KR 2403 HDTV ANTI-ALIASING FILTER
General Description KR 2403 is a HDTV anti-aliasing filter. The filter has a 60 MHz passband and group delay equalization. Other passband frequencies are available. Please consult the factory.
KR Electronics, Inc. Inc.
www.krfilters.com
Features Features • Anti-Aliasing filter • Elliptic response • Group delay equalization • 75 Ω
Typical Performance
Passband Amplitude & Group Delay
(0.2 dB/div & 1 nsec/div)
19 Sep 2001 09:55:41
CH1 CH2 S31 S31 LOG DEL .2 dB/ 1 ns/ REF -.9 dB REF 50 ns
CH1 S31 LOG 10 dB/
Overall Response
(10 dB/div)
19 Sep 2001 09:58:14
REF 0 dB
PRm
PRm
Cor
Cor
PRm Smo Cor
Avg 9
START
. 100
000
MHz
STOP
60 . 000
000
MHz
START
. 100
000
MHz
STOP
200 . 000
000
MHz
Figure 1
Figure 2
KR Electronics, Inc. 91 Avenel Street Avenel, NJ 07001 © 2001, KR Electronics, Inc.
Web Email Phone Fax
www.krfilters.com sales@krfilters.com (732) 636-1900 (732) 636-1982 Page 1
KR KR Electronics, Inc. Inc.
KR KR 2403 HDTV Filter
Specifications
Parameter Filter type Insertion Loss Passband Ripple to 40 MHz Passband Ripple to 60 MHz Group Delay Ripple to 40 MHz Group Delay Ripple to 60 MHz Start of Stopband Stopband Attenuation Source & Load Specification Lowpass < 1.5 dB < ± 0.1 dB < ± 0.2 dB < ± 1 nsec < ± 1.5 nsec 74.25 MHz > 40 dB 75 Ω
www.krfilters.com
Physical Dimensions
KR Electronics, Inc. 91 Avenel Street Avenel, NJ 07001 © 2001, KR Electronics, Inc.
Web Email Phone Fax
www.krfilters.com sales@krfilters.com (732) 636-1900 (732) 636-1982 Page 2
