W4P

4 THIS DRAWING IS UNPUBLISHED. C COPYRIGHT 2014 TE CONNECTIVITY 2 3 2014 RELEASED FOR PUBLICATION LOC - ALL RIGHTS RESERVED. 1 REVISIONS DIST - P NC A D DESCRIPTION LTR B DATE DWN APVD NEW RELEASE PER EO A09299 2/9/90 CW JA REVISED PER EO P15887 2/15/99 ST RDR REVISED PER ECO-14-003390 3/26/14 RLM DM D .580 [14.73 ] CAVITY ID APPROX. AS SHOWN .371 [9.42 ] .323 [8.20 ] C C CUTOUT FEATURE OPTIONAL .292 [7.42 ] B .244 [6.20 ] THIS DRAWING IS A CONTROLLED DOCUMENT. TOLERANCES UNLESS OTHERWISE SPECIFIED: DIMENSIONS: INCHES[mm] A 1. USED WITH DT04-4P-**** (**** = ALL MODIFICATIONS). CONSULT FACTORY FOR MODIFICATION AND APPLICATION. 1470-19 (3/11) MATERIAL 0 1 2 3 4 PLC PLC PLC PLC PLC ANGLES PLASTIC GREEN FINISH 0.010[0.25] 0°30'0" - 08JAN2014 R.MESSENGER CHK 09JAN2014 R.MESSENGER APVD 20FEB2014 D. MEYER B DWN TE Connectivity NAME PRODUCT SPEC - APPLICATION SPEC - WEIGHT SIZE 0.48 g CUSTOMER DRAWING WEDGE LOCK 4 WAY RECEPTACLE DT SERIES CAGE CODE A3 4AFU8 A DRAWING NO W4P SCALE 6:1 RESTRICTED TO SHEET - 1 OF 1 REV B
