SC04-11GWA_11

10.16mm (0.4INCH) SINGLE DIGIT NUMERIC DISPLAY Part Number: SC04-11GWA Green Features 0.4 inch digit height. Low current operation. Excellent character appearance. Easy mounting on P.C. boards or sockets. Mechanically rugged. Standard : gray face, white segment. RoHS compliant. Description The Green source color devices are made with Gallium Phosphide Green Light Emitting Diode. Package Dimensions& Internal Circuit Diagram Notes: 1. All dimensions are in millimeters (inches), Tolerance is ±0.25(0.01")unless otherwise noted. 2. The specifications, characteristics and technical data described in the datasheet are subject to change without prior notice. SPEC NO: DSAD2261 APPROVED: WYNEC REV NO: V.10 CHECKED: Joe Lee DATE: FEB/10/2011 DRAWN: Y.F.Lv PAGE: 1 OF 6 ERP: 1301000709 Selection Guide Part No. Dice Lens Type Iv (ucd) [1] @ 10mA Min. SC04-11GWA Green (GaP) White Diffused 3600 Typ. 8600 Common Cathode, Rt. Hand Decimal. Description Note: 1. Luminous intensity/ luminous Flux: +/-15%. Electrical / Optical Characteristics at TA=25°C Symbol λpeak λD [1] Δλ1/2 C VF [2] IR Parameter Peak Wavelength Dominant Wavelength Spectral Line Half-width Capacitance Forward Voltage Reverse Current Device Green Green Green Green Green Green Typ. 565 568 30 15 2.2 2.5 10 Max. Units nm nm nm pF V uA Test Conditions IF=20mA IF=20mA IF=20mA VF=0V;f=1MHz IF=20mA VR=5V Notes: 1.Wavelength: +/-1nm. 2. Forward Voltage: +/-0.1V. Absolute Maximum Ratings at TA=25°C Parameter Power dissipation DC Forward Current Peak Forward Current [1] Reverse Voltage Operating / Storage Temperature Lead Solder Temperature[2] Notes: 1. 1/10 Duty Cycle, 0.1ms Pulse Width. 2. 2mm below package base. Green 62.5 25 140 5 -40°C To +85°C 260°C For 3-5 Seconds Units mW mA mA V SPEC NO: DSAD2261 APPROVED: WYNEC REV NO: V.10 CHECKED: Joe Lee DATE: FEB/10/2011 DRAWN: Y.F.Lv PAGE: 2 OF 6 ERP: 1301000709 Green SC04-11GWA SPEC NO: DSAD2261 APPROVED: WYNEC REV NO: V.10 CHECKED: Joe Lee DATE: FEB/10/2011 DRAWN: Y.F.Lv PAGE: 3 OF 6 ERP: 1301000709 PACKING & LABEL SPECIFICATIONS SC04-11GWA SPEC NO: DSAD2261 APPROVED: WYNEC REV NO: V.10 CHECKED: Joe Lee DATE: FEB/10/2011 DRAWN: Y.F.Lv PAGE: 4 OF 6 ERP: 1301000709 SPEC NO: DSAD2261 APPROVED: WYNEC REV NO: V.10 CHECKED: Joe Lee DATE: FEB/10/2011 DRAWN: Y.F.Lv PAGE: 5 OF 6 ERP: 1301000709 SPEC NO: DSAD2261 APPROVED: WYNEC REV NO: V.10 CHECKED: Joe Lee DATE: FEB/10/2011 DRAWN: Y.F.Lv PAGE: 6 OF 6 ERP: 1301000709
