KPT-2012SURC

2.0x1.2mm SMD CHIP LED LAMP KPT-2012SURC HYPER RED Features !2.0mmx1.2mm SMT LED,0.75mm THICKNESS. !LOW POWER CONSUMPTION. !WIDE VIEWING ANGLE. !IDEAL FOR BACKLIGHT AND INDICATOR. !VARIOUS COLORS AND LENS TYPES AVAILABLE. !PACKAGE Description The Hyper Red source color devices are made with DH InGaAlP on GaAs substrate Light Emitting Diode. : 2000PCS / REEL. Package Dimensions Notes: 1. All dimensions are in millimeters (inches). 2. Tolerance is ±0.1(0.004") unless otherwise noted. 3. Lead spacing is measured where the lead emerge package. 4. Specifications are subject to change without notice. SPEC NO: KDA0099 APPROVED : J. Lu REV NO: V.1 CHECKED : DATE: SEP/07/2001 DRAWN: S.H.Chen PAGE: 1 OF4 Selection Guide Par t No . Dic e L en s Ty p e Iv (m c d ) @ 20 m A Min . KPT-2012SURC HYPER RED( InGaAlP ) WATER CLEAR 70 Ty p . 150 V i ew i n g An g l e 2θ1/2 12 0 ° Note: 1. θ1/2 is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value. Electrical / Optical Characteristics at T)=25°C Sy m b o l λpeak λD ∆λ1/2 C VF IR Par am et er Peak Wavelength Dominate Wavelength Spectral Line Halfwidth Capacitance Forward Voltage Reverse Current D ev i c e Hyper Red Hyper Red Hyper Red Hyper Red Hyper Red Hyper Red Ty p . 640 6 28 27 45 1.9 2.5 10 Max . Un it s nm nm nm pF V uA Tes t Co n d it io n s IF=20mA IF=20mA IF=20mA VF=0V;f=1MHz IF=20mA V R = 5V Absolute Maximum Ratings at T)=25°C Par am et er Power dissipation DC Forward Current Peak Forward Current [1] Reverse Voltage Operating Temperature Storage Temperature Note: 1. 1/10 Duty Cycle, 0.1ms Pulse Width. H y p e r R ed 170 30 185 5 -40°C To +85°C -40°C To +85°C Un it s mW mA mA V SPEC NO: KDA0099 APPROVED : J. Lu REV NO: V.1 CHECKED : DATE: SEP/07/2001 DRAWN: S.H.Chen PAGE: 2 OF4 Hyper Red KPT-2012SURC SPEC NO: KDA0099 APPROVED : J. Lu REV NO: V.1 CHECKED : DATE: SEP/07/2001 DRAWN: S.H.Chen PAGE: 3 OF4 KPT-2012SURC SMT Reflow Soldering Instructions Number of reflow process shall be less than 2 times and cooling process to normal temperature is required between first and second soldering process. Recommended Soldering Pattern (Units : mm) Tape Specifications (Units : mm) SPEC NO: KDA0099 APPROVED : J. Lu REV NO: V.1 CHECKED : DATE: SEP/07/2001 DRAWN: S.H.Chen PAGE: 4 OF4
