PP10-24-15

厂商：
LAMBDA
封装：
描述：
PP10-24-15 - Single, Dual output DC-DC converter 1.5W ~ 25W - DENSEI-LAMBDA

数据手册：

下载PP10-24-15.pdf

立即购买

详情介绍
数据手册
价格&库存

PP10-24-15 数据手册

PP-SERIES Single output DC-DC converter 1.5W ~ 25W Model name PP 15-48-5 Nominal output voltage Nominal input voltage Name of series PP25 PP15 PP10 Output power Features Compact and single output DC-DC converter Ultra-thin profile: 8mm Wide input voltage range DC5V input: DC4.5 ~ 7.2V (PP25: 4.7V ~ 7.2V) DC12V input: DC9 ~ 18V (PP1R5 ~ PP10: 8V ~ 16.5V) DC24V input: DC18 ~ 36V (PP1R5 ~ PP10: 18V ~ 32V) DC48V input: DC36 ~ 72V (PP1R5 ~ PP10: 32V ~ 63V) Operating temperature: –20 ~ +71°C Isolation between input and output PP15, PP25: Output voltage variable, on/off control 3 year warranty PP6 PP3 PP1R5 3 year warranty Specifications 1. Input voltage range DC5V input: DC4.5 ~ 7.2V (PP25: 4.7 ~ 7.2V) DC12V input: DC9 ~ 18V (PP1R5 ~ PP10: 8 ~ 16.5V) DC24V input: DC18 ~ 36V (PP1R5 ~ PP10: 18 ~ 32V) DC48V input: DC36 ~ 72V (PP1R5 ~ PP10: 32 ~ 63V) Fixed (PP15, PP25: +5% available with external resistor) Convection cooling –20 ~ +71°C PP1R5 ~ PP10: Output derating –20°C ~ +50°C: 100%, +71°C: 20% PP15, PP25: Output derating –20°C ~ +55°C: 100%, +71°C: 50% (5V input of PP25: Output derating –20°C ~ +50°C: 100%, +71°C: 50%) (48V input of PP25: output derating –20°C ~ +40°C: 100%, +71°C: 40%) Input–output, Input–case: 500VAC for 1 min. Over current protection, PP15, PP25: Remote on/off control & Over voltage protection 2. Output voltage range 3. Cooling 4. Operating ambient temperature On-Board Type Power Supply 5. Withstand voltage 6. Functions Product lineup Model name PP1R5-5-5 PP1R5-5-12 PP1R5-5-15 PP1R5-12-5 PP1R5-12-12 PP1R5-12-15 PP1R5-24-5 PP1R5-24-12 PP1R5-24-15 PP1R5-48-5 PP1R5-48-12 PP1R5-48-15 PP3-5-5 PP3-5-12 PP3-5-15 PP3-12-5 PP3-12-12 PP3-12-15 PP3-24-5 PP3-24-12 PP3-24-15 PP3-48-5 PP3-48-12 PP3-48-15 PP6-5-5 PP6-5-12 PP6-5-15 PP6-12-5 PP6-12-12 PP6-12-15 PP6-24-5 PP6-24-12 PP6-24-15 PP6-48-5 PP6-48-12 PP6-48-15 Output voltage 5V 12V 15V 5V 12V 15V 5V 12V 15V 5V 12V 15V 5V 12V 15V 5V 12V 15V 5V 12V 15V 5V 12V 15V 5V 12V 15V 5V 12V 15V 5V 12V 15V 5V 12V 15V Output current 0.3A 0.12A 0.1A 0.3A 0.12A 0.1A 0.3A 0.12A 0.1A 0.3A 0.12A 0.1A 0.6A 0.24A 0.2A 0.6A 0.24A 0.2A 0.6A 0.24A 0.2A 0.6A 0.24A 0.2A 1.2A 0.5A 0.4A 1.2A 0.5A 0.4A 1.2A 0.5A 0.4A 1.2A 0.5A 0.4A Output power UL CSA EN 1.5W 1.44W 1.5W 1.5W 1.44W 1.5W 1.5W 1.44W 1.5W 1.5W 1.44W 1.5W 3.0W 2.88W 3.0W 3.0W 2.88W 3.0W 3.0W 2.88W 3.0W 3.0W 2.88W 3.0W 6.0W 6.0W 6.0W 6.0W 6.0W 6.0W 6.0W 6.0W 6.0W 6.0W 6.0W 6.0W Model name PP10-5-5 PP10-5-12 PP10-5-15 PP10-12-5 PP10-12-12 PP10-12-15 PP10-24-5 PP10-24-12 PP10-24-15 PP10-48-3.3 PP10-48-5 PP10-48-12 PP10-48-15 PP15-12-5 PP15-12-12 PP15-12-15 PP15-24-5 PP15-24-12 PP15-24-15 PP15-48-3.3 PP15-48-5 PP15-48-12 PP15-48-15 PP25-5-3.3 PP25-5-5.2 PP25-12-5 PP25-12-12 PP25-12-15 PP25-24-5 PP25-24-12 PP25-24-15 PP25-48-3.3 PP25-48-5 PP25-48-12 PP25-48-15 Output voltage 5V 12V 15V 5V 12V 15V 5V 12V 15V 3.3V 5V 12V 15V 5V 12V 15V 5V 12V 15V 3.3V 5V 12V 15V 3.3V 5.2V 5V 12V 15V 5V 12V 15V 3.3V 5V 12V 15V Output current 1.6A 0.7A 0.6A 2.0A 0.9A 0.7A 2.0A 0.9A 0.7A 2.0V 2.0A 0.9A 0.7A 2.4A 1.3A 1.0A 2.4A 1.3A 1.0A 2.4A 2.4A 1.3A 1.0A 3.0A 2.9A 4.0A 2.1A 1.7A 4.0A 2.1A 1.7A 5.0A 4.0A 2.1A 1.7A Output power UL CSA EN 8.0W 8.4W 9.0W 10.0W 10.8W 10.5W 10.0W 10.8W 10.5W 6.6W 10.0W 10.8W 10.5W 12W 15.6W 15W 12W 15.6W 15W 7.92W 12W 15.6W 15W 9.9W 15.08W 20W 25.2W 25.5W 20W 25.2W 25.5W 16.5W 20W 25.2W 25.5W : Safety standard approved PP1R5 PP10 PP3 PP15 PP25 PP6 Request customer specification for further details of specifications, outline, characteristics, etc. Read the instruction manual before usage. Contact us about delivery before ordering. 119 PP-SERIES PP3 PP6 On-Board Type Power Supply 120 Terminal assignments *1 +V INPUT *2 –V *3 +V OUTPUT *4 –V Case: Copper (Thickness 0.4mm) Weight: 15g Terminal assignments *1 +V INPUT *2 –V *3 +V OUTPUT *4 –V Case: Copper (Thickness 0.4mm) Weight: 25g Terminal assignments *1 +V INPUT *2 –V *3 +V OUTPUT *4 –V Case: Copper (Thickness 0.4mm) Weight: 40g PP10 PP15 PP25 Terminal assignments *1 +V INPUT *2 –V *3 +V OUTPUT *4 –V Case: Copper (Thickness 0.4mm) Weight: 40g Terminal assignments *1 +V INPUT *2 –V *3 CNT *4 +V OUTPUT *5 –V *6 TRM Case: Copper (Thickness 0.4mm) Weight: 55g Terminal assignments *1 +V INPUT *2 –V *3CNT *4 +V OUTPUT *5 –V *6 TRM Case: Copper (Thickness 0.4mm) Weight: 65g PPD-SERIES Dual output DC-DC converter 1.5W ~ 10W Model name PPD 3-48-1212 Nominal output voltage Nominal input voltage Name of series PPD10 Output power Features Compact and dual output DC-DC converter Ultra-low profile: 8mm Wide input voltage range DC5V input: DC4.5 ~ 7.2V DC12V input: DC8 ~ 16.5V DC24V input: DC18 ~ 32V DC48V input: DC32 ~ 63V Operating temperature: –20 ~ +71°C Isolation between input and output 3 year warranty PPD6 PPD3 PPD1R5 3 year warranty Specifications 1. Input voltage range DC5V input: DC4.5 ~ 7.2V DC12V input: DC8 ~ 16.5V DC24V input: DC18 ~ 32V DC48V input: DC32 ~ 63V Fixed 2. Output voltage range 3. Cooling 4. Operating ambient temperature (Standard mounting) 5. Withstand voltage 6. Functions On-Board Type Power Supply Convection cooling –20 ~ +71°C PPD1R5, PPD3: Output derating –20°C ~ +50°C: 100%, +71°C: 20% PPD6, PPD10: Output derating –20°C ~ +55°C: 100%, +71°C: 20% Input–output, Input–case: 500VAC for 1 min. Over voltage protection Product lineup Model name PPD1R5-5-1212 PPD1R5-5-1515 PPD1R5-12-1212 PPD1R5-12-1515 PPD1R5-24-1212 PPD1R5-24-1515 PPD1R5-48-1212 PPD1R5-48-1515 PPD3-5-1212 PPD3-5-1515 PPD3-12-1212 PPD3-12-1515 PPD3-24-1212 PPD3-24-1515 PPD3-48-1212 PPD3-48-1515 PPD6-5-1212 PPD6-5-1515 PPD6-12-1212 PPD6-12-1515 PPD6-24-1212 PPD6-24-1515 PPD6-48-1212 PPD6-48-1515 PPD10-5-1212 PPD10-5-1515 PPD10-12-1212 PPD10-12-1515 PPD10-24-1212 PPD10-24-1515 PPD10-48-1212 PPD10-48-1515 Output voltage 12V 15V 12V 15V 12V 15V 12V 15V 12V 15V 12V 15V 12V 15V 12V 15V 12V 15V 12V 15V 12V 15V 12V 15V 12V 15V 12V 15V 12V 15V 12V 15V Output current 60mA 50mA 60mA 50mA 60mA 50mA 60mA 50mA 120mA 100mA 120mA 100mA 120mA 100mA 120mA 100mA 250mA 200mA 250mA 200mA 250mA 200mA 250mA 200mA 350mA 300mA 450mA 350mA 450mA 350mA 450mA 350mA Output power 1.44W 1.5W 1.44W 1.5W 1.44W 1.5W 1.44W 1.5W 2.88W 3.0W 2.88W 3.0W 2.88W 3.0W 2.88W 3.0W 6.0W 6.0W 6.0W 6.0W 6.0W 6.0W 6.0W 6.0W 8.4W 9.0W 10.8W 10.5W 10.8W 10.5W 10.8W 10.5W PPD1R5 PPD3 PPD6 PPD10 Request customer specification for further details of specifications, outline, characteristics, etc. Read the instruction manual before usage. Contact us about delivery before ordering. 121 PPD-SERIES PPD1R5 PPD3 Terminal assignments *1 +V INPUT *2 –V *3 +V *4 –V OUTPUT *5 COM Case: Copper (t = 0.4 mm) Weight: 25g Terminal assignments *1 +V INPUT *2 –V *3 +V *4 –V OUTPUT *5 COM Case: Copper (t = 0.4 mm) Weight: 15g On-Board Type Power Supply PPD6 122 PPD10 Terminal assignments *1 +V INPUT *2 –V *3 +V *4 –V OUTPUT *5 COM Case: Copper (t = 0.4 mm) Weight: 40g Terminal assignments *1 +V INPUT *2 –V *3 +V *4 –V OUTPUT *5 COM Case: Copper (t = 0.4 mm) Weight: 40g (Unit: mm)

下载 PDF

PP10-24-15

1. 物料型号： - PP1R5、PP3、PP6、PP10、PP15、PP25系列。

2. 器件简介： - 这些是单输出DC-DC转换器，功率范围从1.5W到25W，具有超薄外形，宽输入电压范围，操作温度为-20至+71°C，并提供3年保修。

3. 引脚分配： - 输入引脚标记为1 +V和2 –V，输出引脚标记为3 +V和4 –V。部分型号有额外的引脚，如5 –V和6 TRM。

4. 参数特性： - 输入电压范围：DC5V输入为DC4.5 ~ 7.2V，DC12V输入为DC9 ~ 18V，DC24V输入为DC18 ~ 36V，DC48V输入为DC36 ~ 72V。 - 输出电压范围：固定（PP15, PP25可通过外接电阻调整+5%）。 - 冷却方式：自然对流冷却。 - 承受电压：输入-输出、输入-外壳间500VAC持续1分钟。

5. 功能详解： - 过电流保护，PP15、PP25型号具有远程开关控制和过压保护功能。

6. 应用信息： - 适用于需要DC-DC转换的场合，具体应用需根据客户规格确定。

7. 封装信息： - 外壳材料为铜，厚度0.4mm，不同型号重量不同，如PP10型号重量为15g，PP15型号重量为65g。
