MM-1315-100

MM-1315-100 Operating Voltage _____________ 250/480 V~, 50 / 60 Hz Operating Voltage _____________ 125/208 V~, 50 – 400 Hz Operating Current ____________ 100 A / Phase Temperature Range __________ -20 TO 50 Deg. C Diel. Withstand (L-CASE) _______ 1500 V~ FOR 1 MIN. Diel. Withstand (L-L) ___________ 2200 Vdc For 1 Min. Leakage Current ______________18 ma (max) @ 250 V~, 60 Hz Resid.Volt after 3.0 second _____ 20 V Max. Max. Cap. each line to case _____0.10 uF 1 LINE LOAD 1 2 2 3 3 GRD GRD Order P/N: MM-1315-100 The Mm-1315-100 filter is designed for use with large computer or motor installations where heavy current is drawn continuously. This filter can handle large in-rush current typical of modern power supplies. When data lines or power is shared with other systems the ground coil helps breakup ground loops which can cause system errors and also increase conducted RF 18.00 17.00 16.00 3.00 2.00 1 LOAD 3 2 1 2 LINE 3 1.15 1.15 2.30 1.50 GRD GRD 3.00 0.70 .27 x .56 SLOT (4 PL) 1/4 - 20 THR'D TER (10 PL) USA EUR JMK Inc 15 Caldwell Dr. Amherst, NH 03031 JMK Ltd Dumbarton G82 2TS Scotland UK PH: 603 886-4100 FX: 603 886-4115 email: info@jmkfilters.com PH: 44-(0) 1389-751841 FX: 44-(0) 1389-751841
