KSM

KSM Series Side Actuated Detect Switches Features/Benefits • Low profile – 1,5 mm • Momentary, normally closed contact • Infrared reflow soldering without cleaning • Thermoformed tape & reel • RoHS compliant and compatible Typical Applications • Automotive • Position sensing switch • Edge card reset switch • Smart card presence switch detector • DSL and fiber optic networks Specifications FUNCTION: Momentary, Normally closed. SWITCHING POWER MAX.: 0.2 W DC SWITCHING VOLTAGE MAX.: 24 V DC SWITCHING CURRENT MAX.: 50 mA DC OPERATING LIFE: 50,000 operations. CONTACT RESISTANCE: < 200 m Ω INSULATION RESISTANCE: > 109 Ω BOUNCE TIME: < 3 ms OPERATING TEMPERATURE: –40ºC to +85ºC TRAVEL TO BREAK: 0,3 (.01181) ± 0,1 (.00394) TOTAL TRAVEL: 1,2 (.047) ± 0,15 (.006) FORCE AT MAXIMUM TRAVEL: < 1.25N – STORAGE TEMPERATURE: –55ºC to +85ºC SOLDERABILITY: According to lead free soldering profiles. PACKAGING: Switches delivered on continuous tape & reels of 2000 pieces, 16mm width. Dimensions according to EIA RS-481 standard. NOTE: Specifications listed above are for switches with standard options. For information on specific and custom switches, consult Customer Service Center. Build-A-Switch To order, simply select desired option from each category and place in the appropriate box. Available options are shown and described on page F-10. For additional options not shown in catalog, consult our Customer Service Center. K SM 6 1 6 1 L F G Designation KSM Actuation 6 Standard Actuation Force 1 0.9N (90 grams) Contact Material 6 Gold plated Contact Arrangement 1 Normally closed F Detect RoHS compliant and compatible. Gold plated. Dimensions are shown: Inches (mm) Specifications and dimensions subject to change F–9 www.ittcannon.com KSM Series Side Actuated Detect Switches DESIGNATION KSM PAD LAYOUT .252 (6,4) TAPE & REEL F Detect Dimensions are shown: Inches (mm) Specifications and dimensions subject to change F–10 www.ittcannon.com
