50R-310

SPECIFICATION SHEET JFW MODEL 50R-310 ROTARY ATTENUATOR JFW Industries, Inc. Phone: 317-887-1340 sales@jfwindustries.com www.jfwindustries.com Frequency Range Impedance Attenuation Range VSWR DC-2700 MHz 50 Ohms nominal 0-10 dB in 1 dB steps 1.2:1 maximum 1.3:1 maximum DC-1000 MHz 1000-2700 MHz Insertion Loss 0.4 dB maximum 0.11 dB typical @ 1000 MHz 0.23 dB typical @ 2700 MHz ± 0.4 dB ± 0.5 dB DC-1000 MHz 1000-2700 MHz Attenuation Accuracy RF Input Power 2 Watts average 1000 Watts peak Attenuation increases in a Clockwise direction 30 degrees with stops at Minimum and maximum SMA female -20ºC to +85ºC See outline drawing 092-039 Direction of Rotation Indexing RF Connector Operating Temperature Range Physical Size ECR/ECN # 9999 11844 Page 1 of 1 DATE 06/13/2001 05/05/2003 09/07/2005 REV A B APPR / DATE BAC 09/08/2005 BAC 09/08/2005 ECR/ECN # 16357 16402 16574 DATE 09/30/2008 10/15/2008 12/02/2008 REV C D E APPR / DATE TRS 09/30/2008 TRS 10/15/2008 TRS 12/02/2008 JFW FORM E-7-F REV F
