JIANGSU CHANGJIANG ELECTRONICS TECHNOLOGY CO., LTD
SOT-23 Plastic-Encapsulate MOSFETS
CJ2307
P-Channel 30-V(D-S) MOSFET
V(BR)DSS
ID
RDS(on)MAX
88mΩ@-10V
-30 V
SOT-23
-2.7A
138mΩ@-4.5V
1. GATE
2. SOURCE
3. DRAIN
FEATURE
TrenchFET Power MOSFET
APPLICATION
z Load Switch for Portable Devices
z
MARKING
Equivalent Circuit
Maximum ratings ( Ta=25℃ unless otherwise noted)
.
Parameter
Symbol
Value
Unit
Drain-Source Voltage
VDS
-30
Gate-Source Voltage
VGS
±20
ID
-2.7
Continuous Source-Drain Current
IS
-0.91
Power Dissipationa,b
PD
1.1
W
RθJA
114
℃/W
Operating Junction Temperature
TJ
150
Storage Temperature
Tstg
-55 ~+150
Continuous Drain Current
a,b
a,b
Thermal Resistance from Junction to Ambient (t≤5s)
www.cj-elec.com
1
V
A
℃
E,Apr,2015
MOSFET ELECTRICAL CHARACTERISTICS
Ta =25 ℃ unless otherwise specified
Parameter
Symbol
Test Condition
Min
Typ
Max
Unit
Static
Drain-Source Breakdown Voltage
V (BR)DSS
VGS = 0V, ID =-250µA
-30
VGS(th)
VDS =VGS, ID =-250µA
-1
Gate-Source Leakage
IGSS
VDS =0V, VGS =±20V
±100
Zero Gate Voltage Drain Current
IDSS
VDS =-30V, VGS =0V
-1
VDS =-30V, VGS =0V, TJ=55℃
-10
Gate-Source Threshold Voltage
Drain-Source On-State Resistancec
RDS(on)
Forward Transconductancec
gfs
-3
VGS =-4.5V, ID =-2.5A
0.110
0.138
VGS =-10V, ID =-3.5A
0.073
0.088
VDS =-10V, ID =-3.5A
7
V
nA
µA
Ω
S
d
Dynamic
Input Capacitance
Ciss
Output Capacitance
Coss
Reverse Transfer Capacitance
Crss
Total Gate Charge
Qg
Gate-Source Charge
Qgs
Gate-Drain Charge
Qgd
Gate Resistance
Rg
Turn-On Delay Time
Rise Time
Turn-Off Delay Time
Fall Time
td(on)
tr
td(off)
tf
340
VDS =-15V,VGS =0V,f =1MHz
pF
67
51
VDS =-15V,VGS =-4.5V,
ID =-2.5A
f =1MHz
VDD=-15V,
RL=15Ω, ID =-1A,
VGEN=-4.5V,Rg=1Ω
4.1
6.2
nC
1.3
1.8
10
Ω
40
60
40
60
20
40
17
30
-0.8
-1.2
ns
Drain-source Body diode characteristics
Body Diode Voltage
VSD
IS=-0.75A, ,VGS =0
V
Notes:
a. t=5s.
b. Surface mounted on 1” ×1” FR4 board.
c. Pulse Test : Pulse Width < 300µs, Duty Cycle ≤2%.
d. Guaranteed by design, not subject to production testing.
www.cj-elec.com
2
E,Apr,2015
Typical Characteristics
Output Characteristics
-20
Ta=25℃
Pulsed
Ta=25℃
Pulsed
VGS=-4.5V
(A)
-8
(A)
-16
ID
ID
VGS=-4.0V
-6
VGS=-3.5V
-8
VGS=-3.0V
DRAIN CURRENT
DRAIN CURRENT
-12
-4
-0
-0
-1
-2
-3
-4
DRAIN TO SOURCE VOLTAGE
RDS(ON) ——
VDS
-5
-0
-1
-2
-3
GATE TO SOURCE VOLTAGE
(V)
ID
RDS(ON) ——
500
-4
VGS
-5
(V)
VGS
Ta=25℃
Ta=25℃
Pulsed
Pulsed
400
RDS(ON)
(m)
250
200
ON-RESISTANCE
(m)
300
RDS(ON)
-4
-2
-0
ON-RESISTANCE
Transfer Characteristics
-10
VGS=-10V,-8V,-6V
VGS=-4.5V
150
VGS=-10V
100
300
ID=-3.5A
200
100
50
0
-0
-4
-8
DRAIN CURRENT
-12
ID
-16
-20
(A)
-0
-4
-8
-12
GATE TO SOURCE VOLTAGE
-16
VGS
-20
(V)
IS —— VSD
-10
Ta=25℃
SOURCE CURRENT
IS (A)
Pulsed
-1
-0.1
-0.01
-0.0
-0.3
-0.6
-0.9
SOURCE TO DRAIN VOLTAGE
-1.2
-1.5
VSD (V)
3 E,Apr,2015
SOT-23 Package Outline Dimensions
Symbol
A
A1
A2
b
c
D
E
E1
e
e1
L
L1
θ
Dimensions In Millimeters
Min
Max
0.900
1.150
0.000
0.100
0.900
1.050
0.300
0.500
0.080
0.150
2.800
3.000
1.200
1.400
2.250
2.550
0.950 TYP
1.800
2.000
0.550 REF
0.300
0.500
0°
8°
Dimensions In Inches
Min
Max
0.035
0.045
0.000
0.004
0.035
0.041
0.012
0.020
0.003
0.006
0.110
0.118
0.047
0.055
0.089
0.100
0.037 TYP
0.071
0.079
0.022 REF
0.012
0.020
0°
8°
SOT-23 Suggested Pad Layout
www.cj-elec.com
4
E,Apr,2015
SOT-23 Tape and Reel
SOT-23 Tape and reel
SOT-23 Embossed Carrier Tape
P0
d
P1
Packaging Description:
SOT-23 parts are shipped in tape. The carrier
tape is made from a dissipative (carbon filled)
polycarbonate resin. The cover tape is a multilayer
film (Heat Activated Adhesive in nature) primarily
composed of polyester film, adhesive layer, sealant,
and anti-static sprayed agent. These reeled parts in
standard option are shipped with 3,000 units per 7"
or 17.8cm diameter reel. The reels are clear in color
and is made of polystyrene plastic (anti-static
coated).
B
W
A
F
E
C
A
A
P
A-A
Dimensions are in millimeter
Pkg type
A
B
C
d
E
F
P0
P
P1
W
SOT-23
3.15
2.77
1.22
Ø1.50
1.75
3.50
4.00
4.00
2.00
8.00
SOT-23 Tape Leader and Trailer
Trailer Tape
Leader Tape
100±2 Empty Pockets
Components
50±2 Empty Pockets
SOT-23 Reel
D
I
G
W2
3000
H
2500
2000
1500
1000
D2
D1
500
W1
Dimensions are in millimeter
Reel Option
D
D1
D2
G
H
I
W1
W2
7''Dia
Ø178.00
54.40
13.00
R78.00
R25.60
R6.50
9.50
12.30
G.W.(kg)
REEL
Reel Size
Box
Box Size(mm)
Carton
Carton Size(mm)
3000 pcs
7 inch
30,000 pcs
203×203×195
120,000 pcs
438×438×220
www.cj-elec.com
5
E,Apr,2015
