4 THIS DRAWING IS UNPUBLISHED. C COPYRIGHT 20 2 3 RELEASED FOR PUBLICATION 1 20 REVISIONS ALL RIGHTS RESERVED. BY - P A B D DESCRIPTION LTR DATE DWN APVD INITIAL RELEASE 16APR2015 DL CW ECR-21-111798 06OCT2021 WQR CW NOTES: 1. TECHNICAL CHARACTERISTICS: INSULATION MATERIAL: PC RATED VOLTAGE: 50V RATED CURRENT: 1A INSULATION RESISTANCE: >=400M ^ RATED IMPULSE VOLTAGE: 0.8KV POLLUTION DEGREE: 3 FLAMMABILITY: UL94V-0 MATING CYCLES: 1500 OPERATION TEMPERATURE: -40 $ C~+70 $ C C : 52 1. : : : : : : : : : : D C PC 50V 1A >=400M ^ 0.8KV 3 UL94V-0 1500 -40 $ C~+70 $ C B B 30.2 HMN-USB-M THIS DRAWING IS A CONTROLLED DOCUMENT. 14.6 A mm MATERIAL 1470-19 (3/13) TOLERANCES UNLESS OTHERWISE SPECIFIED: DIMENSIONS: 0 1 2 3 4 PLC PLC PLC PLC PLC ANGLES - FINISH - - DWN 16APR2015 CHK 16APR2015 APVD 16APR2015 DAVID LI CHRIS WANG XU XIANG PRODUCT SPEC 108-137066 T2114000101-000 DESCRIPTION PART NUMBER TE Connectivity NAME HMN-USB-M A APPLICATION SPEC - 114-137066 WEIGHT CUSTOMER DRAWING SIZE A3 CAGE CODE - DRAWING NO RESTRICTED TO T2114000101000 SCALE 2:1 SHEET 1 OF 1 REV B
