 APPLICATION SPEC - 114-137044 WEIGHT Customer Drawing SIZE CAGE CODE A3 00779 DRAWING NO RESTRICTED TO - T2040164101000 SCALE 1:1 SHEET 1 OF 2 REV C 4 THIS DRAWING IS UNPUBLISHED. C COPYRIGHT 20 RELEASED FOR PUBLICATION BY - 2 3 1 20 REVISIONS ALL RIGHTS RESERVED. P DESCRIPTION LTR - DATE SEE SHEET 1 DWN APVD - - - D D NOTE: SEE SHEET 1 : 1 C C TYPE-2,T2040164101-001,STAINLESS STEEL SCREW,NO LOGO -2,T2040164101-001, , LOGO B B T2040164101-001 HE-016-MC T2040164101-000 HE-016-MC PART NUMBER THIS DRAWING IS A CONTROLLED DOCUMENT. ALL SPEC DIMENSION REFER TO TYPE 1 TYPE 1 A mm MATERIAL 1470-19 (3/13) TOLERANCES UNLESS OTHERWISE SPECIFIED: DIMENSIONS: 0 1 2 3 4 PLC PLC PLC PLC PLC ANGLES - FINISH - - HE-016 MALE INSERT,CRIMPING, STAINLESS STEEL SCREW,NO LOGO HE-016 , , , LOGO TYPE-2 -2 HE-016 MALE INSERT,CRIMPING HE-016 , TYPE-1 -1 PART DESCRIPTION DWN 15APR2015 CHK 15APR2015 APVD 15APR2015 Gino.Yao Chris.Wang Xiang.Xu PRODUCT SPEC TYPE TE Connectivity NAME HE-016-MC A 108-137044 APPLICATION SPEC - 114-137044 WEIGHT Customer Drawing SIZE CAGE CODE A3 00779 DRAWING NO RESTRICTED TO - T2040164101000 SCALE 1:1 SHEET 2 OF 2 REV C
