2322

Bandpass Filter KR Model 2322 Passband Amplitude & Group Delay 4.950 000 MHz 1 1 Overall Amplitude 2 0.000 000 MHz REF= 10 dB/DIV 0.7 dB/div 1_:-54.288 dB -905 kHz 3_:-46.525 dB 805 kHz 3 1 1 2 100 nsec/div 4.335 MHz 5.565 MHz 3 MHz 7 MHz Specifications KR Part Number Filter Type Center Frequency Insertion Loss Passband ±0.7 dB Lower Stopband dc to 4.905 MHz Upper Stopband 5.805 to 100 MHz Group Delay Ripple 4.335 MHz to 5.565 MHz Source and Load Impedance 2322 Bandpass 4.95 MHz 45 dB > 45 dB < ±100 nsec 75 Ω Outline Drawing www.krfilters.com 91 Avenel Street Avenel, NJ 07001 732-636-1900 KR Electronics Dimensions in inches
