2732

KR Electronics, Inc. KR Electronics General Description KR 2732 is a 400 MHz bandpass filter. The filter has a 45 MHz 3 dB bandwidth and is designed for 50 Ω source and load impedance. Other passband frequencies, bandwidths and impedances are available. Please consult the factory. Features • 400 MHz Bandpass • 50 Ω • DIP Package www.krfilters.com Typical Performance Passband Amplitude & Group Delay (1 dB/div & 10 nsec/div) 5 Sep 2006 12:48:29 CH1 CH2 PRm PRm Overall Response (10 dB/div) S 21 S 21 log MAG delay 1 dB/ 10 ns/ REF 0 dB REF 0 s 5 Sep 2006 12:52:52 CH1 S 21 log MAG 10 dB/ REF 0 dB Cor PRm Cor 1 2 Smo START 1.000 000 MHz STOP 1 000.000 000 MHz CENTER 400.000 000 MHz SPAN 50.000 000 MHz KR Electronics, Inc. 91 Avenel Street Avenel, NJ 07001 © 2006, KR Electronics, Inc. Web Email Phone Fax www.krfilters.com sales@krfilters.com (732) 636-1900 (732) 636-1982 Page 1 KR Electronics, Inc. KR 2732 Specifications Parameter Filter type Center Frequency Insertion Loss 3 dB Bandwidth 40 dB Bandwidth Source & Load Specification Bandpass 400 MHz < 3 dB ( 1.5 dB typical) 45 ± 5 MHz 230 MHz typical 50 Ω www.krfilters.com Physical Dimensions Metal Case Pin 1 is Input Pin 5 is Output All other Pins are Ground All leads .030” diameter Dimensions inches KR Electronics, Inc. 91 Avenel Street Avenel, NJ 07001 © 2006, KR Electronics, Inc. Web Email Phone Fax www.krfilters.com sales@krfilters.com (732) 636-1900 (732) 636-1982 Page 2
