2600

KR Electronics, Inc. KR Electronics 2600 Bandpass Filter General Description Features KR 2600 is a 120 MHz bandpass filters. Other passband frequen- • 120 MHz Bandpass cies are available. Please consult the factory. • 50 Ω Source and Load • SMA Connectors www.krfilters.com Typical Performance Passband Amplitude & Return Loss (1 dB/div & 5 dB/div) 22 Feb 2005 12:35:30 CH1 CH2 CH4 S31 S11 S33 LOG LOG LOG 1 dB/ 5 dB/ 5 dB/ REF 0 dB REF -20 dB REF -20 dB Overall Response (10 dB/div) 22 Feb 2005 12:36:11 CH1 S31 LOG 10 dB/ REF 0 dB Cor Cor 2 4 Avg 16 Cor Cor 1 CENTER 120 . 000 000 MHz SPAN 30 . 000 000 MHz START 1 . 000 000 MHz STOP 500 . 000 000 MHz KR Electronics, Inc. 91 Avenel Street Avenel, NJ 07001 © 2005, KR Electronics, Inc. Web Email Phone Fax www.krfilters.com sales@krfilters.com (732) 636-1900 (732) 636-1982 Page 1 KR Electronics, Inc. KR 2600 Bandpass Specifications Parameter Filter type Center Frequency Insertion Loss Minimum 1 dB Bandwidth Source & Load Specification Bandpass 120 MHz < 3 dB (< 2 dB Typical) 10 MHz 50 Ω www.krfilters.com Physical Dimensions Dimensions shown in inches KR Electronics, Inc. 91 Avenel Street Avenel, NJ 07001 © 2005, KR Electronics, Inc. Web Email Phone Fax www.krfilters.com sales@krfilters.com (732) 636-1900 (732) 636-1982 Page 2
