KP-3216SRD

Kingbright Features l3.2mmx1.6mm lLOW ® 3.2x1.6mm SMD CHIP LED LAMPS KP-3216 Package Dimensions SMT LED. 1.1mm THICKNESS. POWER CONSUMPTION. lWIDE VIEWING ANGLE. lIDEAL FOR BACKLIGHT AND INDICATOR. lVARIOUS COLORS AND LENS TYPES AVAILABLE. 1 Description The Bright Red source color devices are made with Gallium Phosphide Red Light Emitting Diode. The Super Bright Green source color devices are made with Gallium Phosphide Green Light Emitting Diode. The High Efficiency Red source color devices are made with Gallium Arsenide Phosphide on Gallium Phosphide Orange Light Emitting Diode. The Yellow source color devices are made with Gallium Arsenide Phosphide on Gallium Phosphide Yellow Light Emitting Diode. The Super Bright Red source color devices are made with Gallium Aluminum Arsenide Red Light Emitting Diodes. Notes: 1. All dimensions are in millimeters (inches). 2. Tolerance is ±0.2.(0.0079") unless otherwise noted. 3. Lead spacing is measured where the lead emerge package. 4. Specifications are subjected to change without notice. Selection Guide Part No. KP-3216HD KP-3216HC KP-3216HT KP-3216ID KP-3216EC KP-3216IT KP-3216YD KP-3216YC KP-3216YT KP-3216SRD KP-3216SRC KP-3216SRT KP-3216SGD KP-3216SGC KP-3216SGT Dice BRIGHT RED (GaP) BRIGHT RED (GaP) BRIGHT RED (GaP) HIGH EFFICIENCY RED (GaAsP/GaP) HIGH EFFICIENCY RED (GaAsP/GaP) HIGH EFFICIENCY RED (GaAsP/GaP) YELLOW (GaAsP/GaP) YELLOW (GaAsP/GaP) YELLOW (GaAsP/GaP) SUPER BRIGHT RED (GaAlAs) SUPER BRIGHT RED (GaAlAs) SUPER BRIGHT RED (GaAlAs) SUPER BRIGHT GREEN (GaP) SUPER BRIGHT GREEN (GaP) SUPER BRIGHT GREEN (GaP) Lens Type RED DIFFUSED WATER CLEAR RED TRAS. RED DIFFUSED WATER CLEAR RED TRANS. YELLOW DIFFUSED WATER CLEAR YELLOW TRANS. RED DIFFUSED WATER CLEAR RED TRANS. GREEN DIFFUSESD WATER CLEAR GREEN TRNS. Iv (mcd) @ 20 mA Min. 0.8 0.8 0.8 5 5 5 3.2 3.2 3.2 40 40 40 3.2 3.2 3.2 Typ. 1.25 1.25 1.2 12.5 12.5 12.5 8 8 8 70 70 70 12.5 12.5 12.5 Viewing Angle 2θ1/2 120° 120° 120° 120° 120° 120° 120° 120° 120° 120° 120° 120° 120° 120° 120° Note: 1. θ1/2 is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value. 1-KP-3216 Electrical / Optical Characteristics at T A=25°C Symbol Parameter Device Bright Red High Efficiency Red Yellow Super Bright Red Super Bright Green Bright Red High Efficiency Red Yellow Super Bright Red Super Bright Green Bright Red High Efficiency Red Yellow Super Bright Red Super Bright Green Bright Red High Efficiency Red Yellow Super Bright Red Super Bright Green All Typ. 700 625 590 660 565 45 45 35 20 30 40 12 10 95 45 2.0 2.0 2.1 1.85 2.2 10 Max. Units Test Conditions λpeak Peak Wavelength nm IF=20mA ∆λ1/2 Spectral Line Halfwidth nm IF=20mA C Capacitance pF VF=0V;f=1MHz vF IR Forward Voltage 2.5 2.5 2.5 2.5 2.5 V IF=20mA Reverse Current uA VR = 5V Absolute Maximum Ratings at T A=25°C Parameter Power dissipation DC Forward Current Peak Forward Current [1] Reverse Voltage Operating/Storage Temperature Lead Soldering Temperature [2] Note: 1. 1/10 Duty Cycle, 0.1ms Pulse Width. Bright Red 105 25 150 5 High Efficiency Red 105 30 150 5 Yellow 105 30 150 5 Super Bright Red 100 30 150 5 Super Bright Green 105 25 150 5 Units mW mA mA V -40 ° C To +85 ° C 230 ° C For 3 Seconds 1-KP-3216 Bright Red KP-3216HD, KP-3216HC, KP-3216HT 1 High Efficiency Red KP-3216ID, KP-3216EC, KP-3216IT 1-KP-3216 Yellow KP-3216YD, KP-3216YC, KP-3216YT Super Bright Red KP-3216SRD, KP-3216SRC, KP-3216SRT 1-KP-3216 Super Bright Green KP-3216SGD, KP-3216SGC, KP-3216SGT 1 KP-3216 Series SMT Reflow Soldering Instructions 1-KP-3216 KP-3216 Series Recommended Soldering Pattern KP-3216 Series Tape Specifications (Units : mm) 1-KP-3216
