PC6-12-5

PC-SERIES Single output DC-DC converter 1.5W ~ 6W Model name P C 6 - 24 - 5 Series name Output power Input voltage Output voltage Features Input/Output isolation 5 dimensions shield metal case Over current protection Adjustable output voltage Remote ON/OFF control (6W type) PC1R5 (1.5W type) Specifications Model Input Voltage Output Voltage (*1) Vdc PC1R5 –5–3.3 PC1R5 –5–5 PC1R5 –5–12 PC1R5 –12–3.3 PC1R5 –12–5 PC1R5 –12–12 PC1R5 –24–3.3 PC1R5 –24–5 PC1R5 –24–12 PC1R5 –48–3.3 PC1R5 –48–5 PC1R5 –48–12 5VDC (4.5 ~ 9.0V) 5V±5% 12V±5% (15V±5%) 12VDC (9 ~ 18V) 3.3V±5% 5V±5% 12V±5% (15V±5%) 0 ~ 400 0 ~ 300 0 ~ 125 (0 ~ 100) 1.32 70 1.5 73 1.5 75 (73) 24VDC (18 ~ 36V) 3.3V±5% 5V±5% 12V±5% (15V±5%) 0 ~ 400 0 ~ 300 0 ~ 125 (0 ~ 100) 1.32 70 1.5 75 1.5 76 (75) 48VDC (36 ~ 72V) 3.3V±5% 5V±5% 12V±5% Vdc 3.3V±5% On-Board Type Power Supply (15V±5%) 0 ~ 400 0 ~ 300 0 ~ 125 (0 ~ 100) 1.32 70 1.5 73 1.5 76 (75) Output Current mA 0 ~ 400 0 ~ 300 0 ~ 125 (0 ~ 100) Output Power (max) Efficiency (typ) (*2) W % 1.32 66 1.5 69 1.5 71 (70) PC3 (3W type) Specifications Model Input Voltage Output Voltage (*1) Vdc PC3 –5–3.3 PC3 –5–5 PC3 –5–12 PC3 –12–3.3 PC3 –12–5 PC3 –12–12 PC3 –24–3.3 PC3 –24–5 PC3 –24–12 PC3 –48–3.3 PC3 –48–5 PC3 –48–12 5VDC (4.5 ~ 9.0V) 5V±5% 12V±5% (15V±5%) 12VDC (9 ~ 18V) 3.3V±5% 5V±5% 12V±5% (15V±5%) 0 ~ 600 0 ~ 600 0 ~ 250 (0 ~ 200) 1.98 70 3.0 75 3.0 77 (77) 24VDC (18 ~ 36V) 3.3V±5% 5V±5% 12V±5% (15V±5%) 0 ~ 600 0 ~ 600 0 ~ 250 (0 ~ 200) 1.98 70 3.0 75 3.0 78 (78) 48VDC (36 ~ 72V) 3.3V±5% 5V±5% 12V±5% (15V±5%) 0 ~ 600 0 ~ 600 0 ~ 250 (0 ~ 200) 1.98 70 3.0 75 3.0 79 (79) Vdc 3.3V±5% Output Current mA 0 ~ 600 0 ~ 600 0 ~ 250 (0 ~ 200) Output Power (max) Efficiency (typ) (*2) W % 1.98 65 3.0 70 3.0 72 (72) PC6 (6W type) Specifications Model Input Voltage Output Voltage (*1) Vdc PC6 –5–3.3 PC6 –5–5 PC6 –5–12 PC6 –12–3.3 PC6 –12–5 PC6 –12–12 PC6 –24–3.3 PC6 –24–5 PC6 –24–12 PC6 –48–3.3 PC6 –48–5 PC6 –48–12 5VDC (4.5 ~ 9.0V) 5V±5% 12V±5% (15V±5%) 12VDC (9 ~ 18V) 3.3V±5% 5V±5% 12V±5% (15V±5%) 0 ~ 1500 0 ~ 1200 0 ~ 500 (0 ~ 400) 4.95 73 6.0 77 6.0 84 (84) 24VDC (18 ~ 36V) 3.3V±5% 5V±5% 12V±5% (15V±5%) 0 ~ 1500 0 ~ 1200 0 ~ 500 (0 ~ 400) 4.95 77 6.0 82 6.0 84 (84) 48VDC (36 ~ 72V) 3.3V±5% 5V±5% 12V±5% (15V±5%) 0 ~ 1500 0 ~ 1200 0 ~ 500 (0 ~ 400) 4.95 77 6.0 82 6.0 85 (85) Vdc 3.3V±5% Output Current mA 0 ~ 1200 0 ~ 1000 0 ~ 500 (0 ~ 400) Output Power (max) Efficiency (typ) (*2) Remote ON/OFF control W % — 3.96 70 6.0 74 6.0 78 (78) Possible (CNT terminal) Common specifications Withstand Voltage Cooling Operating Temperature Over Current Protection Input Protection Input to Output: 500VAC for 1 minute Convection cooling –20 ~ +70°C (–20 ~ +50°C: 100%, +60°C: 70%, +70°C: 40%) Output current limiting, automatic recovery. Avoid to operate overload or dead short for more than 30 seconds. Built in Fuse on input line (*1) Measured at the maximum output power with rated input voltage (5VDC, 12VDC, 24VDC, 48VDC) (*2) At rated input voltage & maximum output power. 115 PC-SERIES Terminal connection [PC1R5 (1.5W type) / PC3 (3W type)] Output voltage can be adjustable by TRM terminal. Output power must be within the rating, when increasing the output voltage. *1 TRM terminal: Open *2 TRM terminal & –Vout terminal: Short Type Output voltage 3.3V type 3.3V 5V type 5V 12V type 12V Type Output voltage 3.3V type 3.67V 5V type 6V 12V type 15V [PC6 (6W type)] *1 TRM terminal: Open *2 TRM terminal & –Vout terminal: Short On-Board Type Power Supply 116 Type Output voltage 3.3V type 3.3V 5V type 5V 12V type 12V Type Output voltage 3.3V type 3.67V 5V type 6V 12V type 15V *3 CNT terminal: Remote ON/OFF control CNT terminal CNT --Vin:Short or 0 ~ 0.4V Output ON CNT --Vin: Open or 2V ~ Vin OFF * Output voltage: Refer to TRM terminal connection Outline drawing • PC1R5 (1.5W type) • PC3 (3W type) • PC6 (6W type) (Unit: mm) Dimension tolerance not designated is ±0.3. PCD-SERIES Dual output DC-DC converter 1.5W ~ 6W Model name PCD 6 - 24 - 1212 Series name Output power Input voltage Output voltage Features Input/Output isolation 5 dimensions shield metal case Over current protection Adjustable output voltage Remote ON/OFF control (6W type) PCD1R5 (1.5W type) Specifications Model Input Voltage Output Voltage (*1) Output Current Output Power (max) Efficiency (typ) (*2) Vdc Vdc mA W % PCD1R5–5–1212 5VDC (4.5 ~ 9.0V) ±12V±5% 0 ~ ±60 1.44 69 ±15V±5% 0 ~ ±50 1.5 67 PCD1R5–12–1212 12VDC (9 ~ 18V) ±12V±5% 0 ~ ±60 1.44 73 ±15V±5% 0 ~ ±50 1.5 73 PCD1R5–24–1212 24VDC (18 ~ 36V) ±12V±5% 0 ~ ±60 1.44 75 ±15V±5% 0 ~ ±50 1.5 75 PCD1R5–48–1212 48VDC (36 ~ 72V) ±12V±5% 0 ~ ±60 1.44 75 ±15V±5% 0 ~ ±50 On-Board Type Power Supply 1.5 75 PCD3 (3W type) Specifications Model Input Voltage Output Voltage (*1) Output Current Output Power (max) Efficiency (typ) (*2) Vdc Vdc mA W % PCD3–5–1212 5VDC (4.5 ~ 9.0V) ±12V±5% 0 ~ ±125 3.0 72 ±15V±5% 0 ~ ±100 3.0 72 PCD3–12–1212 12VDC (9 ~ 18V) ±12V±5% 0 ~ ±125 3.0 77 ±15V±5% 0 ~ ±100 3.0 77 PCD3–24–1212 24VDC (18 ~ 36V) ±12V±5% 0 ~ ±125 3.0 78 ±15V±5% 0 ~ ±100 3.0 78 PCD3–48–1212 48VDC (36 ~ 72V) ±12V±5% 0 ~ ±125 3.0 78 ±15V±5% 0 ~ ±100 3.0 77 PCD6 (6W type) Specifications Model Input Voltage Output Voltage (*1) Output Current Output Power (max) Efficiency (typ) (*2) Vdc Vdc mA W % PCD6–5–1212 5VDC (4.5 ~ 9.0V) ±12V±5% 0 ~ ±250 6.0 75 ±15V±5% 0 ~ ±200 6.0 75 PCD6–12–1212 12VDC (9 ~ 18V) ±12V±5% 0 ~ ±250 6.0 82 ±15V±5% 0 ~ ±200 6.0 82 PCD6–24–1212 24VDC (18 ~ 36V) ±12V±5% 0 ~ ±250 6.0 84 ±15V±5% 0 ~ ±200 6.0 84 PCD6–48–1212 48VDC (36 ~ 72V) ±12V±5% 0 ~ ±250 6.0 82 ±15V±5% 0 ~ ±200 6.0 82 Common specifications Withstand Voltage Cooling Operating Temperature Over Current Protection Input Protection Input to Output: 500VAC for 1 minute Convection cooling –20 ~ +70°C (–20 ~ +50°C: 100%, +60°C: 70%: 40%) Output current limiting, automatic recovery. Avoid to operate overload or dead short for more than 30 seconds. Built in fuse on input line (*1) Output voltage accuracy includes line and load regulation and temperature drift. (*2) At rated input voltage & maximum output power. 117 PCD-SERIES Terminal connection [PCD1R5 (1.5W type) / PCD3 (3W type)] Output voltage can be adjusted by TRM terminals. Output power must be within the rating, when increasing the output voltage. *1 TRM terminal: Open Output: ±12V *2 TRM terminal & –Vout terminal: Short Output: ±15V [PCD6 (6W type)] *1 TRM terminal: Open Output: ±12V *2 TRM terminal & –Vout terminal: Short Output: ±15V On-Board Type Power Supply 118 CNT terminal: Remote ON/OFF control CNT terminal CNT--Vin: Short or 0 ~ 0.4V Output ON OFF CNT--Vin: Open or 2V ~ Vin * Output voltage: Refer to TRM terminal connection Outline drawing • PCD1R5 (1.5W type) • PCD3 (3W type) • PCD6 (6W type) (Unit: mm) Dimension tolerance not designated is ±0.3.
