233

Axial Lead and Cartridge Fuses Designed to UL/CSA Standards RoHS Pb 5 x 20 mm Medium-Acting Fuse 233 Series UL ® ® • Designed to UL/ CSA/ANCE 248 Standard. • Available in Cartridge, Axial and Radial Lead Format. • Available in ratings of 1A to 10A. • RoHS compliant and Lead-Free version available, add XP suffix to standard catalog number ELECTRICAL CHARACTERISTICS: % of Ampere Rating 100% 135% 200% Ampere Rating 1–3.5 4–10 1–10 1–10 Opening Time 4 hours, Minimum 1 hour, Minimum 3 sec., Min.; 1 hour Max. 0.4 sec., Min.; 4 sec., Max. INTERRUPTING RATING: 10,000 amperes at 125 VAC, 0.7-0.8 power factor ORDERING INFORMATION: RoHS compliant and Lead-Free version available, add XP suffix to standard catalog number Catalog Number 0233 001 0233 1.25 0233 01.6 0233 002. 0233 02.5 0233 003. 0233 3.15 0233 03.5 0233 004. 0233 005. 0233 006. 0233 06.3 Ampere Rating 1 1.25 1.6 2 2.5 3 3.15 3.5 4 5 6 6.3 Voltage Rating 125 125 125 125 125 125 125 125 125 125 125 125 Nominal Resistance Cold Ohms 0.18 0.13 0.088 0.068 0.052 0.043 0.038 0.034 0.032 0.022 0.018 0.017 Nominal Melting I2t A2Sec 2.03 3.48 6.31 10.2 17.5 27.0 30.6 37.3 53.0 92.4 135 156 ENVIRONMENTAL SPECIFICATIONS: Operating temperature: -55˚C to 125˚C Thermal Shock: MIL-STD-202F Method 107G, Test Condition B: (5 cycles –65°C to +125°C) Vibration: MIL-STD-202F Method 201A Humidity: MIL-STD-202F Method 103B, Test Condition A. high relative humidity (95%) and elevated temperature (40°C) for 240 hours. Salt Spray: MIL-STD-202F Method 101D, Test Condition B PHYSICAL SPECIFICATIONS: Material: Body: Glass Cap: Nickel Plated Brass Leads: Tin Plated Copper Terminal Strength: MIL-STD-202F Method 211A, Test Condition A Solderability: Reference IEC 60127 Second Edition 2003-01 Annex A Product Marking: Cap 1: current and voltage rating. Cap 2: Agency approval markings. Packaging: Available in Bulk (v=5, H=100, M=1000 pcs/pkg) or on Tape/Reel (MRET1=1000 pcs/reel). 426 w w w. l i t t e l f u s e . c o m Axial Lead and Cartridge Fuses Designed to UL/CSA Standards RoHS Pb 5 x 20 mm Medium-Acting Fuse 233 Series Agency Approvals Ampere Range C I D J 1A – 5A 125V 10000A 6A & 6.3A 125V 500A 1A – 5A 125V 10000A 6A & 6.3A 125V 500A UL ® ® Agency Approvals 0233 0001 20+0.5 5.2+0.1 -0.2 5.1+0.6 5.1+0.6 Certificate No. Cartridge NBK280602-E10480 NBK290502-E10480 Leaded NBK280602-E10480 NBK290502-E10480 Certificate No. SU05001-2010 Listed File No. Guide No. File No. Cert. Class No. E10480 JDYX 029862 LR1422-01 0233000XE2 40 22.5 MAX 5.8 MAX .65* UL ® 1A – 6.3A Notes: * Ratings above 6.3A have 0.8 mm dia lead 1 For RoHS compliant parts add suffix 'XP' 2 For RoHS compliant parts add suffix 'P' All dimensions in mm ® Average Time Current Curves 1.25A 1.6A 2A 2.5A 3A 3.15A 3.5A 4A 5A 6A 6.3A 1A 10000 1000 100 TIME IN SECONDS 10 11 AXIAL LEAD AND CARTRIDGE FUSES 1 10 CURRENT IN AMPERES 100 1000 1 0.1 0.01 0.001 w w w. l i t t e l f u s e . c o m 427
