HI-303

® HI-303 Data Sheet November 17, 2004 FN3125.10 Dual, SPDT CMOS Analog Switch The HI-303 switch is a monolithic device fabricated using CMOS technology and the Intersil dielectric isolation process. This switch features break-before-make switching, low and nearly constant ON resistance over the full analog signal range, and low power dissipation. The HI-303 is TTL compatible and has a logic “0” condition with an input less than 0.8V and a logic “1” condition with an input greater than 4V. (See pinouts for switch conditions with a logic “1” input.) Features • Analog Signal Range (±15V Supplies) . . . . . . . . . . ±15V • Low Leakage at 25oC . . . . . . . . . . . . . . . . . . . . . . . 40pA • Low Leakage at 125oC . . . . . . . . . . . . . . . . . . . . . . . 1nA • Low On Resistance at 25oC . . . . . . . . . . . . . . . . . . . 35Ω • Break-Before-Make Delay . . . . . . . . . . . . . . . . . . . . 60ns • Charge Injection . . . . . . . . . . . . . . . . . . . . . . . . . . . 30pC • TTL, CMOS Compatible • Symmetrical Switch Elements S Functional Diagram IN N P D • Low Operating Power (Typ) . . . . . . . . . . . . . . . . . . . . 1.0mW • Pb-Free Available (RoHS Compliant) Applications • Sample and Hold (i.e., Low Leakage Switching) • Op Amp Gain Switching (i.e., Low On Resistance) • Portable, Battery Operated Circuits • Low Level Switching Circuits Pinout Switch States Shown For A Logic “1” Input HI-303 (PDIP, CERDIP, SOIC) TOP VIEW NC 1 S3 2 D3 3 D1 4 S1 5 IN1 6 GND 7 14 V+ 13 S4 12 D4 11 D2 10 S2 9 IN2 8 V- • Dual or Single Supply Systems Ordering Information PART NUMBER HI1-0303-2 HI1-0303-5 HI3-0303-5 TEMP. RANGE (oC) -55 to 125 0 to 75 0 to 75 0 to 75 -40 to 85 -40 to 85 PACKAGE 14 Ld CERDIP 14 Ld CERDIP 14 Ld PDIP 14 Ld PDIP (Pb-free) 14 Ld SOIC 14 Ld SOIC (Pb-free) PKG. DWG. # F14.3 F14.3 E14.3 E14.3 M14.15 M14.15 LOGIC 0 1 SW1, SW2 OFF ON SW3, SW4 ON OFF HI3-0303-5Z (See Note) HI9P0303-9 HI9P0303-9Z (See Note) NOTE: Intersil Pb-free products employ special Pb-free material sets; molding compounds/die attach materials and 100% matte tin plate termination finish, which are RoHS compliant and compatible with both SnPb and Pb-free soldering operations. Intersil Pb-free products are MSL classified at Pb-free peak reflow temperatures that meet or exceed the Pb-free requirements of IPC/JEDEC J STD-020C. 1 CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures. 1-888-INTERSIL or 321-724-7143 | Intersil (and design) is a registered trademark of Intersil Americas Inc. Copyright © Intersil Americas Inc. 2003, 2004. All Rights Reserved All other trademarks mentioned are the property of their respective owners. HI-303 Schematic Diagrams A V+ MN1B MN2B MP5B IN MP4B MN3B OUT MN4B MN6B MP3B MP2B MP1B V- A SWITCH CELL V+ D2A 200Ω LOGIC IN D1A GND VSWITCH CELL DRIVER (ONE PER SWITCH CELL) DIGITAL INPUT BUFFER AND LEVEL SHIFTER MN1A MN2A MN3A MN4A MN5A MN6A MN7A MN8A A A MP1A MP2A MP3A MP4A MP5A MP6A MP7A MP8A 2 FN3125.10 November 17, 2004 HI-303 Absolute Maximum Ratings Voltage Between Supplies (V+ to V-) . . . . . . . . . . . . . . . . 44V (±22V) Digital Input Voltage . . . . . . . . . . . . . . . . . . . . . . (V+) +4V to (V-) -4V Analog Input Voltage . . . . . . . . . . . . . . . . . . (V+) +1.5V to (V-) -1.5V Typical Derating Factor . . . . . . . . . 1.5mA/MHz Increase in ICCOP ESD Classification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Class 1 Thermal Information Thermal Resistance (Typical, Note 1) θJA (oC/W) θJC (oC/W) CERDIP Package. . . . . . . . . . . . . . . . . 80 24 PDIP Package . . . . . . . . . . . . . . . . . . . 90 N/A SOIC Package . . . . . . . . . . . . . . . . . . . 120 N/A Maximum Junction Temperature Ceramic Packages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175oC Plastic Packages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150oC Maximum Storage Temperature Range . . . . . . . . . . -65oC to 150oC Maximum Lead Temperature (Soldering 10s) . . . . . . . . . . . . 300oC (SOIC - Lead Tips Only) Operating Conditions Temperature Range HI-303-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -55oC to 125oC HI-303-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0oC to 75oC HI-303-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -40oC to 85oC CAUTION: Stresses above those listed in “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress only rating and operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not implied. NOTE: 1. θJA is measured with the component mounted on a low effective thermal conductivity test board in free air. See Tech Brief TB379 for details. Electrical Specifications Supplies = +15V, -15V; VIN = Logic Input. VIN - for Logic “1” = 4V, for Logic “0” = 0.8V. Unless Otherwise Specified TEMP (oC) -2 MIN TYP MAX MIN -5, -9 TYP MAX UNITS PARAMETER DYNAMIC CHARACTERISTICS Switch ON Time, tON Switch OFF Time, tOFF Break-Before-Make Delay, tOPEN Charge Injection Voltage, ∆V (Note 7) OFF Isolation (Note 6) Input Switch Capacitance, CS(OFF) Output Switch Capacitance, CD(OFF) Output Switch Capacitance, CD(ON) Digital Input Capacitance, CIN DIGITAL INPUT CHARACTERISTICS Input Low Level, VINL Input High Level, VINH (Note 10) Input Leakage Current (Low), IINL (Note 5) Input Leakage Current (High), IINH (Note 5) ANALOG SWITCH CHARACTERISTICS Analog Signal Range ON Resistance, rON (Note 2) 25 25 25 25 25 25 25 25 25 - 210 160 60 3 60 16 14 35 5 300 250 - - 210 160 60 3 60 16 14 35 5 300 250 - ns ns ns mV dB pF pF pF pF Full Full Full Full 4 - - 0.8 1 1 4 - - 0.8 1 1 V V µA µA Full 25 Full -15 - 35 40 0.04 1 0.04 1 0.03 0.5 +15 50 75 1 100 1 100 1 100 -15 - 35 40 0.04 0.2 0.04 0.2 0.03 0.2 +15 50 75 5 100 5 100 5 100 V Ω Ω nA nA nA nA nA nA OFF Input Leakage Current, IS(OFF) (Note 3) 25 Full OFF Output Leakage Current, ID(OFF) (Note 3) 25 Full ON Leakage Current, ID(ON) (Note 4) 25 Full 3 FN3125.10 November 17, 2004 HI-303 Electrical Specifications Supplies = +15V, -15V; VIN = Logic Input. VIN - for Logic “1” = 4V, for Logic “0” = 0.8V. Unless Otherwise Specified (Continued) TEMP (oC) -2 MIN TYP MAX MIN -5, -9 TYP MAX UNITS PARAMETER POWER SUPPLY CHARACTERISTICS Current, I+ (Note 8) 25 Full - 0.09 0.01 0.01 0.01 - 0.5 1 10 100 10 100 10 100 - 0.09 0.01 0.01 0.01 - 0.5 1 100 100 100 - mA mA µA µA µA µA µA µA Current, I- (Note 8) 25 Full Current, I+ (Note 9) 25 Full Current, I- (Note 9) 25 Full NOTES: 2. VS = ±10V, IOUT = 10mA. On resistance derived from the voltage measured across the switch under these conditions. 3. VS = ±14V, VD = 14V. 4. VS = VD = ±14V. 5. The digital inputs are diode protected MOS gates and typical leakages of 1nA or less can be expected. 6. VS = 1VRMS , f = 500kHz, CL = 15pF, RL = 1K. 7. VS = 0V, CL = 10nF, Logic Drive = 5V pulse. Switches are symmetrical; S and D may be interchanged. Charge Injection = Q = CL x ∆V. 8. VIN = 4V (one input, all other inputs = 0V). 9. VIN = 0.8V (all inputs). 10. To drive from DTL/TTL circuits, pullup resistors to +5V supply are recommended. Test Circuits and Waveforms 15V S VS = +3V RL 300Ω LOGIC INPUT GND V-15V 90% 0V SWITCH OUTPUT tOFF tON 10% V+ D VO CL 33pF SWITCH OUTPUT LOGIC INPUT 0V VS LOGIC “1” = SWITCH ON VINH 50% 50% SWITCH TYPE HI-303 VINH 4V FIGURE 1A. TEST CIRCUIT FIGURE 1. SWITCH tON AND tOFF FIGURE 1B. MEASUREMENT POINTS 4 FN3125.10 November 17, 2004 HI-303 Test Circuits and Waveforms (Continued) LOGIC INPUT (V) +15V V+ RGEN = 0 S D RL 10kΩ CL 10pF 6 4 2 0 LOGIC INPUT VGEN IN VVLOGIC GND -15V 0 0.4 0.8 TIME (µs) 1.2 1.6 FIGURE 2A. TEST CIRCUIT FIGURE 2B. TTL LOGIC INPUT OUTPUT VOLTAGE (V) 10 5 0 VGEN = 10V (NOTE 11) OUTPUT VOLTAGE (V) 5 0 VGEN = 5V 0 0.4 0.8 TIME (µs) 1.2 1.6 0 0.4 0.8 TIME (µs) 1.2 1.6 FIGURE 2C. VANALOG = 10V FIGURE 2D. VANALOG = 5V OUTPUT VOLTAGE (V) 5 0 -5 VGEN = 0V OUTPUT VOLTAGE (V) 0 -5 VGEN = -5V 0 0.4 0.8 TIME (µs) 1.2 1.6 0 0.4 0.8 TIME (µs) 1.2 1.6 FIGURE 2E. VANALOG = 0V FIGURE 2F. VANALOG = -5V 5 FN3125.10 November 17, 2004 HI-303 Test Circuits and Waveforms (Continued) OUTPUT VOLTAGE (V) 0 -5 -10 VGEN = -10V 0 0.4 0.8 TIME (µs) 1.2 1.6 FIGURE 2G. VANALOG = -10V NOTE: 11. If RGEN , RL or CL is increased, there will be proportional increases in rise and/or fall RC times. FIGURE 2. SWITCHING WAVEFORMS FOR VARIOUS ANALOG INPUT VOLTAGES 15V S1 VS1 = +3V VS2 = +3V S2 V+ D1 D2 OUT 1 OUT 2 LOGIC INPUT 0V LOGIC “1” = SWITCH ON VINH RL1 = RL2 = 300Ω CL1 = CL2 = 33pF RL2 LOGIC INPUT GND V-15V CL2 RL1 CL1 0V SWITCH OUTPUTS 50% 0V 50% 50% OUT 1 OUT 2 50% tOPEN SWITCH TYPE HI-303 VINH 5V tOPEN FIGURE 3A. TEST CIRCUIT FIGURE 3B. MEASUREMENT POINTS FIGURE 3. BREAK-BEFORE-MAKE DELAY (tOPEN) Typical Performance Curves 80 DRAIN TO SOURCE ON RESISTANCE (Ω) DRAIN TO SOURCE ON RESISTANCE (Ω) V+ = +15V, V- = -15V 80 TA = 25oC D 60 125oC 25oC -55oC 60 C 40 40 B A 20 20 A B C D V+ = +15V, V- = -15V V+ = +10V, V- = -10V V+ = +7.5V, V- = -7.5V V+ = +5V, V- = -5V -10 -5 0 5 10 15 0 -15 -10 -5 0 5 10 15 0 -15 DRAIN VOLTAGE (V) DRAIN VOLTAGE (V) FIGURE 4. rDS(ON) vs VD FIGURE 5. rDS(ON) vs VD 6 FN3125.10 November 17, 2004 HI-303 Typical Performance Curves 100 V+ = +15V, V- = -15V TA = 25oC, VS = 15V, RL = 2K POWER DISSIPATION (mW) 80 10 OFF ISOLATION (dB) RL = 100Ω 60 RL = 1k Ω 40 (Continued) 100 V+ = +15V, V- = -15V CLOAD = 30pF, VS = 1VRMS 1.0 20 0.1 1 10 100 1K 10K 100K 1M LOGIC SWITCHING FREQUENCY (50% DUTY CYCLE) (Hz) 0 105 106 107 108 FREQUENCY (Hz) FIGURE 6. DEVICE POWER DISSIPATION vs SWITCHING FREQUENCY (SINGLE LOGIC INPUT) 10.0 V+ = +15V, V- = -15V FIGURE 7. OFF ISOLATION vs FREQUENCY 10.0 V+ = +15V, V- = -15V | VD | = | VS | = 14V SOURCE OR DRAIN OFF LEAKAGE CURRENT (nA) 1.0 ID(ON) (nA) 0.1 1.0 0.1 0.01 25 75 125 TEMPERATURE (oC) 0.01 25 75 125 TEMPERATURE (oC) FIGURE 8. IS(OFF) OR ID(OFF) vs TEMPERATURE* FIGURE 9. ID(ON) vs TEMPERATURE* * The net leakage into the source or drain is the N-Channel leakage minus the P-Channel leakage. This difference can be positive, negative or zero depending on the analog voltage and temperature, and will vary greatly from unit to unit. 60 OUTPUT ON CAPACITANCE (pF) 16 INPUT CAPACITANCE (pF) 50 12 40 8 TRANSITION (INDETERMINATE DUE TO ACTIVE INPUT) 30 4 20 0 2 4 6 8 10 12 14 16 DRAIN VOLTAGE (V) 0 2 4 6 8 10 12 14 16 INPUT VOLTAGE (V) FIGURE 10. OUTPUT ON CAPACITANCE vs DRAIN VOLTAGE FIGURE 11. DIGITAL INPUT CAPACITANCE vs INPUT VOLTAGE 7 FN3125.10 November 17, 2004 HI-303 Typical Performance Curves 300 V+ = +15V, V- = -15V VINH = 4.0V, VINL = 0V SWITCHING TIME (ns) tON 200 SWITCHING TIME (ns) 300 V+ = +15V, TA = 25oC VINH = 4V, VINL = 0V (Continued) tON 200 tOFF tOFF 100 100 -55 -35 -15 5 25 45 65 85 105 125 0 5 10 15 TEMPERATURE (oC) NEGATIVE SUPPLY (V) FIGURE 12. SWITCHING TIME vs TEMPERATURE FIGURE 13. SWITCHING TIME vs NEGATIVE SUPPLY VOLTAGE SWITCHING TIME/BREAK-BEFORE-MAKE TIME (µs) 1.8 1.6 1.4 1.2 1.0 0.8 0.6 0.4 0.2 0 0 5 tOPEN ONLY tOFF INPUT SWITCHING THRESHOLD (V) V- = -15V, TA = 25oC VINH = 4.0V, VINL = 0V 7 V- = -15V, TA = 25oC 6 5 4 3 2 1 0 tON 10 15 0 5 10 15 POSITIVE SUPPLY VOLTAGE (V) POSITIVE SUPPLY VOLTAGE (V) FIGURE 14. SWITCHING TIME AND BREAK-BEFORE-MAKE TIME vs POSITIVE SUPPLY VOLTAGE FIGURE 15. INPUT SWITCHING THRESHOLD vs POSITIVE SUPPLY VOLTAGE 8 FN3125.10 November 17, 2004 HI-303 Dual-In-Line Plastic Packages (PDIP) N E1 INDEX AREA 12 3 N/2 -B-AD BASE PLANE SEATING PLANE D1 B1 B 0.010 (0.25) M D1 A1 A2 L A C L E E14.3 (JEDEC MS-001-AA ISSUE D) 14 LEAD DUAL-IN-LINE PLASTIC PACKAGE INCHES SYMBOL A A1 MIN 0.015 0.115 0.014 0.045 0.008 0.735 0.005 0.300 0.240 MAX 0.210 0.195 0.022 0.070 0.014 0.775 0.325 0.280 MILLIMETERS MIN 0.39 2.93 0.356 1.15 0.204 18.66 0.13 7.62 6.10 MAX 5.33 4.95 0.558 1.77 0.355 19.68 8.25 7.11 NOTES 4 4 8 5 5 6 5 6 7 4 9 Rev. 0 12/93 -C- A2 B B1 C D D1 E E1 e eA eB L N eA eC C e C A BS eB NOTES: 1. Controlling Dimensions: INCH. In case of conflict between English and Metric dimensions, the inch dimensions control. 2. Dimensioning and tolerancing per ANSI Y14.5M-1982. 3. Symbols are defined in the “MO Series Symbol List” in Section 2.2 of Publication No. 95. 4. Dimensions A, A1 and L are measured with the package seated in JEDEC seating plane gauge GS-3. 5. D, D1, and E1 dimensions do not include mold flash or protrusions. Mold flash or protrusions shall not exceed 0.010 inch (0.25mm). 6. E and eA are measured with the leads constrained to be perpendicular to datum -C- . 7. eB and eC are measured at the lead tips with the leads unconstrained. eC must be zero or greater. 8. B1 maximum dimensions do not include dambar protrusions. Dambar protrusions shall not exceed 0.010 inch (0.25mm). 9. N is the maximum number of terminal positions. 10. Corner leads (1, N, N/2 and N/2 + 1) for E8.3, E16.3, E18.3, E28.3, E42.6 will have a B1 dimension of 0.030 - 0.045 inch (0.76 1.14mm). 0.100 BSC 0.300 BSC 0.115 14 0.430 0.150 - 2.54 BSC 7.62 BSC 10.92 3.81 14 2.93 9 FN3125.10 November 17, 2004 HI-303 Ceramic Dual-In-Line Frit Seal Packages (CERDIP) c1 -A-DBASE METAL E b1 M -Bbbb S BASE PLANE SEATING PLANE S1 b2 b ccc M C A-B S AA C A-B S D Q -CA L DS M (b) SECTION A-A (c) LEAD FINISH F14.3 MIL-STD-1835 GDIP1-T14 (D-1, CONFIGURATION A) 14 LEAD CERAMIC DUAL-IN-LINE FRIT SEAL PACKAGE INCHES SYMBOL A b b1 b2 b3 c MIN 0.014 0.014 0.045 0.023 0.008 0.008 0.220 MAX 0.200 0.026 0.023 0.065 0.045 0.018 0.015 0.785 0.310 MILLIMETERS MIN 0.36 0.36 1.14 0.58 0.20 0.20 5.59 MAX 5.08 0.66 0.58 1.65 1.14 0.46 0.38 19.94 7.87 NOTES 2 3 4 2 3 5 5 6 7 2, 3 8 Rev. 0 4/94 α eA c1 D E e eA eA/2 L Q S1 e DS eA/2 c 0.100 BSC 0.300 BSC 0.150 BSC 0.125 0.015 0.005 90o 14 0.200 0.060 105o 0.015 0.030 0.010 0.0015 2.54 BSC 7.62 BSC 3.81 BSC 3.18 0.38 0.13 90o 14 5.08 1.52 105o 0.38 0.76 0.25 0.038 aaa M C A - B S D S NOTES: 1. Index area: A notch or a pin one identification mark shall be located adjacent to pin one and shall be located within the shaded area shown. The manufacturer’s identification shall not be used as a pin one identification mark. 2. The maximum limits of lead dimensions b and c or M shall be measured at the centroid of the finished lead surfaces, when solder dip or tin plate lead finish is applied. 3. Dimensions b1 and c1 apply to lead base metal only. Dimension M applies to lead plating and finish thickness. 4. Corner leads (1, N, N/2, and N/2+1) may be configured with a partial lead paddle. For this configuration dimension b3 replaces dimension b2. 5. This dimension allows for off-center lid, meniscus, and glass overrun. 6. Dimension Q shall be measured from the seating plane to the base plane. 7. Measure dimension S1 at all four corners. 8. N is the maximum number of terminal positions. 9. Dimensioning and tolerancing per ANSI Y14.5M - 1982. 10. Controlling dimension: INCH. α aaa bbb ccc M N 10 FN3125.10 November 17, 2004 HI-303 Small Outline Plastic Packages (SOIC) N INDEX AREA E -B1 2 3 SEATING PLANE -AD -CA h x 45o H 0.25(0.010) M BM M14.15 (JEDEC MS-012-AB ISSUE C) 14 LEAD NARROW BODY SMALL OUTLINE PLASTIC PACKAGE INCHES SYMBOL A L MILLIMETERS MIN 1.35 0.10 0.33 0.19 8.55 3.80 MAX 1.75 0.25 0.51 0.25 8.75 4.00 NOTES 9 3 4 5 6 7 8o Rev. 0 12/93 MIN 0.0532 0.0040 0.013 0.0075 0.3367 0.1497 MAX 0.0688 0.0098 0.020 0.0098 0.3444 0.1574 A1 B C D E α µ A1 0.10(0.004) C e B 0.25(0.010) M C AM BS e H h L N 0.050 BSC 0.2284 0.0099 0.016 14 0o 8o 0.2440 0.0196 0.050 1.27 BSC 5.80 0.25 0.40 14 0o 6.20 0.50 1.27 NOTES: 1. Symbols are defined in the “MO Series Symbol List” in Section 2.2 of Publication Number 95. 2. Dimensioning and tolerancing per ANSI Y14.5M-1982. 3. Dimension “D” does not include mold flash, protrusions or gate burrs. Mold flash, protrusion and gate burrs shall not exceed 0.15mm (0.006 inch) per side. 4. Dimension “E” does not include interlead flash or protrusions. Interlead flash and protrusions shall not exceed 0.25mm (0.010 inch) per side. 5. The chamfer on the body is optional. If it is not present, a visual index feature must be located within the crosshatched area. 6. “L” is the length of terminal for soldering to a substrate. 7. “N” is the number of terminal positions. 8. Terminal numbers are shown for reference only. 9. The lead width “B”, as measured 0.36mm (0.014 inch) or greater above the seating plane, shall not exceed a maximum value of 0.61mm (0.024 inch). 10. Controlling dimension: MILLIMETER. Converted inch dimensions are not necessarily exact. α All Intersil U.S. products are manufactured, assembled and tested utilizing ISO9000 quality systems. Intersil Corporation’s quality certifications can be viewed at www.intersil.com/design/quality Intersil products are sold by description only. Intersil Corporation reserves the right to make changes in circuit design, software and/or specifications at any time without notice. Accordingly, the reader is cautioned to verify that data sheets are current before placing orders. Information furnished by Intersil is believed to be accurate and reliable. However, no responsibility is assumed by Intersil or its subsidiaries for its use; nor for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of Intersil or its subsidiaries. For information regarding Intersil Corporation and its products, see www.intersil.com 11 FN3125.10 November 17, 2004
