LTW-670GS

LTW-670GS

  • 厂商:

    LITEON(光宝)

  • 封装:

  • 描述:

    LTW-670GS - Property of Lite-On Only - Lite-On Technology Corporation

  • 数据手册
  • 价格&库存
LTW-670GS 数据手册
LITE-ON TECHNOLOGY CORPORATION Property of Lite-On Only Features * * * * * * P ackage in 8mm tape on 7" diameter reels. Compatible with automatic placement equipment. Compatible with infrared and vapor phase reflow solder process. E IA STD package. I .C. compatible. Meet green product and Pb-free(According to RoHS) Package Dimensions Part No. LTW-670GS Lens Color Yellow Source Color InGaN White Notes: 1. All dimensions are in millimeters (inches). 2. Tolerance is 0.2 mm (.008") unless otherwise noted. ¡ Part No. : LTW-670GS BNS-OD-C131/A4   Page : 1 of 11 LITE-ON TECHNOLOGY CORPORATION Property of Lite-On Only A bsolute Maximum Ratings at Ta=25 Parameter Power Dissipation Peak Forward Current (1/10 Duty Cycle, 0.1ms Pulse Width) DC Forward Current Reverse Voltage Operating Temperature Range Storage Temperature Range Wave Soldering Condition Suggest IR Reflow Condition : IR-Reflow Soldering Profile for lead free soldering (Acc. to J-STD-020B) 100 30 5 ¢ ¢ LTW-670GS 120 Unit mW mA mA V to + 85 -30 -40 260 ¢ ¢ For 5 Seconds Part No. : LTW-670GS BNS-OD-C131/A4 Page : ¢ to + 100 2 of 11 LITE-ON TECHNOLOGY CORPORATION Property of Lite-On Only Electrical Optical Characteristics Symbol At Ta=25 Min. Typ. Max. Unit Test Condition IF = 20mA Note 1, 2, 5 IF = 20mA Note 1, 2, 5 Fig.6 IF = 20mA Note 3, 5 Fig.1 4 V IF = 20mA Parameter Part No. LTW670GS Luminous Intensity IV 1120 1600 2240 mcd Luminous Flux ΦV 2 £ 670GS 4000 mlm Viewing Angle 1/2 x y VF 670GS 120 0.33 0.33 3.2 deg Chromaticity Coordinates 670GS Forward Voltage 670GS Reverse Current IR 670GS 10 A V R = 5V Note : 1. Luminous intensity is measured with a light sensor and filter combination that approximates the CIE eye-response curve. 2. Iv classification code is marked on each packing bag. 3. The chromaticity coordinates (x, y) is derived from the 1931 CIE chromaticity diagram. 4. Caution in ESD: Static Electricity and surge damages the LED. It is recommended using a wrist band or anti-electrostatic glove when handling the LED. All devices, equipment and machinery must be properly grounded. 5. CAS140B is the test standard for the chromaticity coordinates (x, y) & IV. 6. The chromaticity coordinates (x, y) guarantee should be added ± 0.01 tolerance. Part No. : LTW-670GS Page : 3 of 11 BNS-OD-C131/A4 LITE-ON TECHNOLOGY CORPORATION Property of Lite-On Only Bin Code List IV Spec. Table IV Bin W1 W2 X1 Min. 1120 1400 Max. 1400 1800 ¦¤ ¥ Luminous Intensity (mcd) at = 20mA Luminous Flux (mlm) Typ. 3600 4400 1800 2240 5200 Tolerance on each Luminous Intensity bin is +/- 15%. Hue Spec. Table Hue Bin 5K 5L 6K 6L 7K 7L 8K 8L x y x y x y x y x y x y x y x y CIE 1931 Chromaticity coordinates 0.296 0.259 0.291 0.268 0.313 0.284 0.310 0.297 0.330 0.310 0.330 0.330 0.352 0.344 0.345 0.352 0.291 0.268 0.285 0.279 0.310 0.297 0.307 0.312 0.330 0.330 0.330 0.347 0.338 0.342 0.347 0.371 Tolerance on each Hue (x, y) bin is +/- 0.02 Part No. : LTW-670GS BNS-OD-C131/A4 ¥ ¦¤ Color bin limits at = 20mA 0.310 0.297 0.307 0.312 0.330 0.330 0.330 0.347 0.338 0.342 0.347 0.371 0.364 0.380 0.367 0.401 0.313 0.284 0.310 0.297 0.330 0.310 0.330 0.330 0.352 0.344 0.345 0.352 0.360 0.357 0.364 0.380 Page : 4 of 11 LITE-ON TECHNOLOGY CORPORATION Property of Lite-On Only 0.42 0.4 0.38 0.36 Y-coordinate 0.34 0.32 0.3 0.28 0.26 0.24 0.26 8L 7L 6L 6K 5L 5K 7K 8K 0.28 0.3 0.32 0.34 X-coordinate 0.36 0.38 0.4 Part No. : LTW-670GS Page : 5 of 11 BNS-OD-C131/A4 LITE-ON TECHNOLOGY CORPORATION Property of Lite-On Only T ypical Electrical / Optical Characteristics Curves ( 25 ° C Ambient Temperature Unless Otherwise Noted) Part No. : LTW-670GS BNS-OD-C131/A Page : 6 of 11 LITE-ON TECHNOLOGY CORPORATION Property of Lite-On Only U ser Guide C leaning Do not use unspecified chemical liquid to clean LED they could harm the package. If cleaning is necessary, immerse the LED in ethyl alcohol or isopropyl alcohol at normal temperature for less than one minute. R ecommend Printed Circuit Board Attachment Pad Infrared / vapor phase Reflow Soldering Package Dimensions of Tape Note: 1. All dimensions are in millimeters (inches). Part No. : LTW-670GS BNS-OD-C131/A4 Page : 7 of 11 LITE-ON TECHNOLOGY CORPORATION Property of Lite-On Only Package Dimensions of Reel Notes: 1. Empty component pockets sealed with top cover tape. 2. 7 inch reel-2000 pieces per reel. 3. Minimum packing quantity is 500 pieces for remainders. 4. The maximum number of consecutive missing lamps is two. 5. In accordance with EIA-481-1-B specifications. Part No. : LTW-670GS BNS-OD-C131/A4 Page : 8 of 11 LITE-ON TECHNOLOGY CORPORATION Property of Lite-On Only 1. Application The LEDs described here are intended to be used for ordinary electronic equipment (such as office equipment, communication equipment and household applications).Consult Liteon’s Sales in advance for information on applications in which exceptional reliability is required, particularly when the failure or malfunction of the LEDs may directly jeopardize life or health (such as in aviation, transportation, traffic control equipment, medical and life support systems and safety devices). 2. Storage The storage ambient for the LEDs should not exceed 85°C temperature or 60% relative humidity. It is recommended that LEDs out of their original packaging are IR-reflowed within one week. For extended storage out of their original packaging, it is recommended that the LEDs be stored in a sealed container with appropriate desiccant, or in desiccators with nitrogen ambient. LEDs stored out of their original packaging for more than a week should be baked at about 60 deg C for at least 24 hours before solder assembly. 3. Cleaning Use alcohol-based cleaning solvents such as isopropyl alcohol to clean the LED if necessary. 4. Soldering Recommended soldering conditions: Reflow soldering Wave Soldering Pre-heat 120~150°C Pre-heat time 120 sec. Max. Soldering Temp. 260°C Max. Soldering time 30 sec. Max. Pre-heat Pre-heat time Solder wave Soldering time 100°C Max. 60 sec. Max. 260°C Max. 10 sec. Max. CAUTIONS Soldering iron Temperature Soldering time 300°C Max. 3 sec. Max. (one time only) 5. Drive Method An LED is a current-operated device. In order to ensure intensity uniformity on multiple LEDs connected in parallel in an application, it is recommended that a current limiting resistor be incorporated in the drive circuit, in series with each LED as shown in Circuit A below. Circuit model A LED Circuit model B LED (A) Recommended circuit. (B) The brightness of each LED might appear different due to the differences in the I-V characteristics of those LEDs. 6. ESD (Electrostatic Discharge) Static Electricity or power surge will damage the LED. Suggestions to prevent ESD damage: Use of a conductive wrist band or anti-electrostatic glove when handling these LEDs. All devices, equipment, and machinery must be properly grounded. Work tables, storage racks, etc. should be properly grounded. Use ion blower to neutralize the static charge which might have built up on surface of the LED’s plastic lens as a result of friction between LEDs during storage and handling. Part No. : LTW-670GS Page : 9 of 11 BNS-OD-C131/A4 LITE-ON TECHNOLOGY CORPORATION Property of Lite-On Only ESD-damaged LEDs will exhibit abnormal characteristics such as high reverse leakage current, low forward voltage, or “no lightup” at low currents. To verify for ESD damage, check for “light up” and Vf of the suspect LEDs at low currents. The Vf of “good” LEDs should be >2.0V@0.1mA for InGaN product and >1.4V@0.1mA for AlInGaP product. 7. Reliability Test Test Item Classification Operation Life High Temperature High Humidity Storage High Temperature Storage Low Temperature Storage Temperature Cycling Test Condition Ta= Under Room Temperature As Per Data Sheet Maximum Rating *Test Time= 1000HRS (-24HRS,+72HRS)*@20mA. IR-Reflow In-Board, 2 Times Ta= 65±5 ,RH= 90 95% *Test Time= 240HRS±2HRS Ta= 105±5 *Test Time= 1000HRS (-24HRS,+72HRS) Ta= -55±5 *Test Time=1000HRS (-24HRS,+72H RS) § ¨ § ¨ § § ¨ § Reference Standard MIL-STD-750D:1026 MIL-STD-883D:1005 JIS C 7021:B-1 MIL-STD-202F:103B JIS C 7021:B-11 MIL-STD-883D:1008 JIS C 7021:B-10 JIS C 7021:B-12 MIL-STD-202F:107D MIL-STD-750D:1051 MIL-STD-883D:1010 JIS C 7021:A-4 MIL-STD-202F:107D MIL-STD-750D:1051 MIL-STD-883D:1011 MIL-STD-750D:2031.2 J-STD-020B Endurance Test 105 25 30mins 5mins 10 Cycles § ¨ § -55 30mins 25 5mins Solderability T.sol= 235 ± 5 Immersion time 2±0.5 sec Immersion rate 25±2.5 mm/sec Coverage 95% of the dipped surface § © 8. Others The appearance and specifications of the product may be modified for improvement without prior notice. 9. Quality Guarantee LiteOn guarantee DPPM level of function failure is smaller and equal to 50 DPPM. (Based on 100k usage) Part No. : LTW-670GS BNS-OD-C131/A4 § § IR-Reflow § § Environmental Test to Peak) +3 / second max Ramp-up rate(217 Temp. maintain at 175(±25) 180 seconds max Temp. maintain above 217 60-150 seconds Peak temperature range 260 +0/-5 Time within 5°C of actual Peak Temperature (tp) 20-40 seconds Ramp-down rate +6 /second max § § § § § ¨ § Thermal Shock IR-Reflow In-Board, 2 Times 85 ± 5 -40 ±5 10mins 10mins 100 Cycles MIL-STD-202F:208D MIL-STD-750D:2026 MIL-STD-883D:2003 IEC 68 Part 2-20 JIS C 7021:A-2 Page : 10 of 11 LITE-ON TECHNOLOGY CORPORATION Property of Lite-On Only 10. Suggested Checking List Training and Certification 1. Everyone working in a static-safe area is ESD-certified? 2. Training records kept and re-certification dates monitored? Static-Safe Workstation & Work Areas 1. Static-safe workstation or work-areas have ESD signs? 2. All surfaces and objects at all static-safe workstation and within 1 ft measure less than 100V? 3. All ionizer activated, positioned towards the units? 4. Each work surface mats grounding is good? Personnel Grounding 1. Every person (including visitors) handling ESD sensitive (ESDS) items wear wrist strap, heel strap or conductive shoes with conductive flooring? 2. If conductive footwear used, conductive flooring also present where operator stand or walk? 3. Garments, hairs or anything closer than 1 ft to ESD items measure less than 100V*? 4. Every wrist strap or heel strap/conductive shoes checked daily and result recorded for all DLs? 5. All wrist strap or heel strap checkers calibration up to date? Note: *50V for Blue LED. Device Handling 1. Every ESDS items identified by EIA-471 labels on item or packaging? 2. All ESDS items completely inside properly closed static-shielding containers when not at static-safe workstation? 3. No static charge generators (e.g. plastics) inside shielding containers with ESDS items? 4. All flexible conductive and dissipative package materials inspected before reuse or recycle? Others 1. Audit result reported to entity ESD control coordinator? 2. Corrective action from previous audits completed? 3. Are audit records complete and on file? Part No. : LTW-670GS Page : 11 of 11 BNS-OD-C131/A4
LTW-670GS 价格&库存

很抱歉,暂时无法提供与“LTW-670GS”相匹配的价格&库存,您可以联系我们找货

免费人工找货
