MM-1315-125
Operating Voltage = 250/480 V~, 50 / 60 Hz Operating Voltage = 125/208 V~, 50 – 400 Hz Operating Current = 125 A / Phase Temperature Range = -20 TO 50 Deg. C Diel. Withstand (L-CASE) = 1500 V~ FOR 1 MIN. Diel. Withstand (L-L) = 2200 Vdc For 1 Min. Leakage Current = 18 ma (max) @ 250 V~, 60 Hz Discharge Volt after 3.0 second = 20 V Max. Maximum Capacitance each line to case = 0.10 uF
LINE 1
LOAD
1
2
2
3
3
GRD
GRD
Order P/N:
MM-1315-125
INSERTION LOSS VS. FREQUENCY
90 80
The Mm-1315-125 filter is designed for use with large computer or motor installations where heavy current is drawn continuously. This filter can handle large in-rush current typical of modern power supplies. When data lines or power is shared with other systems the ground coil helps breakup ground loops which can cause system errors and also increase conducted RF emissions.
INSERTION LOSS (db)
70 60 50 40 30 20 10 0 .01 .02 .04 .07
DM
CM
.1 .2
.4 .7
1 2
4 7
10 20
40 70
100
FREQUENCY (MEGAHERTZ)
18.00 17.00 16.00 3.00 2.00
1
LOAD 3 2
1 2 LINE
3
1.15 1.15
3.00
2.30 1.50
GRD
. 27 x .56 SLOT (4 PL)
GRD
0.70 1/4 - 20 THR'D TERM (10 PL)
USA EUR
JMK Inc 15 Caldwell Dr. Amherst, NH 03031 JMK Ltd Dumbarton G82 2TS Scotland UK
PH: 603 886-4100 FX: 603 886-4115 email: info@jmkfilters.com PH: 44-(0) 1389-751841 FX: 44-(0) 1389-751841
