2800

KR Electronics, Inc. KR Electronics General Description KR 2800 is a 200 MHz bandpass filter. The filter has a 6 MHz 3 dB bandwidth and is designed for 50 Ω source and load impedance. Other passband frequencies, bandwidths and impedances are available. Please consult the factory. Features • 200 MHz Bandpass • 50 Ω • DIP Package www.krfilters.com Typical Performance Passband Amplitude & Group Delay (1 dB/div & 10 nsec/div) 9 Oct 2007 15:51:58 CH1 CH2 PRm Cor S 21 S 21 log MAG delay 1 dB/ 10 ns/ REF -4 dB REF 80 ns Overall Response (10 dB/div) 9 Oct 2007 15:54:19 CH1 S 21 log MAG 10 dB/ REF 0 dB PRm Cor 1 PRm Cor Smo 2 CENTER 200.000 000 MHz SPAN 8.000 000 MHz START 100.000 000 MHz STOP 1 000.000 000 MHz KR Electronics, Inc. 91 Avenel Street Avenel, NJ 07001 © 2007, KR Electronics, Inc. Web Email Phone Fax www.krfilters.com sales@krfilters.com (732) 636-1900 (732) 636-1982 Page 1 KR Electronics, Inc. KR 2800 Specifications Parameter Filter type Center Frequency Insertion Loss 3 dB Bandwidth 20 dB Bandwidth 40 dB Bandwidth Source & Load Specification Bandpass 200 MHz < 8 dB ( 5 dB typical) 6 MHz ± 20% 16.5 MHz typical 36 MHz typical 50 Ω www.krfilters.com Physical Dimensions Metal Case Pin 1 is Input Pin 5 is Output All other Pins are Ground All leads .030” diameter Dimensions inches KR Electronics, Inc. 91 Avenel Street Avenel, NJ 07001 © 2007, KR Electronics, Inc. Web Email Phone Fax www.krfilters.com sales@krfilters.com (732) 636-1900 (732) 636-1982 Page 2
