COMMUNICATIONS TEST & MEASUREMENT SOLUTIONS SDA-4040D Stealth Digital Analyzer Key Features • Offers unmatched measurement performance in a single instrument • Enables easy preparation of networks for interactive services with a 5 to 1000-MHz fast, sensitive spectrum analyzer • Provides zero span measurement of power and carrier-tonoise ratios • Enables analysis and quality measurements of digital TV and cable modem signals with optional QAM analysis • Ensures full in-service proof of performance with automated tests • Reduces testing and troubleshooting times for network analysis and qualification • Rugged, weather-resistant, and lightweight With today’s varied networks, a solution that can handle cable modems, digital TV and maintain the analog spectrum is essential. Putting that solution into a single, rugged instrument will enable technicians to use it in the most demanding of situations, whenever it is needed. The JDSU SDA-4040D Stealth Digital Analyzer is just such a solution. Detecting and eliminating return path noise is accomplished with a fast spectrum analyzer (detects signals down to a 5 µs duration), and the industry-unique JDSU PathTrak™ Field View option. A zero span spectrum provides accurate, in-service power and carrier-to-noise measurements of cable modems. The new QAM View digital analysis option adds forward path digital signal testing that includes constellation, pre/post FEC BER, MER, and an exclusive QAM ingress feature that reveals noise under an active carrier. Of course, analog signal measurements are addressed with standard features like RF level, fast-scan, tilt, inservice C/N and HUM, and FCC and CENELEC compliant autotesting. The SDA-4040D is an ideal solution for any network. Priced competitively to ensure that on-site technicians are fully equipped with the equipment they need, the SDA-4040D will ensure rapid and accurate analysis of network turn-up or inservice testing for fastest return on revenue. WEBSITE : www.jdsu.com/test SDA-4040D STEALTH DIGITAL ANALYZER 2 The Spectrum mode has the speed and versatility to effectively troubleshoot difficult system problems JDSU single-instrument solutions Constellation display with MER and pre/post FEC BER The SDA-4040D Stealth Digital Analyzer delivers a single-instrument, “One-Box” solution to help deploy and maintain quality video and data services in the HFC network. With the same durability and measurement accuracy as its proven SAM predecessor, the SDA-4040D is designed with the speed, spectrum, and advanced QAM analysis to test both traditional analog video and the latest digital formats. The versatile combination of standard features and available options enables the meter to be customized, or upgraded to the SDA-5000, to meet virtually any system requirements. Analog testing – Nonintrusive Sweepless Sweep – RF level, fast scan, tilt – In-service carrier-to-noise, hum, depth of modulation – Fast spectrum display with CTB/CSO – Automatic/24-hour testing (FCC and CENELEC compliant) QAM ingress feature shows noise/ingress under an active carrier Return path testing – PathTrak Field View option pinpoints return path noise – Zero-Span Spectrum mode – DOCSIS/DAVIC-compatible cable modem analysis Advanced digital testing – digiCheck average power – QAM View digital analysis option with modulation error ratio (MER), pre/post FEC BER, constellation, and exclusive noise/ingress under the carrier measurement Preparing the network for digital services Single button, in-service C/N measurements on TDMA return path cable modem signals (DOCSIS, EuroDOCSIS, EuroModem) For measurement and analysis of digital TV and forward modem signals, the new QAM View option provides a full complement of digital quality measurements. Included is a 64/256 QAM constellation display with zoom, average digital power level, bit error rate (BER), 21 to 35 dB modulation error ratio (MER) and noise margin “cliff effect” parameter. An equalizer display shows equalizer stress and distance to fault. In addition, an exclusive QAM Ingress Noise mode enables technicians to see ingress/noise under an active digital carrier. This tool is invaluable for detecting forward path ingress otherwise hidden by conventional spectrum views. Zero span/time domain expert mode, showing the TDMA bursty return path cable modem power ramp of 3.5 ms SDA-4040D STEALTH DIGITAL ANALYZER 3 In-service cable modem analyzer For bursty digital signals such as TDMA technologies used on cable modems for reverse services, the SDA-4040D offers two choices. The first is a one-button cable modem analyzer and the second uses advanced zero span capabilities to make the measurement. The one-button cable modem analyzer quickly shows carrier-tonoise measurements, while the zero span option utilizes a time domain display to enable power measurements while the modem is in service. Both methods are compatible with global cable modem standards. Making accurate digital average power measurements is addressed with the digiCheck measurement function. The digiCheck feature is compatible with most non-bursty digital modulations in use today (that is, 16, 32, 64, and 256 QAM, QPR, QPSK, VSB, and CAP16). Analog and digital signal limits Reverse digital modem signal PathTrak Field View option compares headend node spectrum with field testpoint spectrum Analog signal threshold limits have always been a technician’s favorite feature of JDSU instruments. Automatic limit checks provide a quick go/no-go status for audio and video levels. The SDA Series extends this capability with a dedicated digital limit set that can be applied exclusively to the forward digital carriers defined in a channel plan. By assigning separate analog and digital limits, test time is reduced, since no calculation is necessary to determine if analog and digital level relationships are within system specifications. Analog and digital limit capabilities are available in both the Scan and Autotest modes. Tilt measurement Tilt is the easiest and most efficient tool for balancing amplifiers. For cable plants requiring multiple tilt measurements, such as comparing today’s tilt measurement with a historical record, and then making an additional measurement for a new wider channel plan, the technician simply uses markers to indicate the tilt channels that define the new limits. Intermodulation distortion Sweepless Sweep display Intermodulation distortion (CSO/CTB) can be automatically measured using the CTB/CSO mode from the spectrum analyzer. CTB/CSO distortions produced by intermodulation of analog TV carriers can degrade the signal quality of QAM modulated signals used by digital video and cable modems. Scan measurement Scan mode provides a quick graphical view of the entire channel plan with bars representing the video level for each channel. Both video and audio may be displayed. Carrier-to-noise measurement: in-service Carrier-to-noise measurement (on non-scrambled channels) is just as easy, and there is no need to remove modulation from the video carrier. No tunable preselector filter is needed. Graphical reverse testpoint compensation SDA-4040D STEALTH DIGITAL ANALYZER 4 Hum measurement: in-service Measuring hum on a channel (non-scrambled) is as simple as pressing the “HUM” key and since the instrument is battery powered, the measurement is independent of ground loops, therefore isolated from the line (mains). Hum reveals itself as either single (60 Hz) or double (120 Hz) horizontal bars across the video screen. The level of either can be measured. Modulation measurement The Navigator user interface, common on all JDSU SDA meters Includes NTSC, PAL, and SECAM formats. Demodulation of the audio is done for both AM and FM. FM is used to hear audio distortion on the FM radio channels or the sound of the TV program. AM is used to recognize short-wave interference signals in the reverse band. Extensive automated test capability Automated tests can be scheduled to perform either 24-hour FCC compliance tests, or initiated immediately to log performance at individual nodes, amplifiers or other testpoints. A wide range of tests can be performed automatically, including signal levels, C/N, hum and depth of modulation. The operator designates which tests to perform on which channels. Because these tests are nonintrusive, it is easy to test all parameters on all channels at any time. The single-channel level display shows both video and audio levels (either single or dual sound/NICAM) and the difference between the two After a test is performed, the results can be displayed on the SDA screen. A pass/fail indication can be set on a variety of limits for FCC/CENELEC or other government standards, or to system preferences. Data taken during any automated test, or sequence of automated tests, can be viewed immediately with a pass/fail indication for each of the limits. Specific stored measurement results may be viewed on demand. Automated test results can be printed directly to a serial printer or uploaded to a PC using StealthWare to store and include in custom reports. Data analysis with StealthWare Digital channel average power measurements can be made using the digiCheck™ feature Any stored SDA measurement information can be uploaded to a PC using StealthWare, a Microsoft® Windows®-based data management package. Stored sweep, scan, or spectrum screens can be viewed on the PC and analyzed with marker movement and readout information in just the same way as on the actual instrument. A sweep graph overlay function enables comparison of multiple RF response variations over time. StealthWare also allows the operator to build channel plans and edit site locations, which can be downloaded to multiple SDA instruments. Additionally, channel plans can be uploaded to the PC, modified in StealthWare, and then downloaded back to the SDA instrument. Upgrading the SDA-4040D to the SDA-5000 Tilt mode performs automatic tilt calculations between any two of nine designated carriers The JDSU upgrade program is designed to protect customers’ investment in test equipment. As system requirements change, the SDA-4040D can be upgraded to the SDA-5000 for forward and reverse sweep capabilities at any of JDSU worldwide service centers, and model SAM-4040D owners can upgrade to the SDA-4040D with an in-the-field firmware change only. SDA-4040D STEALTH DIGITAL ANALYZER 5 JDSU Basic Service packages To ensure the highest levels of support for SDA purchasers, JDSU offers the Basic Service for instrument package. Designed to provide the foundation for maximizing the features and usage of SDA equipment, JDSU’s Basic Service package offers the following degrees of service and support only JDSU can provide. This includes: – An extended warranty of up to five years – Annual calibration fully traceableto meet NIST standards Limit checks can be instantly viewed after identifying channel of interest with a marker in Scan mode display These core services provide the foundation for a longer product life, help you realize greater meter functionality and maximize your JDSU investment. Ask your sales representative or call the JDSU Customer Care Center for more information. Technology training JDSU provides a comprehensive Cable Networks technology training program designed to help you and your teams understand the changing needs of today’s advanced networks. Training seminars include: – HFC basics – Sweep and balance forward and return – Sweep 101 “Bootcamp” In-service carrier-to-noise In-service “HUM” (PAL and NTSC compatible) Depth of modulation The detailed scan graph offers user-adjustable marker, scale reference level and tilt for maximum signal evaluation SDA-4040D STEALTH DIGITAL ANALYZER 6 Specifications Start with any SAM-4040 or 4040D Optional: PathTrak Field View (4040D) A) Firmware B) Hardware & firmware SAM-4040D SAM-4040 General Display 320 x 240 dot matrix LCD, selectable back light Dimensions 6 x 11 x 3.5 in (15.2 x 27.9 x 8.9 cm) Weight 5.1 lb (2.3 kg) Temperature range operating –4 to 117°F (–20 to +47°C) Depth of modulation Assumes presence of white reference on any VITS line. Nonscrambled channels only. Audio demodulation of AM and FM carriers Range 80 to 100% Resolution < 0.5% at 85% Audio demodulation AM and FM carriers A or B Upgrade to SDA-4040D Standard: Optional: DigiCheck PathTrak ZeroSpan Field View Dig Spectrum Add Option 4 for: QAM View Any Stealth can upgrade to SDA-5000 for: 5 x faster sweep 256 QAM compatible sweep Improved TP Comp setup for reverse sweep A) Firmware B) Hardware & firmware SDA-5000 units can be purchased with,or upgraded to: QAM View PathTrak Field View SSA-1000 Power sources SDA-4040D Battery Extended-life replaceable nickel metal hydride, 12V/3.5A-hr 4 hours cont. use on a single charge Tilt measurement Up to nine pilot carriers or video channels with tilt and level measurements on the highest and lowest. Hi-Lo ∆ Resolution 0.1dB Frequency QAM view option 3SR Range Accuracy Resolution bandwidths A or B Tuning resolutions Sweep resolution SDA-5000 5 to 1,000 MHz ±10 ppm at 25°C; ±10 ppm drift over temperature; ±3 ppm/year aging 30, 280 kHz and 2MHz (30 kHz for CTB/CSO only) 10 kHz 250 kHz maximum Scan mode All video, audio, pilot carrier, and digital channel levels displayed. Sweepless Sweep mode Frequency range Display span Display scale/range 5-1000 MHz User definable 6 vertical divisions 1, 2, 5, or 10 dB/division Sweep pulse occupied bandwidth 30 kHz Stability ±0.5 dB, normalized (dependent on stability of referenced carriers) Sweep rate ~1 second (78 Channels, including scrambled and digital signal types) Channel plan templates (user editable) China-1; China-2; France; HDTP-NL; Ireland; Japan; Jerold; Jerold-HRC; Jerold-IRC; NCTA; NCTA-HRC; NCTA-SUB; NCTA-IRC; NTSC-Broadcast; OIRT-D/K; PL-B/G; PAL-UK Level measurement Range Resolution Accuracy Log linearity Flatness Signal types –40 to +60 dBmV 0.1 dB ±1.0 dB from –20 to +50°C(1,2) ±0.5 dB(1) ±0.5 dB(3) CW, single carrier, video (single or dual audio/NICAM), audio, digital Uncertainty for digital carrier additional ±0.5 dB (digital types 16/32/64/256) QAM, QPR, QPSK,VSB, CAP-16, DVB/ACTS and TDMA using Zero Span Spectrum mode) at 280 kHz RBW QAM view option Any 3ST can be upgraded to SDA-5000 for faster forward sweep and digital signal sweep compatibility Any 3HRV can be upgraded to SDA-5510 3ST 3HRV SDA-5500 SDA-5510 Stealth to SDA series – product upgrade/replacement guide Stealth model 3SR 3SR + 3SRV option 3SR + 3SRT option 3ST 3HRV SSA-1000 SAM 4040 SAM-4040D SDA replacement SDA-5000 SDA-5000 with Option 1 SDA-5000 with Option 2 SDA-5500 SDA-5510 SDA-5000 with Option 2 (firmware only) SDA-4040D SDA-4040D (firmware only) Spectrum mode Spans 3, 5, 10, 20, and 50 MHz (0.3, 0.5, 1, 2, and 5 MHz/div.) Sweep rates ~1 second updates with spans of 50, 20, 10 and 5 MHz ~1.7 second updates with 3 MHz span Display scaling and range 0.5, 1, 2, 5, and 10 dB/div. 6 vertical divisions Dwell programmable 0-25 ms Spurious free dynamic range 60 dB(3) Sensitivity without preamp –40 dBmV 5 to 550 MHz –35 dBmV 550 to 1000 MHz Sensitivity with preamp –50 dBmV 5 to 550 MHz –45 dBmV 550 to 1000 MHz Max. level with preamp +50 dBmV Carrier-to-noise(4) In-service measurement. Non-scrambled channels only. No preselection required for 78 channels or less. Best dynamic range at +10 dBmV or higher input. Range ≥ 52 dB(1) Resolution < 0.5 dB Hum measurement In-service measurement. Carrier > 0 dBmV. Non-scrambled channels only Range 0 to 10% Resolution < 0.2% Accuracy ±0.7% SDA-4040D STEALTH DIGITAL ANALYZER 7 Specifications continued Zero Span mode Video BW >1 MHz, 100 kHz, 10 kHz, 100 Hz Resolution BW 2 MHz, 280 kHz, 30 kHz Measurement BW Compensation programmable 1 kHz to 99 MHz Pulse measurement accuracy nominal level in 10 µs ±2 dB from nominal in 5 µs (>1 MHz VBW, 280 kHz RBW) Sweep times 100 µs to 20 s (1, 2, 5 settings) View option (OPT 4) The QAM View option can be factory installed in any new or existing SDA Series instrument.The specifications and features are in addition to the standard measurement features of the SDA Series.When ordering, please specify OPT 4A for 8MHz, DVB-C, ITU-T J.83 Annex A, or OPT 4B for 6MHz, DVS-031, ITU-T J.83 Annex B. Modulation type 64/256 QAM, DVB-C, ITU-T J.83 Annex A (OPT 4A) 64/256 QAM, DVS-031, ITU-T J.83 Annex B (OPT 4B) Channel bandwidth 8 MHz (OPT 4A); 6 MHz (OPT 4B) Measurable input range (lock range) 64 QAM –20 to +50 dBmV (typical) 256 QAM –15 to +50 dBmV (typical) Frequency tuning 50 to 860 MHz (Digital QAM mode) Resolution 50 kHz BER (bit error rate) 64 QAM Pre-FEC/OPTs 4A and 4B 10–4 to 10–9 64 QAM Post-FEC/OPTs 4A and 4B 10–4 to 10–9 256 QAM Pre-FEC/OPT 4A and 4B 10–4 to 10–9 256 QAM Post-FEC/OPT 4A and 4B 10–4 to 10–9 MER (modulation error ratio) 64 QAM/Option 4A 22 to 35 dB Accuracy ±2.0 dB (typical, see chart below) 64 QAM/Option 4B 21 to 35 dB Accuracy ±1.5 dB 256 QAM/Option 4A 28 to 35 dB Accuracy ±2.0 dB (typical, see chart below) 256 QAM/Option 4B 28 to 35 dB Accuracy ±1.5 dB EVM (error vector magnitude) 64 QAM/Option 4A 1.2% to 5.2% Accuracy ±0.5% (1.2% to 2.0%) ±1.0% (2.1% to 4.0%) ±1.4% (4.1% to 5.2%) 64 QAM/Option 4B 1.2% to 5.8% Accuracy ±0.5% (1.2% to 2.5%) ±1.1% (2.6% to 5.8%) 256 QAM/Option 4A 1.1% to 2.5% Accuracy ±0.6% 256 QAM/Option 4B 1.1% to 2.5% Accuracy ±0.5% QAM level measurement Signal types 64 QAM, 256 QAM Range –20 to +45 dBmV Accuracy ±1.0 dB Flatness ±0.5 dB Linearity ±1.0 dB Temperature ±0.5 dB (typical) Intermodulation distortion (CSO/CTB) Range(5) Resolution ≥ 60 dB 0.1 dB Data storage Files types that can be stored: Sweepless Sweep, autotests, tilt graphs, channel plans, and scan graphs. Spectrum graphs (normal, normal with max hold, and CSO/CTB) can also be stored. Memory space is allocated on demand. All files stored as data, not as screen picture.Typical mix of files for 78channel plan, 8 channel plans; 16 sweep references, 80 sweep traces; 40 scan files, 20 spectrum displays; 20 autotests Serial interface RS232; Epson, IBM, Seiko, and Diconix printers Measurable QAM ingress 64 QAM –25 to –40 dBc 256 QAM –30 to –40 dBc Accuracy ±3.0 dB Graphic display Digital summary (including MER/EVM, Pre/Post FEC BER, Equalizer Stress, Carrier Offset, Symbol Rate) with limit/margin test results, QAM level. IQ constellation with zoom. Adaptive Equalizer Display (8 feed forward/24 feedback), Frequency Response, Group Delay. Ingress/Noise Under the Carrier. Power source Note: Option powered from SDA Series nickel metal hydride battery. Operating time is specified for continuous use in QAM View mode. Option includes high output charger. Charge time ~4 hours Operating time 2.5 hours continuous use (typical) Universal AC charger/adapter Input 100-250 VAC, 50-60 Hz, 0.5 A Output Charge 15 V at 750 ma Physical dimensions (total SDA-5000 size with OPT 4) 6 x 10.5 x 4.25 in (15.2 x 26.7 x 10.8 cm) Weight Approx. 7.7 lb (3.5 kg) Operating temperature range –4 to 113°F (–20 to 45°C) Notes (1)Typical specifications (2)Relative to 25°C (3)At 25°C and +20 dBmV (4) 60 Rango de límites de medida 50 racy Accu 40 3 dB 2.0 dB Accuracy 30 Rango Portadora a Ruido (dB) 20 10 0 –10 (5) Profundidad de Medida(dB) (sin preamplificación/con preselector) 60 50 40 30 20 10 0 –20 –10 0 10 20 30 Nivel portadora de video (dBmV) B 3d Input configuration 75 Ω Type F Female (Optional 75 Ω Type BNC Female) Maximum sustained voltage 100 VAC, 140 VDC Connector type PathTrak field view (OPT 3 required) Update rate Display scaling Selectable nodes 2x/second (remote trace) ~1x/second (local trace) 5/1/2/5/10/20dB/div. 14 (selectable via PathTrak HCU) 0 10 14 Nivel portadora de video (dBmV) 24 Rango de límites de medida ura cy Acc 2.0 dB Accuracy SDA-4040D STEALTH DIGITAL ANALYZER 8 Specifications continued MER Accuracy Worse case condition, 64 QAM, Annex A, 6.89 MSPS 36 34 MER Actual (dB) 32 30 28 26 24 22 20 20 22 24 26 28 30 32 MER Reading (DB) 34 36 38 Upper limit Lower limit Ordering information Model SDA-4040D 1010-00-0471 Digital/Analog HFC Analyzer Includes: Extended-life nickel metal hydride battery, universal charger/AC adapter, canvas carrying case and operator’s manual. Options 1019-00-1290 SDA-OPT3A PathTrak Field View interoperation for model SDA-4040D (requires PathTrak HCU) QAM View SDA-OPT4A/B QAM View digital analysis including 64/256 Constellation, MER, Pre/Post FEC BER, and exclusive QAM ingress under the carrier feature. Please specify OPT version 4A or 4B when Ordering (see below part numbers) 1019-00-1287 SDA-OPT4A 64/256 QAM, DVB-C, ITU-T J.83 Annex A (8 MHz) 1019-00-1288 SDA-OPT4B 64/256 QAM, DVS-031, ITU-T J.83 Annex B (6 MHz) 1019-00-1288 SDA-OPT5 BNC connectors replace standard F type connectors 1010-00-0340 StealthWare Windows™-compatible data management software for all SDA, Stealth, MicroStealth, and CLI products SDA-4040D QAM Pack SDA 4040D Stealth Digital Analyzer Package including QAM View Option SDA-OPT4/B 1013-00-0006 SDA 4040D with SDA-OPT4A (8MHz) 1013-00-0005 SDA 4040D with SDA-OPT4B (6MHz) Optional accessories 1019-00-1298 SDA-CASE1 Replacement soft carrying case for all SDA instruments without QAM View option installed. Compatible with standard and extended life batteries 1019-00-1369 SDA-QAMCASE Replacement soft carrying case for all SDA instruments with QAM View option installed 1019-00-1190 SDA-NIMH Spare extended life battery 1019-00-1195 SDA-NIMCA Universal charger/AC adapter for extended-life nickel metal hydride battery 1012-00-0057 SDA-NIMK Extended life battery kit. Includes extended life battery, universal charger/AC adapter, and soft carrying case (SDA-CASE1) (for upgrading units without QAM View Option) 1019-00-1329 CBC-2 In-vehicle charger for SDA NiMH extended life battery only utilizing standard 12V DC automotive accessory port All statements, technical information and recommendations related to the products herein are based upon information believed to be reliable or accurate. However, the accuracy or completeness thereof is not guaranteed, and no responsibility is assumed for any inaccuracies. The user assumes all risks and liability whatsoever in connection with the use of a product or its application. JDSU reserves the right to change at any time without notice the design, specifications, function, fit or form of its products described herein, including withdrawal at any time of a product offered for sale herein. JDSU makes no representations that the products herein are free from any intellectual property claims of others. Please contact JDSU for more information. JDSU and the JDSU logo are trademarks of JDS Uniphase Corporation. Other trademarks are the property of their respective holders. ©2007 JDS Uniphase Corporation. All rights reserved. 30137235 501 0707 SDA4040D.DS.CAB.TM.AE Test & Measurement Regional Sales N ORTH AMERICA TEL : 1 866 228 3762 FAX : +1 301 353 9216 LATIN AMERICA TEL : +55 11 5503 3800 FAX : +55 11 5505 1598 ASIA PACIFIC TEL : +852 2892 0990 FAX : +852 2892 0770 EMEA TEL : +49 7121 86 2222 FAX : +49 7121 86 1222 www.jdsu.com/test
