Optical Sensor
Product Data Sheet
LTR-329ALS-01
Spec No.: DS86-2014-0006
Effective Date: 09/04/2014
Revision: B
LITE-ON DCC
RELEASE
BNS-OD-FC001/A4
LITE-ON Technology Corp. / Optoelectronics
No.90,Chien 1 Road, Chung Ho, New Taipei City 23585, Taiwan, R.O.C.
Tel: 886-2-2222-6181 Fax: 886-2-2221-1948 / 886-2-2221-0660
http://www.liteon.com/opto
Optical Sensor
LTR-329ALS-01
1. Description
The LTR-329ALS-01 is a low voltage I2C digital light sensor [ALS] in a low cost miniature chipled lead-free surface mount package.
This sensor converts light intensity to a digital output signal capable of direct I 2C interface. It provides a linear response over a wide
dynamic range from 0.01 lux to 64k lux and is well suited to applications under high ambient brightness. There are altogether six
gain settings (1X, 2X, 4X, 8X, 48X and 96X) available for user to configure.
This CMOS design and factory-set one time trimming capability ensure minimal sensor-to-sensor variations for ease of
manufacturability to the end customers.
2. Features
I2C interface (Fast Mode @ 400kbit/s)
Ultra-small ChipLED package
Built-in temperature compensation circuit
Low active power consumption with standby mode
Supply voltage range from 2.4V to 3.6V capable of 1.7V
logic voltage
Operating temperature range from -30 C to +70 C
RoHS and Halogen free compliant
Light Sensor
Close to human eye spectral response
Immunity to IR / UV Light Source
Automatically rejects 50 / 60 Hz lightings flicker
6 dynamic range from 0.01 lux to 64k lux
16-bit effective resolution
3. Applications
To control display backlight in
Mobile Devices: Mobile phone, PDA
Computing Devices: Notebook PC, Desktop Monitor
Consumer Devices: LCD/PDP TV backlight systems, Cameras, Personal Navigation Device, Digital Photo Frame
Dashboard
1/27
Part No. : LTR-329ALS-01
BNS-OD-FC002/A4
Optical Sensor
LTR-329ALS-01
4. Ordering Information
Part Number
Packaging Type
Package
Quantity
LTR-329ALS-01
Tape and Reel
4-pins chipled package
2500
5. Outline Dimensions
Notes :
1. All dimensions are in millimeters.
2/27
Part No. : LTR-329ALS-01
BNS-OD-FC002/A4
Optical Sensor
LTR-329ALS-01
6. Functional Block Diagram
7. Application Circuit
3/27
Part No. : LTR-329ALS-01
BNS-OD-FC002/A4
Optical Sensor
LTR-329ALS-01
I/O Pins Configuration Table
Pin
I/O Type
Symbol
Description
1
VDD
Power Supply Voltage
2
GND
Ground
3
I/O
SDA
I2C serial data. This pin is an open drain input / output.
4
I
SCL
I2C serial clock. This pin is an open drain input.
Recommended Application Circuit Components
Component
Recommended Value
Rp1, Rp2, Rp3 [1]
1 k to 10 k
C1, C2
1uF
4/27
Part No. : LTR-329ALS-01
BNS-OD-FC002/A4
Optical Sensor
LTR-329ALS-01
8. Ratings and Specifications
Absolute Maximum Ratings at Ta = 25C
Parameter
Symbol
Rating
Unit
3.8
V
Supply Voltage
VDD
Digital Voltage Range
SCL, SDA, INT
-0.5 to 3.8
V
Digital Output Current
SCL, SDA, INT
-1 to 20
mA
Storage Temperature
Tstg
-40 to 100
C
Note: Exceeding these ratings could cause damage to the sensor. All voltages are with respect to ground. Currents are
positive into, negative out of the specified terminal.
Recommended Operating Conditions
Description
Symbol
Supply Voltage
VDD
LED Supply Voltage
Min.
Typ.
Max.
Unit
2.4
3.6
V
VLED
2.5
4.35
V
Interface Bus Power Supply Voltage
VIO
1.7
3.6
V
Operating Temperature
Tope
-30
70
C
Electrical & Optical Specifications
All specifications are at VDD = 3.0V, Tope = 25C, unless otherwise noted.
Parameter
Min.
Typ.
Active Supply Current
Standby Current
Initial Startup Time
Wakeup Time from Standby
60
100
Max.
Unit
Condition
250
uA
Active Mode, Tope = 25C
5
uA
Standby / Sleep Mode
1000
ms
(Note 1)
10
ms
(Note 1)
5/27
Part No. : LTR-329ALS-01
BNS-OD-FC002/A4
Optical Sensor
LTR-329ALS-01
Light Sensor
Parameter
Min.
Max.
Unit
Condition
65535
count
Full Scale ADC Count
0
6
count
Ch0, Lux = 0
0
6
count
Ch1, Lux = 0
830
1550
count
3250
6100
count
Full Scale ADC Count
Typ.
Dark ADC Count
Ch0, Lux = 200 (White LED)
Ch1, Lux = 200 (White LED)
ADC Count (Gain=96)
Integration Time : 50ms
Measurement Time : 100ms
Ratio = Ch1/(Ch1 + Ch0),
ALS Ratio
0.15
0.35
Ratio
Lux = 200 (White LED)
Typical Performance Curve
All specifications are at VDD = 3.0V, Tope = 25C, unless otherwise noted.
Figure 1: Normalized Spectral Response
6/27
Part No. : LTR-329ALS-01
BNS-OD-FC002/A4
Optical Sensor
LTR-329ALS-01
Figure 2 : Viewing angle
Figure 3 : Vdd versus Average Idd
7/27
Part No. : LTR-329ALS-01
BNS-OD-FC002/A4
Optical Sensor
LTR-329ALS-01
Figure 4 : Average Idd versus temperature
Figure 5 : Output count ratio versus temperature
8/27
Part No. : LTR-329ALS-01
BNS-OD-FC002/A4
Optical Sensor
LTR-329ALS-01
Lux Formula
Refer to Appendix A for the lux formula
Notes:
1. Startup Sequence
Supply VDD to Sensor
(Sensor in Standby Mode)
Wait 100 ms (min) - initial startup time
I2C Command (Write)
To enable sensor to Active Mode
Wait 10 ms (max) - wakeup time from standby
Sensor is Active and starts measurement
9/27
Part No. : LTR-329ALS-01
BNS-OD-FC002/A4
Optical Sensor
LTR-329ALS-01
AC Electrical Characteristics
All specifications are at VBus = 1.8V, Tope = 25C, unless otherwise noted.
Parameter
Symbol
f SCL
SCL clock frequency
Bus free time between a STOP and START condition
t BUF
Hold time (repeated) START condition. After this period, the first
clock pulse is generated
t HD
LOW period of the SCL clock
Min.
1
Max.
Unit
400
kHz
1.3
us
0.6
us
t LOW
1.3
us
HIGH period of the SCL clock
t HIGH
0.6
us
Set-up time for a repeated START condition
t SU
; STA
0.6
us
Set-up time for STOP condition
t SU
; STO
0.6
us
Rise time of both SDA and SCL signals
tr
30
300
ns
Fall time of both SDA and SCL signals
t
30
300
ns
Data hold time
t HD
; DAT
0.3
0.9
us
Data setup time
t SU
; DAT
100
Pulse width of spikes which must be suppressed by the input filter
t SP
; STA
f
0
ns
50
ns
2
Definition of timing for I C bus
10/27
Part No. : LTR-329ALS-01
BNS-OD-FC002/A4
Optical Sensor
LTR-329ALS-01
9. Principles of Operation
2
I C Protocols
.I2C Write Protocol (type 1):
1
7
1
1
8
1
1
S Slave address W
A
Register Address
A P
1
8
Slave ID (Write)
Slave ID (Write)
1
2
3
4
5
6
7
S
6
S
5
S
4
S
3
S
2
S
1
S
0
8
9
2
3
4
5
6
7
9
SCL
SDA
S
Slave address
A A A A A A A A
7 6 5 4 3 2 1 0
W A
Register Address
A
P
2
.I C Write Protocol (type 2):
1
7
1
1
8
1
S Slave address W
A
Register Address
8
1
1
A Register Command A P
Slave ID (Write)
Slave ID (Write)
1
2
3
4
5
6
7
S
6
S
5
S
4
S
3
S
2
S
1
S
0
8
9
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
SCL
SDA
S
Slave address
A A A A A A A A
7 6 5 4 3 2 1 0
W A
Register Address
A A A A A A A A
7 6 5 4 3 2 1 0
A
Register Command
A
P
2
.I C Read Protocol:
1
7
1
S Slave address R
1
8
1
1
A Register Command N P
Slave ID (Read)
11/27
Part No. : LTR-329ALS-01
BNS-OD-FC002/A4
Optical Sensor
LTR-329ALS-01
Slave ID (Read)
1
2
3
4
5
6
7
8
S
6
S
5
S
4
S
3
S
2
S
1
S
0
9
1
2
3
4
5
6
7
8
9
SCL
SDA
S
Slave address
C C C C C C C C
7 6 5 4 3 2 1 0
R A
Register Command
N
P
2
.I C Read (Combined format) Protocol:
1
7
1
1
8
1
S Slave address W
A
Register Address
1
7
A Sr Slave address
Slave ID (Write)
1
1
2
3
4
1
1
R
A Register Command N P
Slave ID (Read)
Slave ID (Write)
1
8
5
6
Slave ID (Read)
7
8
9
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
……
SCL
S
6
SDA
S
S
5
S
4
S
3
S
2
Slave address
S
1
S
0
A A A A A A A A
7 6 5 4 3 2 1 0
W A
Register Address
S
6
A
Sr
S
5
S
4
S
3
S
2
S
1
S
0
Slave address
1
2
3
4
5
6
……
R A
7
8
9
……
C C C C C C C C
7 6 5 4 3 2 1 0
……
A
Register Command
N
A
Acknowledge (0 for an ACK)
N
Non-Acknowledge(1 for an NACK)
S
Start condition
Sr
Repeated Start condition
P
Stop condition
W
Write (0 for writing)
R
Read (1 for read)
Slave-to-master
P
Master-to-Slave
2
I C Slave Address
The 7 bits slave address for this sensor is 0x29H.
A read/write bit should be appended to the slave address by the master
device to properly communicate with the sensor.
12/27
Part No. : LTR-329ALS-01
BNS-OD-FC002/A4
Optical Sensor
LTR-329ALS-01
I2C Slave Address
(0x29H)
W/R
Command
Type
Bit7
Bit6
Bit5
Bit4
Bit3
Bit2
Bit1
Bit0
Write
0
1
0
1
0
0
1
0
0x52H
Read
0
1
0
1
0
0
1
1
0x53H
value
Register Set
Addr
R/W
Register Name
Description
Reset Value
0x80
R/W
ALS_CONTR
ALS operation mode control SW reset
0x00
0x85
R/W
ALS_MEAS_RATE
ALS measurement rate in active mode
0x03
0x86
R
PART_ID
Part Number ID and Revision ID
0xA0
0x87
R
MANUFAC_ID
Manufacturer ID
0x05
0x88
R
ALS_DATA_CH1_0
ALS measurement CH1 data, lower byte
0x00
0x89
R
ALS_DATA_CH1_1
ALS measurement CH1 data, upper byte
0x00
0x8A
R
ALS_DATA_CH0_0
ALS measurement CH0 data, lower byte
0x00
0x8B
R
ALS_DATA_CH0_1
ALS measurement CH0 data, upper byte
0x00
0x8C
R
ALS_STATUS
ALS new data status
0x00
Notes:
1)
When reading ALS data registers, read sequence should always be from lower address to higher address (E.g. For ALS data,
Ch1 data should be read first followed by Ch0 data. Read sequence should be 0x88, 0x89, 0x8A, 0x8B. When 0x8B is read, all
four ALS data registers will be populated with new set of data).
13/27
Part No. : LTR-329ALS-01
BNS-OD-FC002/A4
Optical Sensor
LTR-329ALS-01
ALS_CONTR Register (0x80)
The ALS_CONTR register controls the ALS Gain setting, ALS operation modes and software (SW) reset for the sensor. The ALS
sensor can be set to either standby mode or active mode. At either of these modes, the I 2C circuitry is always active. The default
mode after power up is standby mode. During standby mode, there is no ALS measurement performed but I 2C communication is
allowed to enable read/write to all the registers
0x80
ALS_CONTR (default = 0x00)
B7
B6
B5
B4
B3
Reserved
ALS Gain
Field
Bits
Default
Type
Reserved
7:5
000
--
ALS Gain
4:2
000
1
0
B1
B0
SW Reset
ALS Mode
Description
--
--
000
Gain 1X 1 lux to 64k lux (default)
001
Gain 2X 0.5 lux to 32k lux
010
Gain 4X 0.25 lux to 16k lux
011
Gain 8X 0.125 lux to 8k lux
100
Reserved
101
Reserved
110
Gain 48X 0.02 lux to 1.3k lux
111
Gain 96X 0.01 lux to 600 lux
RW
0
SW reset
B2
RW
Initial start-up procedure is NOT started (default)
Initial start-up procedure is started, bit has default value
1
of 0 after start-up
ALS mode
0
0
0
Stand-by mode (default)
1
Active mode
RW
14/27
Part No. : LTR-329ALS-01
BNS-OD-FC002/A4
Optical Sensor
LTR-329ALS-01
ALS_MEAS_RATE Register (0x85)
The ALS_MEAS_RATE register controls the integration time and timing of the periodic measurement of the ALS in active
mode. ALS Measurement Repeat Rate is the interval between ALS_DATA registers update. ALS Integration Time is the
measurement time for each ALS cycle. ALS Integration Time must be set to be equal or smaller than the ALS
Measurement Repeat Rate. If ALS Integration Time is set to be bigger than ALS Measurement Repeat Rate, it will be
automatically reset to be equal to ALS Measurement Repeat Rate by the IC internally.
0x85
ALS_MEAS_RATE (default = 0x03)
B7
B6
B5
Reserved
B4
B3
ALS Integration Time
Field
Bits
Default
Type
Reserved
7:6
00
--
B2
B1
B0
ALS Measurement Repeat Rate
Description
--
--
000
100ms (default)
001
50ms
010
200ms
011
400ms
100
150ms
101
250ms
110
300ms
111
350ms
000
50ms
001
100ms
010
200ms
011
500ms (default)
100
1000ms
ALS
integration
5:3
000
RW
time
ALS
measurement
2:0
011
RW
rate
101
110
2000ms
111
15/27
Part No. : LTR-329ALS-01
BNS-OD-FC002/A4
Optical Sensor
LTR-329ALS-01
PART_ID Register (0x86) (Read Only)
The PART_ID register defines the part number and revision identification of the sensor.
0x86
PART_ID (default = 0x92)
B7
B6
B5
B4
B3
Part Number ID
B2
B1
B0
Revision ID
Field
Bits
Default
Type
Description
Part Number ID
7:4
1010
R
Part ID 0x0AH
Revision ID
3:0
0000
R
Revision ID 0x00H
MANUFAC_ID Register (0x87) (Read Only)
The MANUFAC_ID register defines the manufacturer identification of the sensor.
0x87
MANUFAC_ID (default = 0x05)
B7
B6
B5
B4
B3
B2
B1
B0
Manufacturer ID
Field
Bits
Default
Type
Manufacturer ID
7:0
00000101
R
Description
Manufacturer ID (0x05H)
16/27
Part No. : LTR-329ALS-01
BNS-OD-FC002/A4
Optical Sensor
LTR-329ALS-01
ALS_DATA_CH1 Register (0x88 / 0x89) (Read Only)
The ALS_DATA registers should be read as a group, with the lower address read back first (i.e. read 0x88 first, then read
2
0x89). These two registers should also be read before reading channel-0 data (from registers 0x8A, 0x8B). When the I C
2
read operation starts, all four ALS data registers are locked until the I C read operation of register 0x8B is completed. This
will ensure that the data in the registers is from the same measurement even if an additional integration cycle ends during
the read operation. New measurement data is stored into temporary registers and the ALS_DATA registers are updated as
2
soon as there is no on-going I C read operation. The ALS ADC channel-1 data is expressed as a 16-bit data spread over
two registers. The ALS_DATA_CH1_0 and ALS_DATA_CH1_1 registers provide the lower and upper byte respectively.
0x88
ALS_DATA_CH1_0 (default = 0x00)
B7
B6
B5
B4
B3
B2
B1
B0
B2
B1
B0
ALS Data Ch1 Low
0x89
ALS_DATA_CH1_1 (default = 0x00)
B7
B6
B5
B4
B3
ALS Data Ch1 High
Field
Address
Bits
Default
Type
Description
ALS Data Ch1 Low
0x88
7:0
00000000
R
ALS ADC channel 1 lower byte data
ALS Data Ch1 High
0x89
7:0
00000000
R
ALS ADC channel 1 upper byte data
17/27
Part No. : LTR-329ALS-01
BNS-OD-FC002/A4
Optical Sensor
LTR-329ALS-01
ALS_DATA_CH0 Register (0x8A / 0x8B) (Read Only)
These two registers should be read after reading channel-1 data (from registers 0x88, 0x89). Lower address register
should be read first (i.e read 0x8A first, then read 0x8B). See ALS_DATA_CH1 register information above. The ALS ADC
channel-0 data is expressed as a 16-bit data spread over two registers. The ALS_DATA_CH0_0 and ALS_DATA_CH0_1
registers provide the lower and upper byte respectively.
0x8A
ALS_DATA_CH0_0 (default = 0x00)
B7
B6
B5
B4
B3
B2
B1
B0
B2
B1
B0
ALS Data Ch0 Low
0x8B
ALS_DATA_CH0_1 (default = 0x00)
B7
B6
B5
B4
B3
ALS Data Ch0 High
Field
Address
Bits
Default
Type
Description
ALS Data Ch0 Low
0x8A
7:0
00000000
R
ALS ADC channel 0 lower byte data
ALS Data Ch0 High
0x8B
7:0
00000000
R
ALS ADC channel 0 upper byte data
ALS_ STATUS Register (0x8C) (Read Only)
The ALS_STATUS register stores the information about ALS data status.
New data means data has not been read yet. When
the measurement is completed and data is written to the data register, the data status bit will be set to logic 1. When the data
register is read, the data status bit will be set to logic 0.
18/27
Part No. : LTR-329ALS-01
BNS-OD-FC002/A4
Optical Sensor
LTR-329ALS-01
0x8C
ALS_PS_STATUS (default = 0x00)
B7
B6
ALS Data
Valid
B5
ALS Gain
Field
Bits
Default
Type
ALS Data Valid
7
0
R
ALS Data Gain
6:4
000
3
0
R
2
0
R
ALS data
status
Reserved
1:0
00
B3
B2
ALS
Interrupt
Status
ALS Data
Status
B1
B0
Reserved
Description
0
ALS Data is Valid (default)
1
ALS Data is Invalid
000
ALS measured data in Gain 1X (default)
001
ALS measured data in Gain 2X
010
ALS measured data in Gain 4X
011
ALS measured data in Gain 8X
100
Invalid
101
Invalid
110
ALS measured data in Gain 48X
111
ALS measured data in Gain 96X
R
Range
Reserved
B4
R
0
Don’t care
0
OLD data (data already read), (default)
1
NEW data (first time data is being read)
--
Don’t care
19/27
Part No. : LTR-329ALS-01
BNS-OD-FC002/A4
Optical Sensor
LTR-329ALS-01
10. Device Operation(using Interrupt)
Below flow diagram illustrates the LTR-329ALS operation.
20/27
Part No. : LTR-329ALS-01
BNS-OD-FC002/A4
Optical Sensor
LTR-329ALS-01
11. Pseudo Codes Examples
Control Registers
// The Control Register defines the operating modes and gain settings of the ALS of LTR-329.
// Default settings is 0x00 (in Standby mode).
Slave_Addr = 0x29
// Enable ALS
Register_Addr = 0x80
Command = 0x01
// Slave address of LTR-329 device
// ALS_CONTR register
// For Gain X1
// For Gain X96, Command = 0x1D
WriteByte(Slave_Addr, Register_Addr, Command)
ALS Measurement Rate
// The ALS_MEAS_RATE register controls the ALS integration time and measurement rate.
// Default setting of the register is 0x03 (integration time 100ms, repeat rate 500ms)
Slave_Addr = 0x29
// Slave address of LTR-329 device
// Set ALS Integration Time 200ms, Repeat Rate 200ms
Register_Addr = 0x85
// ALS_MEAS_RATE register
Command = 0x12
// Int time = 200ms, Meas rate = 200ms
// For Int time = 400ms, Meas rate = 500ms, Command = 0x1B
WriteByte(Slave_Addr, Register_Addr, Command)
ALS Data Registers (Read Only)
// The ALS Data Registers contain the ADC output data for the respective channel.
// These registers should be read as a group, with the lower address being read first.
Slave_Addr = 0x29
// Read back ALS_DATA_CH1
Register_Addr = 0x88
ReadByte(Slave_Addr, Register_Addr, Data0)
Register_Addr = 0x89
ReadByte(Slave_Addr, Register_Addr, Data1)
// Read back ALS_DATA_CH0
Register_Addr = 0x8A
ReadByte(Slave_Addr, Register_Addr, Data2)
Register_Addr = 0x8B
ReadByte(Slave_Addr, Register_Addr, Data3)
ALS_CH1_ADC_Data = (Data1 255C
20s
Time 25C to Peak Temperature
25C to 260C
8mins
Solder Reflow
Cool Down
It is recommended to perform reflow soldering no more than twice.
23/27
Part No. : LTR-329ALS-01
BNS-OD-FC002/A4
Optical Sensor
LTR-329ALS-01
13. Moisture Proof Packaging
All LTR-329ALS-01 are shipped in moisture proof package. Once opened, moisture absorption begins. This part is
compliant to JEDEC J-STD-033A Level 3.
Time from Unsealing to Soldering
After removal from the moisture barrier bag, the parts should be stored at the recommended storage conditions and
soldered within seven days. When the moisture barrier bag is opened and the parts are exposed to the recommended
storage conditions for more than seven days, the parts must be baked before reflow to prevent damage to the parts.
Recommended Storage Conditions
Storage Temperature
10C to 30C
Relative Humidity
Below 60% RH
Baking Conditions
Package
Temperature
Time
In Reels
60C
48 hours
In Bulk
100C
4 hours
Baking should only be done once.
24/27
Part No. : LTR-329ALS-01
BNS-OD-FC002/A4
Optical Sensor
LTR-329ALS-01
14. Recommended Land Pattern and Metal Stencil Aperture
Recommended Land Pattern
25/27
Part No. : LTR-329ALS-01
BNS-OD-FC002/A4
Optical Sensor
LTR-329ALS-01
Recommended Metal Stencil Aperture
It is recommended that the metal stencil used for solder paste printing has a thickness (t) of 0.11mm (0.004 inches / 4 mils)
or 0.127mm (0.005 inches / 5 mils).
The stencil aperture opening is recommended to be 0.72mm x 0.60mm which has the same dimension as the land
pattern. This is to ensure adequate printed solder paste volume and yet no shorting.
Note:
1. All dimensions are in millimeters
26/27
Part No. : LTR-329ALS-01
BNS-OD-FC002/A4
Optical Sensor
LTR-329ALS-01
15. Package Dimension for Tape and Reel
Notes:
1. All dimensions are in millimeters (inches)
2. Empty component pockets sealed with top cover tape
3. 7 inch reel - 2500 pieces per reel
4. In accordance with ANSI/EIA 481-1-A-1994 specifications.
27/27
Part No. : LTR-329ALS-01
BNS-OD-FC002/A4
