800

INIATURE MINIATURE FUSEHOLDERS Holder / No. 800 01 Panel Mount, Shocksafe Specifications Standard 6.3x32mm Fuses IEC 60127-6 Fuse carrier inserted max. 0,2 4,45 0,5 UL 512 Approvals M12,7x1,5 7,62 VDE: License No. 123336 SEMKO: Certificate No. 9850284 UL Recognized: File No. E 70164 Mounting Bayonet-joint 3,2 2,5 11,7 -0,15 12 -0,1 12.7mm diameter D-hole or double D-hole Admissible torque on plastic hex nut is 1.2Nm Solderable or 4.8mm quick connect-fits 0.5mm tab IP 40 (IEC 60529) PC2 (IEC 60127-6) Holder/Cap: Metal Parts: Terminals: Te r m i n a l s SW14 ∅ 15 ∅ 16 4,8 Protection Class & Category Materials 12,7 -0,1 12,7 -0,1 Panel alternatives 5,5 1...6 5 45,7 8 Cap / No. 816 Black Thermoplastic Polyamide PA 6.6, UL94 V-0 Copper alloy, corrosion protected Solderable, tinned Slot for screwdriver Bayonet-connector-nose Electrical Data (23ºC) Rated Voltage: 500V Rated Current: 10A (800+816 - VDE/SEMKO) 16A (UL/CSA) Rated Power : 2.5W (VDE/SEMKO) -25ºC to +70ºC (consider de-rating) -25ºC/+70ºC/21 days (IEC 60068-2-1...3) +10ºC to +60ºC relative humidity ≤ 75% yearly average, without dew, maximum value for 30 days - 95% 24 cycles at 15 min. each (IEC 60068-2-6) 10 - 60Hz at 0.75mm amplitude 60 - 2000Hz at 10g acceleration ≤ 5mΩ ∅ 9,2 7 For 6.3x32mm Fuses Temperature Operating Temperature 1,5 max. 33,8 1,2 Climatic Test Test Stock Conditions Vibration Resistance Contact Resistance Dielectric Strength > 1.5 kV Impulse Voltage 4 kV, 50 Hz, 1 min., dry > 10 3 MΩ ( 500 VDC, 1 min.) 235ºC, 3 sec. (Wave) 350ºC, 1 sec. (Manual) 260ºC, 5 sec. (IEC 60068-2-20) Conductor - 2.5mm 2 Insulation Resistance Solderability Order Information Packaging Bulk (100 pcs.) Soldering Heat Resistance Minimum Cross Section Marking 800 01, 500V, Approvals 4.7g (Holder) / 2.5g (Cap) Order Numbers Holder Cap, 6.3x32mm No. 800 0000 010 No. 816 0000 000 Unit Weight Note: 1.00 means the number one with two decimal places. 1,000 means the number one thousand. 0 50906 In our continuing strategy to deliver unparalleled circuit protection solutions, technical expertise and application leadership, we proudly introduce the WICKMANN Group and its products to the Littelfuse portfolio. WebSite www.littelfuse.com
