KPT-1608YC

1.6X0.8mm SMD CHIP LED LAMP Part Number: KPT-1608YC Features Yellow Description 1.6mmX0.8mm SMD LED, 0.75mm thickness. The Yellow source color devices are made with Gallium Low power consumption. Arsenide Phosphide on Gallium Phosphide Yellow Light Wide viewing angle. Emitting Diode. Ideal for backlight and indicator. Package: 2000pcs / reel . Moisture sensitivity level : level 3. RoHS compliant. t h ig r b Package Dimensions g in K Notes: 1. All dimensions are in millimeters (inches). 2. Tolerance is ±0.1(0.004") unless otherwise noted. 3. The specifications, characteristics and technical data described in the datasheet are subject to change without prior notice. 4. The device has a single mounting surface. The device must be mounted according to the specifications. SPEC NO: DSAB6992 REV NO: V.21B DATE: MAY/19/2016 PAGE: 1 OF 5 APPROVED: Wynec CHECKED: Allen Liu DRAWN: L.T.Zhang ERP: 1203001790 Selection Guide Part No. Emitting Color (Material) Viewing Angle [1] Iv (mcd) [2] @ 20mA Lens Type Min. KPT-1608YC Yellow (GaAsP/GaP) Typ. 2θ1/2 3 8 150° Water Clear Notes: 1. θ1 / 2 is the angle from optical centerline where the luminous intensity is 1 / 2 of the optical peak value. 2. Luminous intensity / luminous Flux: + / -15%. 3. Luminous intensity value is traceable to CIE127-2007 standards. Electrical / Optical Characteristics at TA=25°C Symbol Parameter Emitting Color Typ. λpeak Peak Wavelength Yellow Dominant Wavelength Yellow 588 Δλ1/2 Spectral Line Half-width Yellow 35 C Capacitance Yellow 20 VF [2] Forward Voltage IR Reverse Current t h 590 λD [1] Max. Units Test Conditions nm IF=20mA nm IF=20mA nm IF=20mA pF VF=0V;f=1MHz 2.5 V IF=20mA 10 uA VR=5V ig r b g in Yellow 2.1 Yellow Notes: 1. Wavelength: + / -1nm. 2. Forward Voltage: + / -0.1V. 3. Wavelength value is traceable to CIE127-2007 standards. 4. Excess driving current and / or operating temperature higher than recommended conditions may result in severe light degradation or premature failure. K Absolute Maximum Ratings at TA=25°C Parameter Values Units Power dissipation 75 mW DC Forward Current 30 mA Peak Forward Current [1] 140 mA 5 V Reverse Voltage Operating Temperature -40°C To +85°C Storage Temperature -40°C To +85°C Notes: 1. 1/10 Duty Cycle, 0.1ms Pulse Width. 2. Relative humidity levels maintained between 40% and 60% in production area are recommended to avoid the build-up of static electricity – Ref JEDEC/JESD625-A and JEDEC/J-STD-033. SPEC NO: DSAB6992 REV NO: V.21B DATE: MAY/19/2016 PAGE: 2 OF 5 APPROVED: Wynec CHECKED: Allen Liu DRAWN: L.T.Zhang ERP: 1203001790 Yellow KPT-1608YC t h ig r b g in K SPEC NO: DSAB6992 REV NO: V.21B DATE: MAY/19/2016 PAGE: 3 OF 5 APPROVED: Wynec CHECKED: Allen Liu DRAWN: L.T.Zhang ERP: 1203001790 KPT-1608YC Reflow soldering is recommended and the soldering profile is shown below. Other soldering methods are not recommended as they might cause damage to the product. t h ig r b Recommended Soldering Pattern (Units : mm; Tolerance: ± 0.1) Reel Dimension g in Tape Dimensions (Units : mm) K SPEC NO: DSAB6992 REV NO: V.21B DATE: MAY/19/2016 PAGE: 4 OF 5 APPROVED: Wynec CHECKED: Allen Liu DRAWN: L.T.Zhang ERP: 1203001790 PACKING & LABEL SPECIFICATIONS KPT-1608YC t h ig r b g in K Terms and conditions for the usage of this document 1. The information included in this document reflects representative usage scenarios and is intended for technical reference only. 2. The part number, type, and specifications mentioned in this document are subject to future change and improvement without notice. Before production usage customer should refer to the latest datasheet for the updated specifications. 3. When using the products referenced in this document, please make sure the product is being operated within the environmental and electrical limits specified in the datasheet. If customer usage exceeds the specified limits, Kingbright will not be responsible for any subsequent issues. 4. The information in this document applies to typical usage in consumer electronics applications. If customer's application has special reliability requirements or have life-threatening liabilities, such as automotive or medical usage, please consult with Kingbright representative for further assistance. 5. The contents and information of this document may not be reproduced or re-transmitted without permission by Kingbright. 6. All design applications should refer to Kingbright application notes available at http://www.kingbright.com/application_notes SPEC NO: DSAB6992 REV NO: V.21B DATE: MAY/19/2016 PAGE: 5 OF 5 APPROVED: Wynec CHECKED: Allen Liu DRAWN: L.T.Zhang ERP: 1203001790
