LTS-3406LP

LITE-ON ELECTRONICS, INC. Property of Lite-On Only FEATURES ＊0.8 inch (20.32 mm) DIGIT HEIGHT. ＊CONTINUOUS UNIFORM SEGMENTS. ＊LOW POWER REQUIREMENT. ＊EXCELLENT CHARACTERS APPEARANCE. ＊HIGH BRIGHTNESS & HIGH CONTRAST. ＊WIDE VIEWING ANGLE. ＊SOLID STATE RELIABILITY. ＊CATEGORIZED FOR LUMINOUS INTENSITY. DESCRIPTION The LTS-3406LP is a 0.8 inch (20.32 mm) digit height single digit seven-segment display. This device utilizes bright red LED chips, which are made from GaP on a transparent GaP substrate, and has a gray face and white segments. DEVICE PART NO. Red Orange LTS-3406LP DESCRIPTION Universal, ± 1 Overflow Rt. & Lt. Hand Decimal PART NO.: LTS-3406LP BNS-OD-C131/A4 PAGE: 1 of 5 LITE-ON ELECTRONICS, INC. Property of Lite-On Only PACKAGE DIMENSIONS NOTES: All dimensions are in millimeters. Tolerances are± 0.25 mm (0.01“) unless otherwise noted. INTERNAL CIRCUIT DIAGRAM PART NO.: LTS-3406LP BNS-OD-C131/A4 PAGE: 2 of 5 LITE-ON ELECTRONICS, INC. Property of Lite-On Only PIN CONNECTION No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 CONNECTION NO PIN CATHODE B ANODE H CATHODE H CATHODE G CATHODE J ANODE J CATHODE D.P. NO PIN ANODE D.P. CATHODE D.P. CATHODE C ANODE C ANODE G ANODE B NO PIN CATHODE B NO PIN PART NO.: LTS-3406LP BNS-OD-C131/A4 PAGE: 3 of 5 LITE-ON ELECTRONICS, INC. Property of Lite-On Only ABSOLUTE MAXIMUM RATING AT Ta=25oC PARAMETER Power Dissipation Per Segment Peak Forward Current Per Segment ( 1/10 Duty Cycle, 0.1ms Pulse Width ) Continuous Forward Current Per Segment Derating Linear From 25℃ Per Segment Reverse Voltage Per Segment Operating Temperature Range MAXIMUM RATING 75 100 25 0.33 5 -35℃ to +85℃ UNIT mW mA mA mA/℃ V -35℃ to +85℃ Storage Temperature Range Solder Temperature: max 260℃ for max 3sec at 1.6mm below seating plane. ELECTRICAL / OPTICAL CHARACTERISTICS AT Ta=25oC PARAMETER Average Luminous Intensity Peak Emission Wavelength Spectral Line Half-Width Dominant Wavelength Forward Voltage Per Segment Reverse Current Per Segment Luminous Intensity Matching Ratio SYMBOL MIN. TYP. MAX. UNIT TEST CONDITION IV λp ∆λ λd VF IR IV-m 320 950 697 90 657 2.1 2.6 100 2:1 µcd nm nm nm V µA IF=10mA IF=20mA IF=20mA IF=20mA IF=20mA VR=5V IF=10mA Note: Luminous intensity is measured with a light sensor and filter combination that approximates the CIE (Commision Internationale De L’Eclairage) eye-response curve. PART NO.: LTS-3406LP BNS-OD-C131/A4 PAGE: 4 of 5 LITE-ON ELECTRONICS, INC. Property of Lite-On Only TYPICAL ELECTRICAL / OPTICAL CHARACTERISTIC CURVES (25oC Ambient Temperature Unless Otherwise Noted) PART NO.: LTS-3406LP BNS-OD-C131/A4 PAGE: 5 of 5
