® HA-5127/883 Data Sheet January 16, 2006 FN3751.3 Ultra Low Noise, Precision Operational Amplifier The HA-5127/883 monolithic operational amplifier features an excellent combination of precision DC and wideband high speed characteristics. Utilizing the Intersil D.I. technology and advanced processing techniques, this unique design unites low noise precision instrumentation performance with high speed, wideband capability. This amplifier’s impressive list of features include low VOS, wide gain-bandwidth, high open loop gain, and high CMRR. Additionally, this flexible device operates over a wide supply range while consuming only 120mW of power. Using the HA-5127/883 allows designers to minimize errors while maximizing speed and bandwidth. This device is ideally suited for low level transducer signal amplifier circuits. Other applications which can utilize the HA-5127/883’s qualities include instrumentation amplifiers, pulse or RF amplifiers, audio preamplifiers, and signal conditioning circuits. Features • This Circuit is Processed in Accordance to MIL-STD-883 and is Fully Conformant Under the Provisions of Paragraph 1.2.1. • High Slew Rate . . . . . . . . . . . . . . . . . . . . . . . .7V/µs (Min) • Unity Gain Bandwidth. . . . . . . . . . . . . . . . . . . .5MHz (Min) • Low Noise Voltage (at 1kHz) . . . . . . . . . 4.5nV/√Hz (Max) • Low Offset Voltage . . . . . . . . . . . . . . . . . . . . .100µV (Max) • Low Offset Drift With Temperature . . . . . . 1.8µV/oC (Max) • High CMRR . . . . . . . . . . . . . . . . . . . . . . . . . . 100dB (Min) • High Voltage Gain . . . . . . . . . . . . . . . . . . . 700kV/V (Min) Applications • High Speed Signal Conditioners • Wide Bandwidth Instrumentation Amplifiers • Low Level Transducer Amplifiers • Fast, Low Level Voltage Comparators • Highest Quality Audio Preamplifiers Ordering Information PART NUMBER HA2-5127/883 PART MARKING TEMP RANGE (°C) PKG. PACKAGE DWG. # T8.C • Pulse/RF Amplifiers HA2-5127/883 -55 to +125 8 Pin Can Pinout HA-5127/883 (METAL CAN) TOP VIEW BAL 8 BAL 1 + 3 4 V5 7 V+ -IN 2 6 OUT +IN NC 1 CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures. 1-888-INTERSIL or 1-888-468-3774 | Intersil (and design) is a registered trademark of Intersil Americas Inc. Copyright Intersil Americas Inc. 2001, 2004, 2005, 2006. All Rights Reserved All other trademarks mentioned are the property of their respective owners. HA-5127/883 Absolute Maximum Ratings Voltage Between V+ and V- Terminals . . . . . . . . . . . . . . . . . . . .44V Differential Input Voltage (Note 2) . . . . . . . . . . . . . . . . . . . . . . . 0.7V Voltage at Either Input Terminal . . . . . . . . . . . . . . . . . . . . . V+ to VInput Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25mA Differential Output Current . . . . . . . . . . . Full Short Circuit Protection Junction Temperature (TJ) . . . . . . . . . . . . . . . . . . . . . . . . . . .+175oC Storage Temperature Range . . . . . . . . . . . . . . . . . -65oC to +150oC ESD Rating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
