PZT2222A

JIANGSU CHANGJIANG ELECTRONICS TECHNOLOGY CO., LTD SOT-223 Plastic-Encapsulate Transistors PZT2222A TRANSISTOR (NPN) SOT-223 FEATURES z Epitaxial planar die construction z Complementary PNP Type available (PZT2907A) 1. BASE MARKING: 2. COLLECTOR 3. EMITTER Solid dot = Green molding compound device, if none,the normal device. MAXIMUM RATINGS (Ta=25℃ unless otherwise noted) Symbol Parameter VCBO Collector-Base Voltage VCEO VEBO IC PC TJ Tstg Collector-Emitter Voltage Emitter-Base Voltage Collector Current -Continuous Collector Power Dissipation Junction Temperature Storage Temperature Value Unit 75 V 40 6 600 1 150 -55~ +150 V V mA W ℃ ℃ ELECTRICAL CHARACTERISTICS (Ta=25℃ unless otherwise specified) Parameter Symbol Test conditions Min Max Unit Collector-base breakdown voltage V(BR)CBO IC= 10μ A,IE=0 75 V Collector-emitter breakdown voltage V(BR)CEO IC= 10mA, IB=0 40 V Emitter-base breakdown voltage V(BR)EBO IE=10μA, IC=0 6 V Collector cut-off current ICBO VCB=60V, IE=0 10 nA Collector cut-off current ICEX VCE=60V,VBE(off)=3V 10 nA Emitter cut-off current IEBO VEB= 3V , IC=0 10 nA hFE(1) VCE=10V, IC= 0.1mA 35 hFE(2) VCE=10V, IC= 1mA 50 hFE(3) VCE=10V, IC= 10mA 75 hFE(4) VCE=10V, IC= 150mA 100 hFE(5) VCE=1V, IC= 150mA 50 hFE(6) VCE=10V, IC= 500mA 40 VCE(sat) IC=500mA, IB= 50mA 1 V VCE(sat) IC=150mA, IB= 15mA 0.3 V VBE(sat) IC=500mA, IB= 50mA 2.0 V VBE(sat) IC=150mA, IB=15mA 1.2 V DC current gain Collector-emitter saturation voltage Base-emitter saturation voltage 300 Transition frequency fT Output Capacitance Cob VCB=10V, IE= 0,f=1MHz 8 pF Delay time td 10 ns Rise time tr VCC=30V, IC=150mA VBE(off)=0.5V,IB1=15mA 25 ns Storage time tS 225 ns Fall time tf VCC=30V, IC=150mA IB1=-IB2= 15mA 60 ns www.cj-elec.com VCE=20V,IC= 20mA, f=100MHz 1 300 MHz D,Jan,2017 Typical Characteristics Static Characteristic COMMON EMITTER Ta=25℃ COLLECTOR CURRENT 700uA 0.15 600uA 500uA 0.10 400uA Ta=25℃ 100 200uA COMMON EMITTER VCE= 10V IB= 100uA 4 6 8 10 12 VCEsat —— 100 14 10 16 1 IC Ta=25℃ β=10 10 10 IC —— 600 (mA) IC 900 Ta=25℃ 600 Ta=100 ℃ β=10 1 10 COLLECTOR CURREMT (mA) VBE fT 500 600 100 —— IC (mA) IC (MHz) 600 IC IC 300 600 100 COLLECTOR CURREMT 100 VBEsat —— 1200 Ta=100 ℃ 1 10 COLLECTOR CURRENT VCE (V) BASE-EMITTER SATURATION VOLTAGE VBEsat (mV) 2 1000 COLLECTOR-EMITTER SATURATION VOLTAGE VCEsat (mV) Ta=100℃ 300uA 0.05 COLLECTOR-EMITTER VOLTAGE 100 TRANSITION FREQUENCY 10 T =2 5℃ a T= a 10 0℃ fT IC (mA) DC CURRENT GAIN 800uA 0 COLLECTOR CURRENT IC 900uA 0.00 1 COMMON EMITTER VCE= 10V 100 COMMON EMITTER VCE=10V Ta=25℃ 0.1 10 0 300 600 900 1200 1 10 100 Cob/Cib —— VCB/VEB PC 1200 f=1MHz IE=0/IC=0 —— IC (mA) Ta COLLECTOR POWER DISSIPATION PC (mW) 1100 Ta=25 ℃ (pF) 100 COLLECTOR CURRENT BESE-EMMITER VOLTAGE VBE (mV) Cib C CAPACITANCE —— 1mA hFE 0.20 hFE 1000 IC (A) 0.25 10 Cob 1000 900 800 700 600 500 400 300 200 100 1 0.1 1 REVERSE VOLTAGE www.cj-elec.com 10 V 0 20 0 (V) 25 50 75 AMBIENT TEMPERATURE 2 100 Ta 125 150 (℃ ) D,Jan,2017 SOT-223 Package Outline Dimensions Symbol A A1 A2 b b1 c D E E1 e L θ Dimensions In Millimeters Min. Max. —— 1.800 0.020 0.100 1.500 1.700 0.660 0.840 2.900 3.100 0.230 0.350 6.300 6.700 6.700 7.300 3.300 3.700 2.300(BSC) 0.750 —— 0° 10° Dimensions In Inches Min. Max. —— 0.071 0.001 0.004 0.059 0.067 0.026 0.033 0.114 0.122 0.009 0.014 0.248 0.264 0.264 0.287 0.130 0.146 0.091(BSC) 0.030 —— 0° 10° SOT-223 Suggested Pad Layout www.cj-elec.com 3 D,Jan,2017 SOT-223 Tape and Reel P1 C A E P0 d SOT-223 Embossed Carrier Tape A B F W A A A A-A P Packaging Description: SOT-223 parts are shipped in tape. The carrier tape is made from a dissipative (carbon filled) polycarbonate resin. The cover tape is a multilayer film (Heat Activated Adhesive in nature) primarily composed of polyester film, adhesive layer, sealant, and anti-static sprayed agent. These reeled parts in standard option are shipped with 2,500 units per 13" or 33.0cm diameter reel. The reels are clear in color and is made of polystyrene plastic (anti-static coated). Dimensions are in millimeter Pkg type A B C d E F P0 SOT-223 6.765 7.335 1.88 Ø1.50 1.75 5.50 4.00 P P1 W 8.00 2.00 12.00 SOT-223 Tape Leader and Trailer Leader Tape Trailer Tape Components 51±1 Empty Pockets G SOT-223 Reel 51±1 Empty Pockets H W1 D1 D2 I W2 D Dimensions are in millimeter Reel Option D D1 D2 G H I W1 W2 13''Dia Ø330.00 100.00 13.00 R151.00 R56.00 R6.50 12.40 17.60 Carton Size(mm) G.W.(kg) REEL 2,500 pcs www.cj-elec.com Reel Size 13 inch Box 2,500 pcs Box Size(mm) 336×336×48 4 Carton 20,000 pcs 445×355×365 D,Jan,2017
