COMPONENTS PRODUCT INFORMATION
USB Type-C® Compatible DX07 Series
Hybrid Contact Receptacle
CONNECTOR
MB-0335-5
December 2021
RoHS Compliant
On-board Type
Mid-mount Type
The DX07 Series connectors are USB Type-C® compliant, and they are a standard
interface for various devices, such as PCs, smartphones, audio-visual equipment, gaming
devices, and other hand-held devices.
This product is a through-hole, SMT hybrid contact receptacle which allows for reworking
of soldering area.
Note) USB Type-C®, USB-C® are trademarks of USB Implementers Forum.
Applicable Markets
PCs, tablets, HUBs, POS registers, portable gaming devices, and others
Features
Compliant with Universal Serial Bus Type-C Specification Release 2.1
Compatible with 10Gbps x2 (20Gbps) Super Speed communication. (USB 3.2)
Supports 240W (5A/48V) max. power supply.
(Compatible with USB Power Delivery Extended Power Range)
Lock structure with superior durability.
Remarks: Large selection of connector variations are available in DX07 Series
Please refer to the chart below for brochures of other variations.
Brochure Number
Brochure Name
MB-0297-*
DX07 SMT Contact Receptacle
MB-0333-*
DX07 Waterproof Receptacle
MB-0336-*
DX07 Vertical Receptacle
MB-0350-*
DX07 16-position Receptacle
MB-0362-*
DX07 USB4 Gen3 Compatible Receptacle
MB-0301-*
DX07 Plug Series
MB-0324-*
DX07 Harness
MB-0332-*
DX07 Vertical Plug
Note: The asterisk (*) stands for revision number.
JAE Connector Div. Proprietary. Copyright © 2021 Japan Aviation Electronics Industry, Ltd.
1/4
MB-0335-5
General Specifications
Number of
Contacts
24 Position
Contact
Resistance
40mΩ max. (initial)
Dielectric
Withstanding
Voltage
100Vrms / 1minute
Insulation
Resistance
100MΩ (initial)
Durability
10,000 times
Operating
Temperature
Range
-40˚C ~ +85˚C
VBUS(Terminal No. A4, A9, B4, B9) DC 5A (Total)
Rated
Current
GND(Terminal No. A1, A12, B1, B12) DC 6.25A(Total)
VCONN(Terminal No. B5) DC 1.25A
Others DC 0.25A / pin
Rated
Voltage
48Vrms
Ordering Information
DX07 * * 24 X * * R****
Series
DX07: USB Type C
S: On-board, B: Mid-mount
Modification Code #1
Reeled pcs. / reel
Modification Code #2
Plating Specification
J: Contact area: Au flash over Palladium
Ni over Ni plating
A: Contact area: Au over Ni plating
No. of Contacts: 24 positions
Board Connection Type
X: Hybrid Type
JAE Connector Div. Proprietary. Copyright © 2021, Japan Aviation Electronics Industry, Ltd.
2/4
MB-0335-5
Outer Dimensions
On-board
B
A
C
C/H
D
Unit: mm
Part Number
C/H
Dimension Dimension Dimension Dimension
A
B
C
D
Mating
Length
0.7
DX07S024XJ1
1.6
9.4
9.65
3.34
Shell
Plating
Note
Black
Nickel
--
5.5
Bracket
0.9
Contact
0.7
DX07S024XJ1A
2.0
DX07SA24XJ2
10.5
9.25
3.77
0.9
--
5.1
-Nickel
Flange
10.44
DX07S024XJ4
3.4
10.0
10.25
DX07S024XA8
Mid-mount
10.17
Body
5.17
Bracket
1.9
Contact
1.8
Screw
-hole
M2
4.7
5.17
--
B
A
C
C/H
D
Unit: mm
Part Number
DX07B024XJ1
C/H
0.7
Dimension Dimension Dimension Dimension
A
B
C
D
11.8
9.65
3.14
0.9
Mating
Length
Shell
Plating
Note
5.5
Black
Nickel
--
JAE Connector Div. Proprietary. Copyright © 2021, Japan Aviation Electronics Industry, Ltd.
3/4
MB-0335-5
Technical Documents
Part Number
Drawing
Number
Specifications
Handling
Instructions
Package Quantity
DX07B024XJ1
DX07B024XJ1R1300
SJ116121
SJ116122
1,300 pieces/reel
DX07S024XJ1
DX07S024XJ1R1100
SJ116123
SJ116124
1,100 pieces/reel
DX07S024XJ1A
DX07S024XJ1AR1000
SJ117695
SJ117696
DX07SA24XJ2
DX07SA24XJ2R1000
SJ116666
SJ116667
DX07S024XJ4
DX07S024XJ4R250
SJ119851
SJ119852
250 pieces/reel
DX07S024XA8
DX07S024XA8R700
SJ121226
SJ121227
700 pieces/reel
JACS-30361
JAHL-30361
1,000 pieces/reel
Note) Please order in reel units.
Notice:
1. The values specified in this brochure are only for reference. The products and their specifications are subject to change without notice.
Contact our sales staff for further information before considering or ordering any of our products.
For purchase, a product specification must be agreed upon.
2. Users are requested to provide protection circuits and redundancy circuits to ensure safety of the equipment, and sufficiently review the
suitability of JAE's products to the equipment.
3. The products presented in this brochure are designed for the uses recommended below.
We strongly suggest you contact our sales staff when considering use of any of the products in any other way than the recommended
applications or for a specific use that requires an extremely high reliability.
(1) Applications that require consultation:
(i) Please contact us if you are considering use involving a quality assurance program that you specify or that is peculiar to the industry,
such as:
Automotive electrical components, train control, telecommunications devices (mainline), traffic light control, electric power, combustion
control, fire prevention or security systems, disaster prevention equipment, etc.
(ii) We may separately give you our support with a quality assurance program that
you specify, when you think of a use such as :
Aviation or space equipment, submarine repeaters, nuclear power control systems, medical equipment for life support, etc.
(2) Recommended applications include:
Computers, office appliances, telecommunications devices (terminals, mobile units), measuring equipment, audiovisual equipment, home
electric appliances, factory automation equipment, etc.
* The specifications in this brochure are subject to change without notice. Please contact JAE for information.
JAE Connector Div. Proprietary. Copyright © 2021, Japan Aviation Electronics Industry, Ltd.
4/4
