LTV-715F-TA1

L ITE-ON TECHNOLOGY CORPORATION Property of LITE-ON Only FEATURES * Low collector dark current ( ICEO : MAX. 10-6A at VCE = 10V ) * Current transfer ratio ( CTR : MIN. 600% at IF = 1mA, VCE = 2V ) * High input-output isolation voltage ( Viso = 5,000Vrms ) * Response time ( tr : TYP. 60µs at VCE = 2V, IC = 10mA, RL = 100Ω ) * Dual-in-line package : LTV-715F * Wide lead spacing package : LTV-715FM * Surface mounting package : LTV-715FS * Tape and reel packaging : LTV-715FS-TA1 * UL approved ( No. E113898 ) * TUV approved ( No. R9653630 ) * CSA approved ( No. CA91533-1 ) * FIMKO approved ( No. 202944 ) * NEMKO approved ( No. P98101737 ) * DEMKO approved ( No. 307925 ) * SEMKO approved ( No. 9833170 / 01 ) * VDE approved ( No. 094722 ) Part No. : LTV-715F ( M, S, -TA1 ) BNS-OD-C131/A4 Page : 1 of 9 L ITE-ON TECHNOLOGY CORPORATION Property of LITE-ON Only OUTLINE DIMENSIONS LTV-715F : LTV-715FM : *1. Year date code. *2. 2-digit work week. *3. Factory identification mark shall be marked (Z : Taiwan, Y : Thailand, X : China). Part No. : LTV-715F ( M, S, -TA1 ) BNS-OD-C131/A4 Page : 2 of 9 L ITE-ON TECHNOLOGY CORPORATION Property of LITE-ON Only OUTLINE DIMENSIONS LTV-715FS : *1. Year date code. *2. 2-digit work week. *3. Factory identification mark shall be marked (Z : Taiwan, Y : Thailand, X : China). Part No. : LTV-715F ( M, S, -TA1 ) BNS-OD-C131/A4 Page : 3 of 9 L ITE-ON TECHNOLOGY CORPORATION Property of LITE-ON Only TAPING DIMENSIONS LTV-715FS-TA1 : Description Tape wide Pitch of sprocket holes Distance of compartment Distance of compartment to compartment Symbol W P0 F P2 P1 Dimensions in mm ( inches ) 16 ± 0.3 ( .63 ) 4 ± 0.1 ( .15 ) 7.5 ± 0.1 ( .295 ) 2 ± 0.1 ( .079 ) 12 ± 0.1 ( .472 ) Part No. : LTV-715F ( M, S, -TA1 ) BNS-OD-C131/A4 Page : 4 of 9 L ITE-ON TECHNOLOGY CORPORATION Property of LITE-ON Only ABSOLUTE MAXIMUM RATING ( Ta = 25°C ) PARAMETER Forward Current INPUT Reverse Voltage Power Dissipation Collector - Emitter Voltage Emitter - Collector Voltage OUTPUT Collector Current Collector Power Dissipation Total Power Dissipation *1 Isolation Voltage Operating Temperature Storage Temperature *2 Soldering Temperature IC PC Ptot Viso Topr Tstg Tsol 80 150 170 5,000 -25 ~ +100 -40 ~ +125 260 mA mW mW Vrms °C °C °C SYMBOL IF VR P VCEO VECO RATING 50 6 70 35 6 UNIT mA V mW V V *1. AC For 1 Minute, R.H. = 40 ~ 60% Isolation voltage shall be measured using the following method. (1) Short between anode and cathode on the primary side and between collector and emitter on the secondary side. (2) The isolation voltage tester with zero-cross circuit shall be used. (3) The waveform of applied voltage shall be a sine wave. *2. For 10 Seconds Part No. : LTV-715F ( M, S, -TA1 ) BNS-OD-C131/A4 Page : 5 of 9 L ITE-ON TECHNOLOGY CORPORATION Property of LITE-ON Only ELECTRICAL - OPTICAL CHARACTERISTICS ( Ta = 25°C ) PARAMETER Forward Voltage INPUT Reverse Current Terminal Capacitance Collector Dark Current Collector-Emitter Breakdown Voltage Emitter-Collector Breakdown Voltage Collector Current * Current Transfer Ratio Collector-Emitter Saturation Voltage Isolation Resistance Floating Capacitance Cut-Off Frequency Response Time (Rise) Response Time (Fall) SYMBOL MIN. TYP. MAX. UNIT VF IR Ct ICEO BVCEO — — — — 35 1.2 — 30 — — 1.4 10 250 10-6 — V µA pF A V CONDITIONS IF=10mA VR=4V V=0, f=1KHz VCE=10V, IF=0 IC=0.1mA IF=0 IE=10µA IF=0 IF=1mA VCE=2V IF=20mA IC=5mA DC500V 40 ~ 60% R.H. V=0, f=1MHz VCE=2V, IC=2mA RL=100Ω, -3dB VCE=2V, IC=10mA RL=100Ω OUTPUT BVECO IC CTR VCE(sat) 6 6 600 — — 16 1600 — — 75 7500 1.0 V mA % V Ω pF kHz µs µs TRANSFER CHARACTERISTICS RISO Cf fc tr tf 5×1010 1×1011 — — — — 0.6 6 60 53 — 1 — 250 250 * CTR = IC × 100% IF Part No. : LTV-715F ( M, S, -TA1 ) BNS-OD-C131/A4 Page : 6 of 9 L ITE-ON TECHNOLOGY CORPORATION Property of LITE-ON Only CHARACTERISTICS CURVES Fig.1 Forward Current vs. Ambient Temperature 60 Forward current I F (mA) Fig.2 Collector Power Dissipation vs. Ambient Temperature Collector power dissipation Pc (mW) 200 50 40 30 20 10 0 -25 150 100 50 0 25 50 75 100 o 125 0 -25 0 25 50 75 100 o 125 Ambient temperature Ta ( C) Ambient temperature Ta ( C) Fig.3 Current Transfer Ratio vs. Forward Current 3500 VCE= 2V Current transfer ratio CTR (%) Fig.4 Forward Current vs. Forward Voltage 100 o 3000 2500 2000 1500 1000 500 0 0.1 1 1 Forward current IF (mA) 10 0.5 0.7 0.9 1.1 1.3 1.5 1.7 1.9 Forward voltage (V) Forward current (mA) 100 C 80 C 60 C 10 o o 40 C 20 C o o Fig.5 Collector Current vs. Collector-emitter Voltage 60 PC(MAX.) Fig.6 Collector Current vs. Collector-emitter Voltage 100 90 PC(MAX.) I F= 5mA Collector current Ic (mA) Collector current Ic (mA) 50 40 30 20 10 0 0 2 4 6 8 10 I F= 1mA 0.9mA 0.8mA 0.7mA 0.6mA 0.5mA 0.2mA 0.3mA 0.4mA 0.1mA 80 70 60 50 40 30 20 10 0 0 2mA 1mA 1 2 3 4 5 Collector-emitter voltage Vce (V) Collector-emitter voltage Vce (V) Part No. : LTV-715F ( M, S, -TA1 ) BNS-OD-C131/A4 Page : 7 of 9 L ITE-ON TECHNOLOGY CORPORATION Property of LITE-ON Only CHARACTERISTICS CURVES Fig.7 Relative Current Transfer Ratio vs. Ambient Temperature 1.0 Relative current transfer ratio (%) Fig.8 Collector-emitter Saturation Voltage vs. Ambient Temperature Collector-emitter saturation voltage VCE (sat) (V) I F= 1mA VCE= 2V 1.00 0.80 0.60 0.40 0.20 0.00 I F= 20mA Ic= 5mA 0.8 0.6 0.4 0.2 0 20 40 60 80 O 100 20 40 60 80 O 100 Ambient temperature Ta ( C) Ambient temperature Ta ( C) Fig.9 Collector Dark Current vs. Ambient Temperature 10.00 Collector dark current I CEO (nA) Fig.10 Response Time vs. Load Resistance 5 2 3 10 5 2 2 10 5 2 10 5 2 0 10 VCE= 10V VCE= 2V I C= 10mA tf tr 1.00 0.10 Response time ( s) td ts 0.1 1 10 0.01 20 40 60 80 O 100 Ambient temperature Ta ( C) Load resistance RL (k ) Fig.11 Frequency Response Test Circuit for Response Time Input Output Output td tr ts tf VCE= 2V I C= 2mA Voltage gain Av (dB) Vcc Input RD RL 10% 90% 0 Test Circuit for Frequency Response -10 RL= 10k 1k 100 RD Vcc RL Output -20 0.1 1 10 100 Frequency f (kHz) Part No. : LTV-715F ( M, S, -TA1 ) BNS-OD-C131/A4 Page : 8 of 9 L ITE-ON TECHNOLOGY CORPORATION Property of LITE-ON Only RECOMMENDED FOOT PRINT PATTERNS (MOUNT PAD) Unit : mm Part No. : LTV-715F ( M, S, -TA1 ) BNS-OD-C131/A4 Page : 9 of 9
