KR 2502 Bandpass Filter General Description KR Electronics, Inc. www.krfilters.com KR 2502 is a 70 MHz surface mount bandpass filter. Other cen- Features Features ter frequencies and bandwidths available. Please consult the fac- • Surface Mount Package tory. • Sharp Transition to Stopband • >55 dB Stopband • 75 Ω Source and Load Typical Performance Passband Amplitude & Group Delay (0.5 dB/div and 10 nsec/div) 1 Oct 2003 10:00:06 CH1 CH2 PRm Cor S 21 S 21 log MAG delay .5 dB/ 10 ns/ REF 0 dB REF 30 ns CH1 S 21 log MAG Overall Response (10 dB/div) 1 Oct 2003 09:58:33 10 dB/ REF 0 dB PRm Cor 2 PRm Cor 1 CENTER 70.000 000 MHz SPAN 139.980 000 MHz CENTER 70.000 000 MHz SPAN 36.000 000 MHz KR Electronics, Inc. 91 Avenel Street Avenel, NJ 07001 © 2003, KR Electronics, Inc. Web Email Phone Fax www.krfilters.com sales@krfilters.com (732) 636-1900 (732) 636-1982 Page 1 KR KR Electronics, Inc. KR KR 2502 Bandpass Specifications Parameter Filter type Center Frequency Insertion Loss Min 1 dB Bandwidth Max 55 dB Bandwidth Source and Load Specification Bandpass 70 MHz < 2 dB (
