2521-4

KR Electronics 2521-4 Bandpass General Description KR 2521-4 s a 100 MHz bandpass filter. The filter has a minimum 3 dB bandwidth of 20 MHz and is designed for 50 Ω source and load impedance. Other center frequencies and bandwidths are available. Please consult the factory. KR Electronics, Inc. www.krfilters.com Features Features • 100 MHz Bandpass • 50 Ω • SMA Connectors Typical Performance Passband Amplitude (1 dB/div) 14 Nov 2003 14:31:42 CH1 S 21 log MAG 1 dB/ REF 0 dB CH1 S 21 log MAG Overall Response (5 dB/div) 14 Nov 2003 14:32:24 5 dB/ REF 0 dB PRm Cor PRm Cor START 90.000 000 MHz STOP 110.000 000 MHz START .100 000 MHz STOP 225.000 000 MHz KR Electronics, Inc. 91 Avenel Street Avenel, NJ 07001 © 2003, KR Electronics, Inc. Web Email Phone Fax www.krfilters.com sales@krfilters.com (732) 636-1900 (732) 636-1982 Page 1 KR KR Electronics, Inc. KR 2521KR Electronics 2521-4 Specifications Parameter Filter type Center Frequency Insertion Loss 3 dB Bandwidth Source & Load Specification Bandpass 100 MHz < 3 dB ( 1 dB Typ) 20 MHz min 50 Ω www.krfilters.com Physical Dimensions KR Electronics, Inc. 91 Avenel Street Avenel, NJ 07001 © 2003, KR Electronics, Inc. Web Email Phone Fax www.krfilters.com sales@krfilters.com (732) 636-1900 (732) 636-1982 Page 2
