50BR-001

SPECIFICATION SHEET JFW MODEL 50BR-001 BENCH TOP ROTARY ATTENUATOR JFW Industries, Inc. Phone: 317-887-1340 sales@jfwindustries.com www.jfwindustries.com Frequency Range Impedance Attenuation Range VSWR DC-2000 MHz 50 Ohms nominal 0-110 dB in 1 dB steps 1.3:1 maximum 1.5:1 maximum 1.7:1 maximum ± ± ± ± 0.3 0.5 0.5 0.5 dB dB dB dB or or or or 1% 2% 3% 4% DC-1000 MHz 1000-1500 MHz 1500-2000 MHz DC-500 MHz 500-1000 MHz 1000-1500 MHz 1500-2000 MHz DC-1000 MHz 1000-2000 MHz Attenuation Accuracy Insertion Loss 1.0 dB maximum 1.5 dB maximum 2 Watts average 1000 Watts peak -20ºC to +85ºC RF Input Power Operating Temperature Range Direction of Rotation Attenuation increases in a Clockwise direction 30 degrees with stops at Minimum and maximum BNC, TNC, N or SMA female See outline drawing 092-050-01 Indexing RF Connector Physical Size ECR/ECN # 2837 9999 Page 1 of 1 DATE 05/24/1994 11/26/2001 05/05/2003 REV A B APPR / DATE ECR/ECN # 14197 17408 DATE 05/21/2007 07/10/2009 REV C D APPR / DATE TRS 05/21/2007 TRS 07/10/2009 TRS 02/24/2004 JFW FORM E-7-F REV F
