HA-5002883_06

® HA-5002/883 Data Sheet January 5, 2006 FN3705.4 Monolithic, Wideband, High Slew Rate, High Output Current Buffer The HA-5002/883 is a monolithic, wideband, high slew rate, high output current, buffer amplifier. Utilizing the advantages of the Intersil Dielectric Isolation technologies, the HA-5002/883 current buffer offers 1300V/µs slew rate typically and 1000V/µs minimum with 110MHz of bandwidth. The ±100mA minimum output current capability is enhanced by a 3Ω output impedance. The monolithic HA-5002/883 will replace the hybrid LH0002 with corresponding performance increases. These characteristics range from the 3MΩ (typ) input impedance to the increased output voltage swing. Monolithic design technologies have allowed a more precise buffer to be developed with more than an order of magnitude smaller gain error. The voltage gain is 0.98 guaranteed minimum with a 1kΩ load and 0.96 minimum with a 100Ω load. The HA-5002/883 will provide many present hybrid users with a higher degree of reliability and at the same time increase overall circuit performance. Features • This Circuit is Processed in Accordance to MIL-STD-883 and is Fully Conformant Under the Provisions of Paragraph 1.2.1. • Voltage Gain (RL = 1kΩ) . . . . . . . . . . . . . . . . . . 0.98 (Min) 0.995 (Typ) (RL = 100Ω) . . . . . . . . . . . . . . . . . 0.96 (Min) 0.971 (Typ) • High Input Impedance . . . . . . . . . . . . . . . . . . 1.5MΩ (Min) 3MΩ (Typ) • Low Output Impedance . . . . . . . . . . . . . . . . . . . 5Ω (Max) 3Ω (Typ) • Very High Slew Rate . . . . . . . . . . . . . . . . .1000V/µs (Min) 1300V/µs (Typ) • Wide Small Signal Bandwidth . . . . . . . . . . . 110MHz (Typ) • High Output Current . . . . . . . . . . . . . . . . . . . .100mA (Min) • High Pulsed Output Current . . . . . . . . . . . . . 400mA (Max) • Monolithic Dielectric Isolation Construction • Replaces Hybrid LH0002 Ordering Information PART NUMBER PART MARKING TEMP RANGE (°C) PACKAGE Applications • Line Driver • Data Acquisition • 110MHz Buffer • High Power Current Booster • High Power Current Source • Sample and Holds • Radar Cable Driver • Video Products HA2-5002/883 HA2-5002/883 -55 to +125 8 Pin Can HA4-5002/883 HA4-5002/883 -55 to +125 20 Ld Ceramic LCC Pinouts HA-5002/883 (CLCC) TOP VIEW OUT V1 + NC NC NC HA-5002/883 (METAL CAN) TOP VIEW IN 3 NC V2 NC NC NC 4 5 6 7 8 2 1 20 19 18 NC 17 V2 + 16 NC 15 NC 14 NC V1+ 1 V2 + 2 8 7 V1V2 - 6 9 10 11 12 13 IN V1 NC NC NC NC 3 4 OUT 5 NC 1 CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures. 1-888-INTERSIL or 1-888-468-3774 | Intersil (and design) is a registered trademark of Intersil Americas Inc. Copyright Intersil Americas Inc. 2002, 2004-2006. All Rights Reserved All other trademarks mentioned are the property of their respective owners. HA-5002/883 Absolute Maximum Ratings Voltage Between V+ and V- Terminals. . . . . . . . . . . . . . . . . . . . .44V Input Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Equal to Supplies Peak Output Current (50ms On, 1s Off) . . . . . . . . . . . . . . . . . .±400mA Junction Temperature (TJ) . . . . . . . . . . . . . . . . . . . . . . . . . . . +175°C Storage Temperature Range . . . . . . . . . . . . . . . . . .-65°C to +150°C ESD Rating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
