HS-117

HS-117RH Data Sheet February 2000 File Number 4560.4 Radiation Hardened Adjustable Positive Voltage Regulator The Radiation Hardened HS-117RH is an adjustable positive voltage linear regulator capable of operating up to 40VDC. The voltage is adjustable from 1.2V to 37V with two external resistors. The device is capable of sourcing from 50mA to 1.25APEAK (Min). Protection is provided by the on-chip thermal shutdown and output current limiting circuitry. The Intersil HS-117RH has advantages over other industry standard types, in that circuitry is incorporated to minimize the effects of radiation and temperature on device stability. Negligible low dose rate sensitivity is achieved through the use of vertical transistor geometries. Constructed with the Intersil dielectrically isolated Rad Hard Silicon Gate (RSG) process, the HS-117RH is immune to Single Event Latch-up and has been specifically designed to provide highly reliable performance in harsh radiation environments. Specifications for Rad Hard QML devices are controlled by the Defense Supply Center in Columbus (DSCC). The SMD numbers listed here must be used when ordering. Detailed Electrical Specifications for the HS-117RH are contained in SMD 5962-99547. A “hot-link” is provided on our homepage for downloading. www.intersil.com/spacedefense/space.asp Features • Electrically Screened to DSSC SMD # 5962-99547 • QML Qualified per MIL-PRF-38535 Requirements • Radiation Environment - 300kRAD(Si) (Max) - Latch-up Immune - Negligible Low Dose Rate Effects Sensitivity • Superior Temperature Stability • Over-Temp and Over-Current/Voltage Protection Applications • Switch Mode DC - DC Power Conversion • Housekeeping Supplies for Motors • Power Supplies for Robotic Control Ordering Information ORDERING NUMBER 5962F9954701VXC 5962F9954701QXC 5962F9954701/VYA 5962F9954701/QYA HS9S-117RH/Proto INTERNAL MKT. NUMBER HS9S-117RH-Q HS9S-117RH-8 HSYE-117RH-Q HSYE-117RH-8 HS9S-117RH/Proto HSYE-117RH/Proto TEMP. RANGE (oC) -55 to 125 -55 to 125 -55 to 125 -55 to 125 -55 to 125 -55 to 125 Pinout HS9S-117RH (TO-257AA FLANGE MOUNT) TOP VIEW HSYE-117RH/Proto 3 2 1 IN OUT ADJUST HSYE-117RH (SMD.5 CLCC) BOTTOM VIEW 2 3 1 - ADJUST 2 - IN 3 - OUT 1 NOTE: No current JEDEC outline for the SMD.5 package. Refer to SMD for package dimensions. The TO-257 is a totally isolated metal package. 1 CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures. 1-888-INTERSIL or 321-724-7143 | Copyright © Intersil Corporation 2000 HS-117RH Die Characteristics DIE DIMENSIONS 2616µm x 2794µm (103 mils x 110 mils) 483µm ±25.4µm (19 mils ±1 mil) INTERFACE MATERIALS Glassivation: Type: Silox (SiO2) Thickness: 8.0kÅ ±1.0kÅ Top Metallization: Type: AlSiCu Thickness: 16.0kÅ ±2kÅ Substrate: Radiation Hardened Silicon Gate, Dielectric Isolation Backside Finish: Gold ASSEMBLY RELATED INFORMATION Substrate Potential: Unbiased (DI) ADDITIONAL INFORMATION Worst Case Current Density:
