M3-P4-S0-1-1010-1

Cm3TM Connector Series Features/Benefits applications • Maximum power / minimum size • Low profile design for space sensitive • Replaces conventional circular • • • • • connectors (50% less weight) Simple harnessing and fast installation Easy contact assembly without tool Only one housing for signal and power connectors Excellent vibration resistance 2 sealed entries for power and signal cable Typical Applications • • • • • Small servo motors Factory automation Material handling Industrial motion control Robotics Materials HOUSING: Zinc die cast, plating optional INSULATORS: PBT glass filled SEALING: FKM or alternative CRIMP SLEEVE: Brass CONTACT MATERIAL: Brass / beryllium copper gold plated Specifications Mechanical MATING CYCLES: min 50 MECHANICAL CODING: 3 coding for signal WEIGHT: approximate 170 g (without cable) Operating Environment OPERATING TEMPERATURE: -40˚C - 125˚C STORAGE TEMPERATURE: -40˚C -/+ 85˚C CLIMATIC CATEGORY: -40˚C / 125˚C/56 WATER TIGHTNESS: IP65 or IP67 NOTE: Specifications and materials subject to change. POWER CURRENT RATING AT 80˚C (176˚F) ambient temp: 12 A max MAXIMUM VOLTAGE: 630 VAC OVER VOLTAGE CATEGORY II: Test voltage 4.8 KV DIELECTRIC STRENGTH: 2.2 KV CONTACT RESISTANCE:
