2510-SMA

KR Electronics, Inc. KR 2510-SMA Bandpass Filter General Description KR 2510-SMA is a 40 MHz surface mount bandpass filter. Other center frequencies and bandwidths available. Please consult the factory. www.krfilters.com Features • SMA Connectors • Sharp Transition to Stopband • >55 dB Stopband • 50 Ω Source and Load Typical Performance Overall Response (10 dB/div) 15 Oct 2003 11:35:43 CH1 S 21 log MAG 10 dB/ REF .84 dB PRm Cor CENTER 40.000 000 MHz SPAN 50.000 000 MHz KR Electronics, Inc. 91 Avenel Street Avenel, NJ 07001 © 2005, KR Electronics, Inc. Web Email Phone Fax www.krfilters.com sales@krfilters.com (732) 636-1900 (732) 636-1982 Page 1 KR Electronics, Inc. KR 2510-SMA Bandpass Specifications Parameter Filter type Center Frequency Insertion Loss Min 3 dB Bandwidth Max 55 dB Bandwidth Source and Load Specification Bandpass 40 MHz < 5 dB ( 2.5 dB typical) 4 MHz (4.8 MHz typical) 10 MHz (9.5 MHz typical) 50 Ω www.krfilters.com Physical Dimensions Dimensions in inches Metal Case KR Electronics, Inc. 91 Avenel Street Avenel, NJ 07001 © 2005, KR Electronics, Inc. Web Email Phone Fax www.krfilters.com sales@krfilters.com (732) 636-1900 (732) 636-1982 Page 2
