TS-10

COMMUNICATIONS TEST & MEASUREMENT SOLUTIONS TestPoint with Fibre Channel TS-10 10Gbps TS-10 1Gbps V2 The TestPoint integrated solution: Fibre Channel, Ethernet, SONET/SDH/OTN 10 Gbps module 1 Gbps V2 module Features – Fibre Channel features covering 1G/2G/4G/8G/10GFC and 11.270G/11.317G (OTN for 10GFC) – Built-in RFC 2544 test support – Buffer-to-buffer credit settings between 1 and 4095 (implicit login) including R_RDY support The JDSU TestPoint Fibre Channel offering provides a comprehensive Fibre Channel test solution for transport applications in verification labs, production and service provider environments (lab and field). TestPoint provides traffic generation, analysis, and impairment testing at multiple line rates. – PRBS testing at FC-1 and FC-2 level – Capture features: 8B/10B for 1G/2G/4G/8GFC; 64B/66B for 10GFC – Stressed Receiver Sensitivity (SRS), also called stressed eye, feature for 10GFC (and 10GigE) – User-friendly GUI and simple automation Note: TestPoint hardware is available in modules (TS-30/170) or configurations (TS-10). The term module is used in the text. Evolution TestPoint currently supports 1G/2G/4GFC on the 1Gbps V2 module, 8GFC/10GFC/11.270G /11.317G (OTN with 10GFC client) on the 10 Gbps module, and 1G/2GFC on the multi-rate module. Stressed Receiver Sensitivity testing per IEEE 802.3 is also available for 10GFC (and 10GigE) module. www.jdsu.com/test TestPoint with Fibre Channel A Complete feature set for Fibre Channel Transport Key TestPoint Fibre Channel features include: Traffic Generation Frame Payload Frame Size Flow Control Performance Measurements RFC 2544 Captures and Triggers Link Initialization PCS Injections & Reporting Test Patterns IEEE 802.3 Test Patterns Clock Rate Variations Automated Test Reports At FC-1 or FC-2 (header, CRC) level; Class 3 PRBS31; PRBS23; PRBS15 (10Gbps only); User 16-byte Sequence 12 (when running at FC-1) to 4104 Bytes Buffer-to-Buffer Credit range 1 to 4095 (can be enabled/disabled) Latency; Packet Jitter; Sequencing (loss, out-of-sequence, duplicate) Throughput; Latency; Frame Loss Rate; Back-to-Back Frames 8B/10B for 1G/2G/4G/8GFC; 64B/66B for 10GFC Reporting of Active State or error condition 8B/10B for 1G/2G/4G/8GFC; 64B/66B for 10GFC CJTPAT, CRPAT, CJPAT for 1G/2G/4GFC, JSPAT for 8GFC Pseudo-Random, Square Wave, PRBS31 for 10GFC +/-110 ppm Statistics & Errors (testreport.txt); Event Log (log.csv); RFC 2544 On the 10 Gbps module, TestPoint supports an RFC 2544 test suite across two ports within the same TS-30/170 chassis when equipped with a Group Controller module. An integrated solution The TestPoint solution not only integrates multiple Fibre Channel rates but also provides support for Ethernet and SONET/SDH/OTN. Here is a breakdown for hardware supporting Fibre Channel: 10Gbps 1Gbps V2 Multi-rate 8GFC, 10GFC; 11.270G; 10GigE LAN; 10GigE WAN/SONET/SDH (STS-192c/VC-4-64c); OTU2; ODU2; 11.049G; 11.095G 1GFC; 2GFC; 4GFC; 1000BASE-X; 100BASE-FX; 10/100/1000BASE-T 1GFC; 2GFC; OC-3/STM-1 ; OC-12/STM-4 ; OC-48/STM-16; OTU1; ODU1; 1000BASE-X; 100BASE-FX; 10/100/1000BASE-T Additional software features are available, including GFP on the 10Gbps module. TestPoint is available in three chassis formats: the compact TS-10, 3-slot TS-30, and 17-slot TS-170. Fibre Channel Specific Ordering Information Modules (TS-30/170) N530-0163 10 Gbps module –XFP Version OPT 0160-05 10GFC OPT 0163-41 8GFC for 10 Gbps module OPT 0160-03 G.709 Digital Wrapper and FEC OPT 0160-06 11.270G Extended Rate (req. 0160-03) OPT 0160-08 11.317G Extended Rate (req. 0160-03) N530-0134 1Gbps V2 Module OPT 0134-11 Dual 1G/2GFC OPT 0134-33 Dual 4GFC TS-10 N550-0228 TS-10 10Gbps Configuration (XFP) OPT 0221-05 10GFC OPT 0228-41 8GFC for 10 Gbps module OPT 0221-03 G.709 Digital Wrapper and FEC OPT 0221-06 11.270G Extended Rate (req. 0221-03) OPT 0221-08 11.317G Extended Rate (req. 0160-03) N550-0224 1Gbps V2 Configuration OPT 0224-11 Dual 1G/2GFC OPT 0224-33 Dual 4GFC 30149267 001 0209 TPFC.SS.TNT.TM.AE NORTH AMERICA LATIN AMERICA ASIA PACIFIC TEL: +1 866 228 3762 FAX: +1 301 353 9216 TEL: +1 954 688-5660 FAX: +1 954 3454668 TEL: +852 2892 0990 FAX: +852 2892 0770 EMEA TEL: +49 7121 86 2222 FAX: +49 7121 86 1222 www.jdsu.com/test
