SG-213

Photointerrupters(Transmissive) KODENSHI SG-213 DIMENSIONS The SG-213 photointerrupter high-performance standard type, combines high-output GaAs IRED with high sensitive phototransistor. (Unit : mm) FEATURES •High performance •High-speed response •5mm gap. •Widely applicable APPLICATIONS •Tape-end sensors •Timing sensors •Edge sensors •Copiers MAXIMUM RATINGS Item Power dissipation Input Reverse voltage Forward current Pulse forward current *1 Collector power dissipation Collector current Output C-E voltage E-C voltage Operating temp. Storage temp. Soldering temp.*2 (Ta=25℃) Symbol PD VR IF IFP PC IC VCEO VECO Topr. Tstg. Tsol. Rating 100 5 60 1 100 40 30 5 -20~+85 -30~+85 240 Unit mW V mA A mW mA V V ℃ ℃ ℃ *1.ｔｗ≦100 μ sec.period ：T=10msec. *2. For MAX. 5 seconds at the position of 2mm from the package ELECTRO-OPTICAL CHARACTERISTICS Item Forward voltage Reverse current Capacitance Peak wavelength Output Collector dark current Light current C-E saturation voltage Switching Rise time speeds Fall time Input (Ta=25℃) Symbol VF IR Ct λp ICEO IL VCE(sat) tr tf Conditions IF=30mA VR=5V V=0, f=1KHz VCE=10V VCE=5V, IF=20mA IF=30mA, IC=0.2mA VCC=5V, IC=2mA RL=100Ω Min. Typ. 1.2 25 940 Max. 1.5 10 0.1 Unit. V μA pF nm μA mA V μ ec. s μ ec. s 0.1 0.4 5 5 - 1- Photo interrupters(Transmissive) SG-213 Collector power dissipation Vs. Ambient temperature Forward current Vs. Forward voltage Light current Vs. Forward current Light current Vs. Collector-Emitter voltage Relative light current Vs. Ambient temperature Dark current Vs. Ambient temperature Switching time Vs. Load resistance Relative light current Vs. Moving distance - 2-
