LTE-304

L ITE-ON TECHNOLOGY CORPORATION Property of Lite-On Only FEATURES * SELECTED TO SPECIFIC ON-LINE INTENSITY AND RADIANT INTENSITY RANGES * LOW COST MINIATURE PLASTIC SIDE LOOKING PACKAGE * HIGH SPEED PACKAGE DIMENSIONS NOTES: 1. All dimensions are in millimeters (inches). 2. Tolerance is ±0.25mm(.010") unless otherwise noted. 3. Lead spacing is measured where the leads emerge from the package. 4. Specifications are subject to change without notice. Part No. : LTE-304 (PRELIMINARY) DATA SHEET BNS-OD-C131/A4 Page : 1 of 3 L ITE-ON TECHNOLOGY CORPORATION Property of Lite-On Only ABSOLUTE MAXIMUM RATINGS AT TA=25℃ PARAMETER Power Dissipation Peak Forward Current (300pps, 10μs pulse) Continuous Forward Current Reverse Voltage Operating Temperature Range Storage Temperature Range Lead Soldering Temperature [1.6mm(.063") From Body] MAXIMUM RATING 200 1 80 5 -40℃ to + 85℃ -55℃ to + 100℃ 260℃ for 5 Seconds UNIT mW A mA V ELECTRICAL OPTICAL CHARACTERISTICS AT TA=25℃ PARAMETER Aperture Radiant Incidence Radiant Intensity Peak Emission Wavelength Spectral Line Half-Width Forward Voltage Reverse Current Rise/Fall Time Viewing Angle (See FIG.6) SYMBOL MIN. TYP. MAX. Ee IE λPeak Δλ VF IR Tr/Tf 2θ1/2 0.350 2.625 --------850 50 1.6 -30 30 ----2.0 100 --UNIT mW/c ㎡ mW/sr nm nm V μA nS deg. TEST CONDITION IF = 20mA IF = 20mA IF = 50mA IF = 50mA IF = 50mA VR = 5V 10%~90% Part No. : LTE-304 (PRELIMINARY) DATA SHEET BNS-OD-C131/A4 Page : 2 of 3 L ITE-ON TECHNOLOGY CORPORATION Property of Lite-On Only TYPICAL ELECTRICAL / OPTICAL CHARACTERISTICS CURVES (25℃ Ambient Temperature Unless Otherwise Noted) 1.0 Relative Radiant Intensity Forward Current IF (mA) 120 100 80 60 40 20 0 850 Wavelength (nm) 950 -40 -20 0 20 40 60 80 100 Ambient Temperature Ta ( o C) 0.5 0 750 FIG.1 SPECTRAL DISTRIBUTION FIG.2 FORWARD CURRENT VS. AMBIENT TEMPERATURE 1.2 Output Power Relative To Value at IF=20mA 100 Forward Current (mA) 80 60 40 20 0 0 1.2 1.6 2.0 2.4 2.8 Forward Voltage (V) 1.0 0.8 0.6 0.4 0.2 0 -20 0 20 40 60 80 Ambient Temperature Ta ( o C) FIG.3 FORWARD CURRENT VS. FORWARD VOLTAGE FIG.4 RELATIVE RADIANT INTENSITY VS. AMBIENT TEMPERATURE 0 o 10 o 20 o o 5.0 Output Power Relative To Value at IF=20mA 30 Relative Radiant Intensity 4.0 3.0 2.0 1.0 0 0 20 40 60 80 100 40 1.0 0.9 0.8 0.7 50 60 o o o 70 o 80 o 90 0.5 0.3 0.1 0.2 0.4 0.6 o Foward Current (mA) FIG.5 RELATIVE RADIANT INTENSITY VS. FORWARD CURRENT FIG.6 RADIATION DIAGRAM Part No. : LTE-304 (PRELIMINARY) DATA SHEET BNS-OD-C131/A4 Page : 3 of 3
