2712

KR Electronics, Inc. KR Electronics General Description KR 2712 is a 10 MHz bandpass filter. The filter has a minimum 0.5 dB bandwidth of 4 MHz. Other passband frequencies are available. Please consult the factory. www.krfilters.com Features • SMA Connectors • Sharp Transition to Stopband • 50 Ω Source and Load Typical Performance Passband Amplitude & Group Delay (0.5 dB/div and 20 nsec/div) 28 Jul 2006 12:38:15 CH1 CH2 PRm Cor Del S 21 S 21 log MAG delay .5 dB/ 20 ns/ REF 0 dB REF 180 ns Overall Response (10 dB/div) 28 Jul 2006 12:42:37 CH1 S 21 log MAG 10 dB/ REF 0 dB 1 PRm Cor PRm Cor 2 Smo START 8.000 000 MHz STOP 12.000 000 MHz START 1.000 000 MHz STOP 100.000 000 MHz KR Electronics, Inc. 91 Avenel Street Avenel, NJ 07001 © 2006, KR Electronics, Inc. Web Email Phone Fax www.krfilters.com sales@krfilters.com (732) 636-1900 (732) 636-1982 Page 1 KR Electronics, Inc. KR Electronics 2712 Specifications Parameter Filter type Center Frequency Insertion Loss 0.5 dB Bandwidth Attenuation at 5.5 MHz Attenuation at 14.5 MHz Source and Load Specification Bandpass 10 MHz < .7 dB 4 MHz min 50 dB min 36 dB min 50 Ω www.krfilters.com Physical Dimensions Notes: 1. Dimensions in inches KR Electronics, Inc. 91 Avenel Street Avenel, NJ 07001 © 2006, KR Electronics, Inc. Web Email Phone Fax www.krfilters.com sales@krfilters.com (732) 636-1900 (732) 636-1982 Page 2
