IRFZ44NPBF

PD - 94787 IRFZ44NPbF Advanced Process Technology Ultra Low On-Resistance Dynamic dv/dt Rating 175°C Operating Temperature Fast Switching Fully Avalanche Rated Lead-Free Advanced HEXFET® Power MOSFETs from International Rectifier utilize advanced processing techniques to achieve extremely low on-resistance per silicon area. This benefit, combined with the fast switching speed and ruggedized device design that HEXFET power MOSFETs are well known for, provides the designer with an extremely efficient and reliable device for use in a wide variety of applications. The TO-220 package is universally preferred for all commercial-industrial applications at power dissipation levels to approximately 50 watts. The low thermal resistance and low package cost of the TO-220 contribute to its wide acceptance throughout the industry. HEXFET® Power MOSFET D VDSS = 55V RDS(on) = 17.5mΩ G S ID = 49A Description TO-220AB Absolute Maximum Ratings Parameter ID @ TC = 25°C ID @ TC = 100°C IDM PD @TC = 25°C VGS IAR EAR dv/dt TJ TSTG Continuous Drain Current, VGS @ 10V Continuous Drain Current, VGS @ 10V Pulsed Drain Current Power Dissipation Linear Derating Factor Gate-to-Source Voltage Avalanche Current Repetitive Avalanche Energy Peak Diode Recovery dv/dt Operating Junction and Storage Temperature Range Soldering Temperature, for 10 seconds Mounting torque, 6-32 or M3 srew Max. 49 35 160 94 0.63 ± 20 25 9.4 5.0 -55 to + 175 300 (1.6mm from case ) 10 lbf•in (1.1N•m) Units A W W/°C V A mJ V/ns °C Thermal Resistance Parameter RθJC RθCS RθJA Junction-to-Case Case-to-Sink, Flat, Greased Surface Junction-to-Ambient Typ. ––– 0.50 ––– Max. 1.5 ––– 62 Units °C/W www.irf.com 1 10/31/03 IRFZ44NPbF Electrical Characteristics @ TJ = 25°C (unless otherwise specified) V(BR)DSS ∆V(BR)DSS/∆TJ RDS(on) VGS(th) gfs IDSS IGSS Qg Qgs Qgd td(on) tr td(off) tf LD LS Ciss Coss Crss EAS Parameter Drain-to-Source Breakdown Voltage Breakdown Voltage Temp. Coefficient Static Drain-to-Source On-Resistance Gate Threshold Voltage Forward Transconductance Drain-to-Source Leakage Current Gate-to-Source Forward Leakage Gate-to-Source Reverse Leakage Total Gate Charge Gate-to-Source Charge Gate-to-Drain ("Miller") Charge Turn-On Delay Time Rise Time Turn-Off Delay Time Fall Time Internal Drain Inductance Internal Source Inductance Input Capacitance Output Capacitance Reverse Transfer Capacitance Single Pulse Avalanche Energy Min. Typ. Max. Units Conditions 55 ––– ––– V VGS = 0V, ID = 250µA ––– 0.058 ––– V/°C Reference to 25°C, I D = 1mA ––– ––– 17.5 mΩ VGS = 10V, ID = 25A 2.0 ––– 4.0 V VDS = VGS, ID = 250µA 19 ––– ––– S VDS = 25V, ID = 25A ––– ––– 25 VDS = 55V, VGS = 0V µA ––– ––– 250 VDS = 44V, VGS = 0V, TJ = 150°C ––– ––– 100 VGS = 20V nA ––– ––– -100 VGS = -20V ––– ––– 63 ID = 25A ––– ––– 14 nC VDS = 44V ––– ––– 23 VGS = 10V, See Fig. 6 and 13 ––– 12 ––– VDD = 28V ––– 60 ––– ID = 25A ns ––– 44 ––– RG = 12Ω ––– 45 ––– VGS = 10V, See Fig. 10 Between lead, 4.5 ––– ––– 6mm (0.25in.) nH G from package ––– 7.5 ––– and center of die contact ––– 1470 ––– VGS = 0V ––– 360 ––– VDS = 25V ––– 88 ––– pF ƒ = 1.0MHz, See Fig. 5 ––– 530 150 mJ IAS = 25A, L = 0.47mH D S Source-Drain Ratings and Characteristics IS ISM VSD trr Qrr ton Notes: Parameter Continuous Source Current (Body Diode) Pulsed Source Current (Body Diode) Diode Forward Voltage Reverse Recovery Time Reverse Recovery Charge Forward Turn-On Time Min. Typ. Max. Units Conditions D MOSFET symbol 49 ––– ––– showing the A G integral reverse ––– ––– 160 S p-n junction diode. ––– ––– 1.3 V TJ = 25°C, IS = 25A, VGS = 0V ––– 63 95 ns TJ = 25°C, IF = 25A ––– 170 260 nC di/dt = 100A/µs Intrinsic turn-on time is negligible (turn-on is dominated by LS+LD) Repetitive rating; pulse width limited by max. junction temperature. (See fig. 11) Starting TJ = 25°C, L = 0.48mH RG = 25Ω, IAS = 25A. (See Figure 12) ISD ≤ 25A, di/dt ≤ 230A/µs, VDD ≤ V(BR)DSS, TJ ≤ 175°C Pulse width ≤ 400µs; duty cycle ≤ 2%. This is a typical value at device destruction and represents operation outside rated limits. This is a calculated value limited to TJ = 175°C . 2 www.irf.com IRFZ44NPbF 1000 VGS 15V 10V 8.0V 7.0V 6.0V 5.5V 5.0V BOTTOM 4.5V TOP 1000 I D , Drain-to-Source Current (A) 100 I D , Drain-to-Source Current (A) 100 VGS 15V 10V 8.0V 7.0V 6.0V 5.5V 5.0V BOTTOM 4.5V TOP 4.5V 10 10 4.5V 1 0.1 20µs PULSE WIDTH TJ = 25 °C 1 10 100 1 0.1 20µs PULSE WIDTH TJ = 175 ° C 1 10 100 VDS , Drain-to-Source Voltage (V) VDS , Drain-to-Source Voltage (V) Fig 1. Typical Output Characteristics Fig 2. Typical Output Characteristics 1000 2.5 RDS(on) , Drain-to-Source On Resistance (Normalized) ID = 49A I D , Drain-to-Source Current (A) TJ = 25 ° C TJ = 175 ° C 2.0 100 1.5 1.0 10 0.5 1 V DS = 25V 20µs PULSE WIDTH 4 5 6 7 8 9 10 11 0.0 -60 -40 -20 0 VGS = 10V 20 40 60 80 100 120 140 160 180 VGS , Gate-to-Source Voltage (V) TJ , Junction Temperature ( °C) Fig 3. Typical Transfer Characteristics Fig 4. Normalized On-Resistance Vs. Temperature www.irf.com 3 IRFZ44NPbF 2500 VGS , Gate-to-Source Voltage (V) 2000 VGS = 0V, f = 1MHz Ciss = Cgs + Cgd , Cds SHORTED Crss = Cgd Coss = Cds + Cgd 20 ID = 25A VDS = 44V VDS = 27V VDS = 11V 16 C, Capacitance (pF) 1500 Ciss 12 1000 8 500 Coss Crss 4 0 1 10 100 0 VDS , Drain-to-Source Voltage (V) 0 10 20 30 40 50 60 70 QG , Total Gate Charge (nC) Fig 5. Typical Capacitance Vs. Drain-to-Source Voltage Fig 6. Typical Gate Charge Vs. Gate-to-Source Voltage 1000 1000 ISD , Reverse Drain Current (A) OPERATION IN THIS AREA LIMITED BY R DS(on) 100 TJ = 175 ° C ID, Drain-to-Source Current (A) 100 10 10 100µsec 1msec 1 TJ = 25 ° C 1 Tc = 25°C Tj = 175°C Single Pulse 1 10 VDS , Drain-toSource Voltage (V) 10msec 0.1 0.0 V GS = 0 V 0.6 1.2 1.8 2.4 0.1 VSD ,Source-to-Drain Voltage (V) 100 Fig 7. Typical Source-Drain Diode Forward Voltage Fig 8. Maximum Safe Operating Area 4 www.irf.com IRFZ44NPbF 50 VDS 40 RD VGS RG D.U.T. + ID , Drain Current (A) -VDD 30 VGS Pulse Width ≤ 1 µs Duty Factor ≤ 0.1 % 20 10 Fig 10a. Switching Time Test Circuit VDS 90% 0 25 50 TC , Case Temperature ( ° C) 75 100 125 150 175 Fig 9. Maximum Drain Current Vs. Case Temperature 10% VGS td(on) tr t d(off) tf Fig 10b. Switching Time Waveforms 10 Thermal Response (Z thJC ) 1 D = 0.50 0.20 0.10 PDM SINGLE PULSE (THERMAL RESPONSE) t1 t2 Notes: 1. Duty factor D = t 1 / t 2 2. Peak TJ = P DM x Z thJC + TC 0.0001 0.001 0.01 0.1 0.1 0.05 0.02 0.01 0.01 0.00001 t1 , Rectangular Pulse Duration (sec) Fig 11. Maximum Effective Transient Thermal Impedance, Junction-to-Case www.irf.com 5 IRFZ44NPbF EAS , Single Pulse Avalanche Energy (mJ) 15V 300 TOP 240 VDS L DRIVER BOTTOM ID 10A 18A 25A RG 20V D.U.T IAS tp + V - DD 180 A 0.01Ω 120 Fig 12a. Unclamped Inductive Test Circuit V(BR)DSS tp 60 0 25 Starting TJ , Junction Temperature ( °C) 50 75 100 125 150 175 Fig 12c. Maximum Avalanche Energy Vs. Drain Current I AS Fig 12b. Unclamped Inductive Waveforms Current Regulator Same Type as D.U.T. 50KΩ QG 12V .2µF .3µF VGS QGS VG QGD VGS 3mA D.U.T. + V - DS Charge IG ID Current Sampling Resistors Fig 13a. Basic Gate Charge Waveform Fig 13b. Gate Charge Test Circuit 6 www.irf.com IRFZ44NPbF Peak Diode Recovery dv/dt Test Circuit D.U.T* + Circuit Layout Considerations • Low Stray Inductance • Ground Plane • Low Leakage Inductance Current Transformer + + - RG VGS • dv/dt controlled by RG • ISD controlled by Duty Factor "D" • D.U.T. - Device Under Test + VDD * Reverse Polarity of D.U.T for P-Channel Driver Gate Drive P.W. Period D= P.W. Period [VGS=10V ] *** D.U.T. ISD Waveform Reverse Recovery Current Body Diode Forward Current di/dt D.U.T. VDS Waveform Diode Recovery dv/dt [VDD] Re-Applied Voltage Inductor Curent Body Diode Forward Drop Ripple ≤ 5% [ ISD ] *** VGS = 5.0V for Logic Level and 3V Drive Devices Fig 14. For N-channel HEXFET® power MOSFETs www.irf.com 7 IRFZ44NPbF TO-220AB Package Outline Dimensions are shown in millimeters (inches) 2.87 (.113) 2.62 (.103) 10.54 (.415) 10.29 (.405) 3.78 (.149) 3.54 (.139) -A6.47 (.255) 6.10 (.240) -B4.69 (.185) 4.20 (.165) 1.32 (.052) 1.22 (.048) 4 15.24 (.600) 14.84 (.584) 1.15 (.045) MIN 1 2 3 LEAD ASSIGNMENTS IGBTs, CoPACK 1 - GATE 2 1- GATE- DRAIN 1- GATE 32- DRAINSOURCE 2- COLLECTOR 3- SOURCE 3- EMITTER 4 - DRAIN LEAD ASSIGNMENTS HEXFET 14.09 (.555) 13.47 (.530) 4- DRAIN 4.06 (.160) 3.55 (.140) 4- COLLECTOR 3X 3X 1.40 (.055) 1.15 (.045) 0.93 (.037) 0.69 (.027) M BAM 3X 0.55 (.022) 0.46 (.018) 0.36 (.014) 2.54 (.100) 2X NOTES: 1 DIMENSIONING & TOLERANCING PER ANSI Y14.5M, 1982. 2 CONTROLLING DIMENSION : INCH 2.92 (.115) 2.64 (.104) 3 OUTLINE CONFORMS TO JEDEC OUTLINE TO-220AB. 4 HEATSINK & LEAD MEASUREMENTS DO NOT INCLUDE BURRS. TO-220AB Part Marking Information EXAMPLE: THIS IS AN IRF1010 LOT CODE 1789 ASSEMBLED ON WW 19, 1997 IN THE ASSEMBLY LINE "C" INTERNATIONAL RECTIFIER LOGO ASSEMBLY LOT CODE PART NUMBER Note: "P" in assembly line position indicates "Lead-Free" DATE CODE YEAR 7 = 1997 WEEK 19 LINE C Data and specifications subject to change without notice. This product has been designed and qualified for the Automotive [Q101] market. Qualification Standards can be found on IR’s Web site. IR WORLD HEADQUARTERS: 233 Kansas St., El Segundo, California 90245, USA Tel: (310) 252-7105 TAC Fax: (310) 252-7903 Visit us at www.irf.com for sales contact information.10/03 8 www.irf.com
