2532

KR Electronics, Inc. KR Electronics 2532 General Description KR 2532 is a 30 MHz low cost video filter with near SMPTE 274M performance. Other bandwidths available. Please consult the factory. For filter with Sin(x)/x compensation see KR 2382. www.krfilters.com Features • SIP Package • Sharp Transition to Stopband • Near SMPTE 274M • 75 Ω Source and Load Typical Performance Passband Amplitude & Group Delay (0.2 dB/div and 3nsec/div) 3 Mar 2004 13:26:40 CH1 CH2 PRm Cor 1 S 21 S 21 log MAG delay .2 dB/ 3 ns/ REF -.7 dB REF 50 ns CH1 S 21 log MAG Overall Response (5 dB/div) 3 Mar 2004 13:28:55 5 dB/ REF 0 dB PRm Cor PRm Cor 2 Smo START .100 000 MHz STOP 30.000 000 MHz START .100 000 MHz STOP 100.000 000 MHz KR Electronics, Inc. 91 Avenel Street Avenel, NJ 07001 © 2004, KR Electronics, Inc. Web Email Phone Fax www.krfilters.com sales@krfilters.com (732) 636-1900 (732) 636-1982 Page 1 KR Electronics, Inc. KR Electronics 2532 Specifications Parameter Filter type End of Passband Insertion Loss Passband Ripple Attenuation at 37.125 MHz Attenuation at 43.5 MHz Sin(x)/x Group Delay Ripple to 27 MHz Source and Load Specification Video Lowpass 30 MHz < 1 dB (0.7 dB typical) < 0.2 dB 12 dB > 40 dB No < 3 nsec 75 Ω www.krfilters.com See KR 2382 for Sin(x)/x compensated filter Physical Dimensions Pin 1 is Input Pin 11 is Output Pins 2 thru 10 are Ground Pin Dimensions .020 x .010 All dimensions in inches KR Electronics, Inc. 91 Avenel Street Avenel, NJ 07001 © 2004, KR Electronics, Inc. Web Email Phone Fax www.krfilters.com sales@krfilters.com (732) 636-1900 (732) 636-1982 Page 2
