ACTERNA TEST & MEASUREMENT SOLUTIONS RSAM-5600 Remote Service Analyzer Module Key Features • Remote, Web Browser interface - Saves time daily by eliminating driving to hubs and headends • Quick comparison of field to headend results - isolates network problems, determines the source of errors and reduces unnecessary truck rolls • Instant access to remote sites - speeds up analysis for headend and field technicians • Daily Digital Quick Check of system performance at the press of a button - ensures revenue stream by proactively testing and analyzing the VOD, HSD, and analog physical layer • Designed and priced to meet the needs of remote hub sites – can affordably be deployed in all remote hubs • Continuous monitoring with SNMP threshold alarming integrates with OSS and NMS - helps find and fix problems before customers complain With the rapid deployment of services such as VOD, high-speed data, and VoIP, daily system checks are often times overlooked. Additionally, with unmanned hubs and headends, problems in the field are often left unresolved or unnecessarily delayed while technicians try to determine the origin of the problem. Enter the JDSU RSAM-5600 Remote Service Analyzer Module — providing remote analysis of forward path digital and analog signals and specifically designed for deployment in remote, un-manned hub sites or headend locations. In conjunction with JDSU’s RAS-100 Remote Analysis Software, the RSAM-5600 provides remote analysis and views of channel performance to the field, headend, and NOC technicians using JDSU’s DSAM workforce automation (WFA) browser or any standard Internet browser. With the performance and price needs for deployment in multiple remote hub sites or headend locations the RSAM-5600 can eliminate technicians driving to various sites to verify the status and integrity of services. Better still network problems can be quickly resolved and closed with technicians focusing on deploying the new services — faster. The RSAM-5600 Remote Service Analyzer Module also complements the wealth of JDSU’s existing cable networks solutions with the SDA forward and reverse sweep, PathTrakTM Reverse Path Monitoring, and DTS MPEG analysis. WEBSITE : www.jdsu.com RSAM-5600 REMOTE SERVICE ANALYZER MODULE 2 More Efficient Technicians With the RSAM-5600, technicians can focus their efforts on the business priorities. JDSU’s RSAM-5600 allows technicians to quickly analyze unmanned hub and headend sites remotely. A quick check of the RSAM data can identify and locate the problem eliminating wasted time driving to remote sites to check system levels. Additionally, isolating network problems can easily be accomplished quickly from the field by providing technicians the ability to view the quality of the originating source. Solve Problems before they occur Proactively analyze multiple downstream channels from your PC identifying potential problems BEFORE they happen ensuring customer satisfaction and keeping your revenue streams flowing. Quickly test and report systems performance against multiple limits sets for predictive analysis. The RSAM-5600 will monitor system performance and trigger SNMP events upon critical threshold violations. SNMP event notification from the RSAM can even be integrated into your existing OSS or NMS systems. Technicians can then remotely diagnose the problem from their web browser or be dispatched to correct a potential failure. Whether you use the DSAM Browser or a standard Internet web browser, instant access to the RSAM data and proactive analysis ensures a higher level of customer service. The ability to view originating source quality in the field increases your time to resolution and increases your customer satisfaction. Clients are simply web browsers which point to the RAS-100 - Remote Analysis Software RSAM-5600 SNMP events are at the unit level and do not pass through the server Coax Distribution Network Fiber Node Primary Fiber Ring Ethernet Hub Server Ethernet DSAMs can have their browser configured to access the RAS-100 Remote Analysis Software or can be directed there by the IAS-100 Hub Fiber Distribution RAS-100 - Remote Analysis Software resides on a customer supplied PC Ethernet PC Hub RSAM-5600 Up to 100 RSAM-5600 units can be managed by a single RAS-100 Remote Analysis Software RSAM-5600 DSAM-2500 PC Figure 1: Typical instalation RSAM-5600 REMOTE SERVICE ANALYZER MODULE 3 Integrated solution The RSAM is configured using the JDSU FDM-100 Field Data Management software. Easily set-up, maintain and update channel plans and limits. The FDM-100 interface is common between DSAM field meters and the RSAM-5600 and even provides asset management of your RSAM-5600 deployments. Accessing RSAM measurement is accomplished via the RAS-100 Remote Analysis Software. The RAS-100 provides a browser compatible interface via a web server which services measurement requests to individual RSAM units. There are no clients to purchase or install in your system. View the results 24/7 from anywhere—including over an RF network on the DSAM. The RAS-100 Remote Analysis Software responds to requests and formats the web page appropriately for the DSAM WFA web browser or a standard Internet web browser. On Demand Reporting Full Scan From a PC web browser, a technician can quickly analyze system levels using the Full Scan report. This report graphically depicts the analog video levels and average digital power levels across the channel lineup. The user can then quickly compare the levels to the 4 different thresholds to determine the systems health. From the field, a user equipped with a DSAM with the WFA Browser option can also remotely view the full scan. Ethernet PC Hub RSAM-5600 Primary Fiber Ring Hub Hub Remote view of Scan Graph on PC Internet Browser Coax Distribution Network DSAM-2500 Figure 2: Remote service analysis Remote view of Scan Graph on a DSAM RSAM-5600 REMOTE SERVICE ANALYZER MODULE 4 Test All Channels Eliminate driving to remote hubsites to perform system checks. With the all channels report, detailed analysis of system performance is just one mouse click away. The All Channels Report provides channel by channel details including Video level, Audio Level, delta V/A, digital power level, MER, and compares the results against four user defined limit sets. The reports are presented in a tabular format that can then be printed for recording the remote systems performance. Single Channel In depth analysis and detailed troubleshooting of individual channels with the Single Channel Report provides measurement results on a per channel basis. Identify performance issues on digital channels such as average power level, MER, and BER. The user interface provides quick graphical feedback of the pass/fail status of the test. Access to single channel test is also available in the field using the DSAM WFABrowser option allowing field technicians to determine if the problem is from the source or caused by network conditions without calling a headend technician. Performance Monitoring and SNMP Events The RSAM-5600 will be continuously performing the All Channels Test in the background regardless of a users request. While performing the test, the RSAM will compare the measurements against the “critical” limit set. Using SNMP traps, the RSAM will send notification of events when measurements violate the limit thresholds. The SNMP events are generated at the RSAM and can be filtered and consolidated using an OSS or network management system. Single Channel Report of a digital channel All Channels Report of analog channels Custom build hierarchies to fit your network On Demand Report from remote sites RSAM-5600 REMOTE SERVICE ANALYZER MODULE 5 Specifications (preliminary) Frequency Range Accuracy Tuning resolution 4 to 1,000 MHz ±10 ppm at 77°F (25°C) Analog 10 KHz Digital 50 KHz Channel bandwidth RSAM-5600A 8 MHz RSAM-5600B 6 MHz Level measurement, analog Signal types CW, video and audio (NTSC, PAL, and SECAM) Range –40 to +60 dBmV(1) Resolution 0.1 dB Resolution bandwidth 330 KHz Accuracy(2) ±1.5 dB typical @ 25°C Level measurement, digital Modulation types QPSK, QAM (DVB/ACTS) Range –40 to +60 dBmV(1) Resolution 0.1 dB Resolution bandwidth 330 kHz Accuracy(2) ±2.0 dB typical @ 25°C Downstream QAM demodulation Modulation type 64 and 256 QAM, ITU-T J.83 Annex A, B or C (selectable) Input range (lock range) –15 to +50 dBmV total integrated power(3) from 55 to 1000 MHz BER(4) Pre- and Post-FEC 10-4 to 10-9 MER(4) EVM(4) Range 64 QAM: 21 to 35 dB Accuracy ±2 dB (typical) Range 256 QAM: 28 to 35 dB Accuracy ±2 dB (typical) Range 64 QAM: 1.2% to 5.8% Accuracy ±0.5% (1.2% to 2.0%) ±1.0% (2.1% to 4.0%) ±1.4% (4.1% to 5.8%) Range 256 QAM: 1.1% to 2.4% Accuracy ±0.6% General Dimensions 19 x 13.5 x 3.5 in ( 48.3 x 34.3 x 8.9 cm) Weight 7 lb 7 oz (3.4 kg) Operating temperature range 32 to 120°F; 0 to +50°C Storage temperature range 0 to 120°F; -20 to +50°C Power supply input 47-63 Hz, ~110VA, 100-265 VAC (1) Typical, detectable range (2) Accuracy for levels between –20 to 60 dBmV Additional uncertainty ±0.5 dB across –20°C to 50°C Additional uncertainty ±1.0 dB from 4 MHz to 15 MHz (3) At 64 QAM (4) Accuracy and behavior from 100 MHz to 1000 MHz for levels between –5 to 50 dBmV (typical) Symbol rate Annex A, 5.057 to 6.952 Msps for 64 and 256 QAM Annex B, 5.057 Msps for 64 QAM and 5.361 Msps for 256 QAM Annex C, 5.274 Msps for 64 QAM and 5.361 Msps for 256 QAM Standards compliance Shock and vibration IEC 60068 Drop IEC 61010 Handle stress IEC 61010 Safety – emissions EN 55022 Safety – immunity EN 61000 Interfaces RF 75 ohm, F81 or BNC option Max. sustained voltage 100 VAC, 140 VDC RS232 Standard via DB9 Ethernet RJ45, 10 base T,TCP/IP and UDP supported AUX TTL compatible output for controlling accessories Hub Fiber Node Primary Fiber Ring Hub Fiber Distribution Head End Hub Coax Distribution Network HFC Network DTS-200 MPEG Test System SELECT ENTER Drop & Home Wiring DTS SDA PathTrak RSAM-5600 Headend and Performance Monitoring Reverse Path - PathTrak MPEG - DTS Series Forward Path - RSAM-5600 Figure 3: RSAM - Complements the cable solution DSAM CLI Cable System Construction and Maintenance SDA-5000 SDA-4040D StealthWare Drop/Home Installation and Service DSAM-2500/-1500 MS-1200D/-1300D/-1400 CLI-1450/-1750 & HWTK RSAM-5600 REMOTE SERVICE ANALYZER MODULE Ordering Info Models RSAM-5600A RSAM-5600B RAS-100 Part number 1010-00-0892 1010-00-0893 1010-00-0891 Description Remote Service Analyzer Module, 4 to 1000 MHz, 8 MHz channel spacing Remote Service Analyzer Module, 4 to 1000 MHz, 6 MHz channel spacing JDSU RAS-100 Remote Analysis Software, PC Based Web Server for controlling and viewing Remote RSAM-5600 measurements. Includes one copy of FDM-100 for configuring and managing RSAM’s One License controls up to 100 RSAM-5600 units. Substitute 75-ohm BNC connection IAS-100 Instrument Application Software, a TechSync solution. Works in conjunction with the DSAM WFA browser option. Optional BNC-connection IAS-100 1019-00-1455 1010-00-0878 All statements, technical information and recommendations related to the products herein are based upon information believed to be reliable or accurate. However, the accuracy or completeness thereof is not guaranteed, and no responsibility is assumed for any inaccuracies. The user assumes all risks and liability whatsoever in connection with the use of a product or its application. JDSU reserves the right to change at any time without notice the design, specifications, function, fit or form of its products described herein, including withdrawal at any time of a product offered for sale herein. JDSU makes no representations that the products herein are free from any intellectual property claims of others. Please contact JDSU for more information. JDSU and the JDSU logo are trademarks of JDS Uniphase Corporation. Other trademarks are the property of their respective holders. ©2005 JDS Uniphase Corporation. All rights reserved. 10143166 500 0905 RSAM5600.DS.CAB.TM.AE Test & Measurement Regional Sales N ORTH AMERICA TEL : 1 866 228 3762 FAX : +1 301 353 9216 LATIN AMERICA TEL : +55 11 5503 3800 FAX : +55 11 5505 1598 ASIA PACIFIC TEL : +852 2892 0990 FAX : +852 2892 0770 EMEA TEL : +49 7121 86 2222 FAX : +49 7121 86 1222 WEBSITE : www.jdsu.com
