HI-201

HI-200, HI-201 Data Sheet October 1999 File Number 3121.4 Dual/Quad SPST, CMOS Analog Switches HI-200/HI-201 (dual/quad) are monolithic devices comprising independently selectable SPST switches which feature fast switching speeds (HI-200 240ns, and HI-201 185ns) combined with low power dissipation (15mW at 25oC). Each switch provides low “ON” resistance operation for input signal voltage up to the supply rails and for signal current up to 80mA. Rugged DI construction eliminates latch-up and substrate SCR failure modes. All devices provide break-before-make switching and are TTL and CMOS compatible for maximum application versatility. HI-200/HI-201 are ideal components for use in high frequency analog switching. Typical applications include signal path switching, sample and hold circuit, digital filters, and operational amplifier gain switching networks. Features • Analog Voltage Range . . . . . . . . . . . . . . . . . . . . . . . ±15V • Analog Current Range . . . . . . . . . . . . . . . . . . . . . . . 80mA • Turn-On Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 240ns • Low rON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55Ω • Low Power Dissipation . . . . . . . . . . . . . . . . . . . . . . .15mW • TTL/CMOS Compatible Applications • High Frequency Analog Switching • Sample and Hold Circuits • Digital Filters • Operational Amplifier Gain Switching Networks Ordering Information PART NUMBER HI1-0200-5 HI2-0200-5 HI3-0200-5 HI1-0201-2 HI1-0201-4 HI1-0201-5 HI3-0201-5 HI4P0201-5 HI9P0201-5 HI9P0201-9 TEMPERATURE RANGE (oC) 0 to 75 0 to 75 0 to 75 -55 to 125 -25 to 85 0 to 75 0 to 75 0 to 75 0 to 75 -40 to 85 PACKAGE 14 Ld CERDIP 10 Pin Metal Can 14 Ld PDIP 16 Ld CERDIP 16 Ld CERDIP 16 Ld CERDIP 16 Ld PDIP 20 Ld PLCC 16 Ld SOIC 16 Ld SOIC PKG. NO. Functional Diagram V+ F14.3 T10.B E14.3 F16.3 F16.3 F16.3 E16.3 N20.35 M16.15 M16.15 1 LOGIC 0 LOGIC INPUT VREF INPUT SOURCE GATE REFERENCE, LEVEL SHIFTER, AND DRIVER SWITCH CELL GATE DRAIN OUTPUT V- TRUTH TABLE HI-200 ON OFF HI-201 ON OFF 1 CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures. 1-888-INTERSIL or 407-727-9207 | Copyright © Intersil Corporation 1999 HI-200, HI-201 Pinouts (Switches Shown For Logic “1” Input) HI-201 (CERDIP, PDIP, SOIC) TOP VIEW OUT1 A1 OUT1 IN1 VGND IN4 OUT4 V- 7 8 VREF A4 1 2 3 4 5 6 7 8 16 A2 15 OUT2 14 IN2 13 V+ 12 VREF 11 IN3 10 OUT3 9 A3 IN1 VNC GND IN4 4 5 6 7 8 9 OUT4 10 A4 11 NC 12 A3 13 OUT3 HI-200 (CERDIP, PDIP) TOP VIEW A2 1 NC 2 GND 3 NC 4 IN2 5 OUT2 6 14 A1 13 NC 12 V+ 11 NC 10 IN1 9 OUT1 HI-201 (PLCC) TOP VIEW OUT2 19 18 IN2 17 V+ 16 NC 15 VREF 14 IN3 NC 1 A1 3 2 20 HI-200 (METAL CAN) TOP VIEW V+ 10 A1 A2 2 1 9 IN1 8 7 4 5 OUT2 6 VOUT1 VREF GND 3 IN2 Schematic Diagrams TTL/CMOS REFERENCE CIRCUIT VREF CELL HI-200 V+ R6 R2 5K QP1 QP4 QN1 D3 R3 24.2K QN2 R4 5.4K R5 7.9K MN15 VGND GND MN16 MN17 R7 100K MN14 D3 300 QP2 QP3 QN4 MP13 QP5 TO P2 VREF MP13 QN1 R3 24.2K QN2 R4 5.4K R5 7.9K MN15 VMN16 MN17 MN14 MP14 QN3 QP6 R7 100K VLL QP4 R2 5K QP1 QP2 QP3 QN4 QP5 TO P2 VREF V+ R6 600 TTL/CMOS REFERENCE CIRCUIT VREF CELL HI-201 VLL GND GND 2 A2 HI-200, HI-201 Schematic Diagrams (Continued) SWITCH CELL A’ QN11 V+ QN12 INPUT QP11 QN13 OUTPUT V- QP12 A’ DIGITAL INPUT BUFFER AND LEVEL SHIFTER V+ QP3 QP1 QP5 QP4 A’ V+ QN1 QP7 D1 TO VLL TO VREF 200Ω D2 QP2 A V- QP6 QP8 QP9 QP10 QN8 QN6 QN7 QN9 QN10 A’ QN2 QN4 QN5 QN3 V- 3 HI-200, HI-201 Absolute Maximum Ratings Supply Voltage (V+ to V-). . . . . . . . . . . . . . . . . . . . . . . . . 44V (±22) VREF to Ground . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20V, -5V Digital Input Voltage . . . . . . . . . . . . . . . . . . . . . . (V+) +4V to (V-) -4V Analog Input Voltage (One Switch) . . . . . . . . . . (V+) +2V to (V-) -2V Thermal Information Thermal Resistance (Typical, Note 1) θJA (oC/W) θJC (oC/W) 14 Ld CERDIP Package . . . . . . . . . . . . 80 24 16 Ld CERDIP Package . . . . . . . . . . . . 75 20 PLCC Package. . . . . . . . . . . . . . . . . . . 80 N/A PDIP Package . . . . . . . . . . . . . . . . . . . 95 N/A 16 Ld SOIC Package . . . . . . . . . . . . . . 110 N/A 10 Pin Metal Can Package . . . . . . . . . . 160 75 Maximum Storage Temperature. . . . . . . . . . . . . . . . -65oC to 150oC Maximum Junction Temperature (Hermetic Packages) . . . . . 175oC Maximum Junction Temperature (Plastic Packages) . . . . . . . 150oC Maximum Lead Temperature (Soldering, 10s). . . . . . . . . . . . 300oC (PLCC and SOIC - Lead Tips Only) Operating Conditions Temperature Ranges HI-201-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -55oC to 125oC HI-201-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -25oC to 85oC HI-200-5, HI-201-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0oC to 75oC HI-201-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -40oC to 85oC CAUTION: Stresses above those listed in “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress only rating and operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not implied. NOTE: 1. θJA is measured with the component mounted on an evaluation PC board in free air. Electrical Specifications PARAMETER DYNAMIC CHARACTERISTICS Switch ON Time, tON HI-200 HI-201 Supplies = +15V, -15V; VREF = Open; VAH (Logic Level High) = 2.4V, VAL (Logic Level Low) = 0.8V TEST CONDITIONS TEMP (oC) -2 MIN TYP MAX MIN -4, -5, -9 TYP MAX UNITS 25 25 Full - 240 185 1000 500 500 - - 240 185 1000 - ns ns ns Switch OFF Time, tOFF HI-200 HI-201 25 25 Full Off Isolation HI-200 HI-201 Input Switch Capacitance, CS(OFF) Output Switch Capacitance, CD(OFF) Output Switch Capacitance, CD(ON) Digital Input Capacitance, CA Drain-to-Source Capacitance, CDS(OFF) DIGITAL INPUT CHARACTERISTICS Input Low Threshold, VAL Input High Threshold, VAH Input Leakage Current (High or Low), IA ANALOG SWITCH CHARACTERISTICS Analog Signal Range, VS ON Resistance, rON (Note 2) Full 25 Full -15 55 80 +15 70 100 -15 55 72 +15 80 100 V Ω Ω (Note 3) Full Full Full 2.4 0.8 1.0 2.4 0.8 1.0 V V µA (Note 4) 25 25 25 25 25 25 25 70 80 5.5 5.5 11 5 0.5 70 80 5.5 5.5 11 5 0.5 dB dB pF pF pF pF pF 330 220 1000 500 500 500 220 1000 ns ns ns 4 HI-200, HI-201 Electrical Specifications PARAMETER OFF Input Leakage Current, IS(OFF) HI-200 HI-201 Supplies = +15V, -15V; VREF = Open; VAH (Logic Level High) = 2.4V, VAL (Logic Level Low) = 0.8V (Continued) TEST CONDITIONS (Note 6) TEMP (oC) 25 Full 25 Full OFF Output Leakage Current, ID(OFF) HI-200 HI-201 (Note 6) 25 Full 25 Full ON Leakage Current, ID(ON) HI-200 HI-201 (Note 6) 25 Full 25 Full POWER SUPPLY CHARACTERISTICS (Note 5) Power Dissipation, PD 25 Full Current, I+ 25 Full Current, I25 Full NOTES: 2. VOUT = ±10V, IOUT = 1mA. 3. Digital Inputs are MOS gates: typical leakage is < 1nA. 4. VA = 5V, RL = 1kΩ , CL = 10pF, VS = 3VRMS , f = 100kHz. 5. VA = +3V or VA = 0V for Both Switches. 6. Refer to Leakage Current Measurements (Figure 2). 15 0.5 0.5 60 2.0 2.0 15 0.5 0.5 60 2.0 2.0 mW mW mA mA mA mA -2 MIN TYP 1 100 2 1 100 2 35 1 100 2 MAX 5 500 5 500 5 500 5 500 5 500 5 500 MIN -4, -5, -9 TYP 1 10 2 1 10 2 35 1 10 2 MAX 50 500 50 250 50 500 50 250 50 500 50 250 UNITS nA nA nA nA nA nA nA nA nA nA nA nA Test Circuits and Waveforms TA = 25oC, VSUPPLY = ±15V, VAH = 2.4V, VAL = 0.8V and VREF = Open 1mA 2 r ON = -----------1mA IN ±VIN V V2 OUT FIGURE 1A. ON RESISTANCE TEST CIRCUIT 5 HI-200, HI-201 Test Circuits and Waveforms 80 70 ON RESISTANCE (Ω) VIN = 0V ON RESISTANCE (Ω) 60 50 40 30 20 10 0 -50 -25 0 25 50 75 100 125 TEMPERATURE (oC) 0 -15 TA = 25oC, VSUPPLY = ±15V, VAH = 2.4V, VAL = 0.8V and VREF = Open (Continued) 100 V+ = +10V V- = -10V V+ = +12.5V V- = -12.5V 50 V+ = +15V V- = -15V -10 -5 0 5 ANALOG SIGNAL LEVEL (V) 10 15 FIGURE 1B. ON RESISTANCE vs TEMPERATURE FIGURE 1C. HI-200 ON RESISTANCE vs ANALOG SIGNAL LEVEL FIGURE 1. ON RESISTANCE IS(OFF) 100 + 14V IS(OFF) / ID(OFF) CURRENT (nA) 10 A IN OUT ID(OFF) A ±14V FIGURE 2B. OFF LEAKAGE CURRENT TEST CIRCUIT ID(ON) 1.0 IN OUT 0.1 25 50 75 100 125 TEMPERATURE (oC) A ID(ON) ± 14V FIGURE 2A. LEAKAGE CURRENT vs TEMPERATURE FIGURE 2C. ON LEAKAGE CURRENT TEST CIRCUIT FIGURE 2. LEAKAGE CURRENTS 90 80 SWITCH CURRENT (mA) 70 60 50 40 30 20 10 0 0 1 2 3 4 5 6 7 VOLTAGE ACROSS SWITCH (±V) ±VIN IN OUT HI-201 I FIGURE 3A. SWITCH CURRENT vs VOLTAGE FIGURE 3. SWITCH CURRENT FIGURE 3B. TEST CIRCUIT 6 HI-200, HI-201 Test Circuits and Waveforms DIGITAL INPUT VAH = 4V 50% 50% TA = 25oC, VSUPPLY = ±15V, VAH = 2.4V, VAL = 0.8V and VREF = Open (Continued) VAL = 0V tON 80% SWITCH OUTPUT 0V tOFF 80% FIGURE 4A. MEASUREMENT POINTS VA VA OUTPUT OUTPUT VA = 0 to 4V Vertical: 2V/Div. Horizontal: 100ns/Div. FIGURE 4B. WAVEFORMS WITH TTL COMPATIBLE LOGIC INPUT VA = 0 to 15V Vertical: 5V/Div. Horizontal: 100ns/Div. FIGURE 4C. WAVEFORMS WITH CMOS COMPATIBLE LOGIC INPUT FIGURE 4. SWITCH tON AND tOFF 140 120 OFF ISOLATION (dB) 100 80 60 40 20 0 100Hz RL = 1kΩ 1kHz 10kHz 100kHz FREQUENCY (Hz) 1MHz FIGURE 5. HI-201 OFF ISOLATION vs FREQUENCY For more information see Application Notes AN520, AN521, AN531, AN532 and AN557. 7 HI-200, HI-201 Application Information Single Supply Operation The switch operation of the HI-200/201 is dependent upon an internally generated switching threshold voltage optimized for ±15V power supplies. The HI-200/201 does not provide the necessary internal switching threshold in a single supply system. Therefore, if single supply operation is required, the HI-300 series of switches is recommended. The HI-300 series will remain operational to a minimum +5V single supply. Switch performance will degrade as power supply voltage is reduced from optimum levels (±15V). So it is recommended that a single supply design be thoroughly evaluated to ensure that the switch will meet the requirements of the application. For further information see Application Notes AN520, AN521, AN531, AN532, AN543 and AN557. 8 HI-200 Die Characteristics DIE DIMENSIONS: 54 mils x 79 mils METALLIZATION: Type: CuAl Thickness: 16kÅ ±2kÅ PASSIVATION: Type: Nitride over Silox Nitride Thickness: 3.5kÅ ±1kÅ Silox Thickness: 12kÅ ±2kÅ WORST CASE CURRENT DENSITY: 2 x 105 A/cm2 at 25mA Metallization Mask Layout HI-200 GND A2 A1 V+ 2 1 10 9 IN 2 3 8 IN 1 OUT 2 4 5 V- 6 VREF 7 OUT 1 9 HI-201 Die Characteristics DIE DIMENSIONS: 81 mils x 85 mils METALLIZATION: Type: CuAl Thickness: 16kÅ ±2kÅ PASSIVATION: Type: Nitride over Silox Nitride Thickness: 3.5kÅ ±1kÅ Silox Thickness: 12kÅ ±2kÅ WORST CASE CURRENT DENSITY: 2 x 105 A/cm2 at 25mA Metallization Mask Layout HI-201 A1 A2 OUT 1 2 1 16 15 OUT 2 IN 1 3 14 IN 2 13 V- V+ 4 5 12 VREF GND IN 4 6 11 IN 3 OUT 4 7 8 9 10 OUT 3 A4 A3 All Intersil semiconductor products are manufactured, assembled and tested under ISO9000 quality systems certification. Intersil semiconductor products are sold by description only. Intersil Corporation reserves the right to make changes in circuit design and/or specifications at any time without notice. Accordingly, the reader is cautioned to verify that data sheets are current before placing orders. Information furnished by Intersil is believed to be accurate and reliable. However, no responsibility is assumed by Intersil or its subsidiaries for its use; nor for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of Intersil or its subsidiaries. For information regarding Intersil Corporation and its products, see web site http://www.intersil.com Sales Office Headquarters NORTH AMERICA Intersil Corporation P. O. Box 883, Mail Stop 53-204 Melbourne, FL 32902 TEL: (407) 724-7000 FAX: (407) 724-7240 EUROPE Intersil SA Mercure Center 100, Rue de la Fusee 1130 Brussels, Belgium TEL: (32) 2.724.2111 FAX: (32) 2.724.22.05 ASIA Intersil (Taiwan) Ltd. 7F-6, No. 101 Fu Hsing North Road Taipei, Taiwan Republic of China TEL: (886) 2 2716 9310 FAX: (886) 2 2715 3029 10
