LTE-4206_1

LITE-ON TECHNOLOGY CORPORATION Property of Lite-On Only FEATURES * SELECTED TO SPECIFIC ON-LINE INTENSITY AND RADIANT INTENSITY RANGES * LOW COST MINIATURE PLASTIC END LOOKING PACKAGE * MECHANICALLY AND SPECTRALLY MATCHED TO THE LTR-4206 SERIES OF PHOTOTRANSISTOR * CLEAR TRANSPARENT COLOR PACKAGE PACKAGE DIMENSIONS NOTES: 1. All dimensions are in millimeters (inches). 2. Tolerance is ±0.25mm(.010") unless otherwise noted. 3. Protruded resin under flange is 1.0mm(.039") max. 4. Lead spacing is measured where the leads emerge from the package. 5. Specifications are subject to change without notice. Part No. : LTE-4206 DATA SHEET BNS-OD-C131/A4 Page : 1 of 3 LITE-ON TECHNOLOGY CORPORATION Property of Lite-On Only ABSOLUTE MAXIMUM RATINGS AT TA=25℃ PARAMETER Power Dissipation Peak Forward Current (300pps, 10μs pulse) Continuous Forward Current Reverse Voltage Operating Temperature Range Storage Temperature Range Lead Soldering Temperature [1.6mm(.063") From Body] MAXIMUM RATING 90 1 60 5 -40℃ to + 85℃ -55℃ to + 100℃ 260℃ for 5 Seconds UNIT mW A mA V ELECTRICAL OPTICAL CHARACTERISTICS AT TA=25℃ PARAMETER SYMBOL MIN. 0.184 Aperture Radiant Incidence Ee 0.36 0.52 0.68 1.383 Radiant Intensity IE 2.71 3.91 5.11 Peak Emission Wavelength Spectral Line Half-Width Forward Voltage Reverse Current Viewing Angle (See FIG.6) λPeak Δλ VF IR 2θ1/2 20 940 50 1.2 1.6 100 nm nm V μA deg. IF = 20mA IF = 20mA IF = 20mA VR = 5V 4.06 5.87 7.67 mW/sr IF = 20mA TYP. MAX. 0.54 0.78 1.02 mW/c㎡ IF = 20mA UNIT TEST BIN NO. CONDITION BIN A BIN B BIN C BIN D BIN A BIN B BIN C BIN D Part No. : LTE-4206 DATA SHEET BNS-OD-C131/A4 Page : 2 of 3 LITE-ON TECHNOLOGY CORPORATION Property of Lite-On Only TYPICAL ELECTRICAL / OPTICAL CHARACTERISTICS CURVES (25℃ Ambient Temperature Unless Otherwise Noted) 1.0 Relative Radiant Intensity Forward Current IF (mA) 60 50 40 30 20 10 0 940 Wavelength (nm) 1040 -40 -20 0 20 40 60 80 100 Ambient Temperature Ta ( o C) 0.5 0 840 FIG.1 SPECTRAL DISTRIBUTION FIG.2 FORWARD CURRENT VS. AMBIENT TEMPERATURE 1.2 Output Power Relative To Value at IF=20mA 50 Forward Current (mA) 40 30 20 10 0 0 1.2 1.6 2.0 2.4 2.8 Forward Voltage (V) 1.0 0.8 0.6 0.4 0.2 0 -20 0 20 40 60 80 Ambient Temperature Ta ( o C) FIG.3 FORWARD CURRENT VS. FORWARD VOLTAGE FIG.4 RELATIVE RADIANT INTENSITY VS. AMBIENT TEMPERATURE 0 o 10 o 20 o o 5.0 Output Power Relative To Value at IF=20mA 30 Relative Radiant Intensity 4.0 3.0 2.0 1.0 0 0 20 40 60 80 100 40 1.0 0.9 0.8 0.7 50 60 o o o 70 o 80 o 90 0.5 0.3 0.1 0.2 0.4 0.6 o Foward Current (mA) FIG.5 RELATIVE RADIANT INTENSITY VS. FORWARD CURRENT FIG.6 RADIATION DIAGRAM Part No. : LTE-4206 DATA SHEET BNS-OD-C131/A4 Page : 3 of 3
