AP-B10_1

AC Current transducer AP-B10 Split core transducer for the electronic measurement AC waveforms current, with galvanic isolation between the primary (High power) and the secondary circuits (Electronic circuit). Switch selectable ranges and RMS 0-5V and 0-10V switch selectable voltage output. IPN = 10 .. 400 A Electrical data Primary Nominal Current I PN ( A.t.RMS) 10,25,50 50,75,100 100,150,200 200,300,400 Analogue Output Signal V OUT ( V) 0-5V 0-5V 0-5V 0-5V or or or or 0-10V 0-10V 0-10V 0-10V AP AP AP AP Type 50 B10 100 B10 200 B10 400 B10 Features • RMS output • Split core type • 5V & 10V switch selectable voltage output • DIN mounting & Panel mounting • Eliminates insertion loss • Switch selectable ranges RL VC IC Load resistance Supply voltage Current Consumption Limitation of voltage output (0-10V) Limitation of voltage output (0-5V) Overloaded input current ≥ 10 kΩ +24 ±5% V DC < 30 mA 14 V 7 V no limitation Accuracy-Dynamic performance data Advantages < ±1 % of IPN < ±0.5 % of IPN < ±0.5 % of IPN ±1 mV/K ±0.1 %/K < 150 ms 30 .. 2000 Hz • Large aperture for cable up to Ø18mm • High isolation between primary and secondary circuits • Easy to mount ε X L VOE VOT TCε G tr f Accuracy @ IPN, TA = 25°C (without offset) Linearity (0 .. ± IPN) Electrical offset voltage, TA = 25°C Thermal drift of VOE Thermal drift of the gain (% of reading) Response time @ 90% of IP Frequency bandwidth (±1%) General data TA TS m dCp dCl CTI Ambient operating temperature Ambient storage temperature Mass Protection type Creepage distance Clearance distance Comparative tracking index (Group I) UL94 classification -20 .. +60 °C -20 .. +85 °C 90 g IP20 5.5 mm 5.5 mm 600 V V0 Applications • Automation systems Analog current reading for remote monitoring (e.g. motor) and software alarms. • Panelmeters Simple connection displays power consumption. Insulation category Vb Rated Voltage 300 with IEC 61010-1 standards and following conditions : - Single insulation - Over voltage category CAT III - Pollution degree PD2 - None uniform field R.m.s. voltage for AC insulation test, 50Hz, 1mn 5 R.m.s. voltage for partial discharge extinction @ 10pC 1.5 Peak impulse withstand voltage 1.2/50µs 6.1 If insulated cable is used for the primary circuit, the voltage category could be improved with the following table : Cable insulation (primary) Category HAR 05 600V CAT III HAR 07 1000V CAT III The operator must have accrediation to install this material. The users must take care of all protection gurantee against electrical shock. V Vd Ve Vw kV kV kV Notes : Installation and maintenance should be done with power supply disconnected. . 041029/3 LEM Components www.lem.com Dimensions AP(R)-B10 Output Vo ltage Selection Switch 20 Front Vie w 55 (unit : mm, 1mm = 0.0394 inch) Left View 16.40 Rang e Selection Switch 14.80 4.7 0 40(distance between screws) 37 33.50 Axis of ape rture 67 21 25 18 .50 Plug-in connector included : XW4B-03C1-H1 (OMRON) 18.50 Bottom View Mechanical characteristics • General tolerance • Primary aperture • Panel mounting • Distance between holes ±1 mm ∅ 18.5 mm 2 holes ∅ 4.0 mm 40.0 mm For panel mounting, replace M4 screws by new one (not supplied) with appropriate length to panel´s thickness. Connections • Wires up to 2 mm ∅ 0-5, 10V Selectable GND RL OUTPUT AP/APR +24VDC Output Connector 3(-) 2(out)1(+) Output Switch Range Switch Front Ip Is DIN si ze35.50 69 +24VDC OUT GND LEM reserves the right to carry out modifications on its transducers, in order to improve them, without previous notice.
