803

INIATURE MINIATURE FUSEHOLDERS Holder / No. 803 01 Volts for 500 Volts ø15 Panel Mount for 6.3x32 mm Fuses Klemmfeder 3,2 2,5 Specifications Packaging 0 bulk (100 pcs.) Standard Renkverschluß IEC 60127-6 UL 512 CSA C22.2 Approvals R1 Loch durchgehend Verdrehungsschutzfläche 4,8±0,1 Mounting Gerätewand 5,5 Pluggable with clamping spring in 12.7mm diameter D-hole (panel of 0.75mm - 3 mm) Solderable or 4.8mm quick connect-fits 0.5mm tab IP 40 (IEC 60529) PC2 (IEC 60127-6) Holder / Cap: Clamp spring: 0,75...3 Te r m i n a l s 8 45,7 Einsatzträger eingesetzt 0,2 Überstand max. 0,5 Protection Class & Category Materials 7,62±0,1 12,7S^-0,1 Verdrehungsschutzfläche P. Panel Mounting Hole Metal Parts: Terminals: Rated Voltage: Rated Current: Rated Power : Thermoplastic (Polyamide PA 6.6), black, UL94 V-0 non-corrosion metal, untreated Copper alloy, corrosion protected solderable tinned 500 V 10 A (VDE/SEMKO) 16 A (UL/CSA) 4 W (VDE/SEMKO) 12S^-0,1 4,45 Electrical Data (23ºC) Cap / No. 816 for 500 Volt O 9,2 7 Schlitz für Schraubendreher Slot for screw-driver Renkverschlussnase Bayonet-connector-nose Temperature Operating Temperature Test Climatic Test -25ºC to +70ºC (consider de-rating) -25 ºC/+70 ºC/21 days (IEC 60068-2-1...3) +10ºC to +60ºC relative humidity ≤ 75% yearly average, without dew, maximum value for 30 days - 95% ≤ 5mΩ > 2 kV Stock Conditions 7 1,5 max. 33,8 1,2 Contact Resistance Dielectric Strength Impulse Voltage 4 kV with 1.2 / 50 µs For 6.3x32 mm Fuses Insulation Resistance Solderability > 10 3 MΩ ( 500 VDC, 1 min.) 235ºC, 2 sec. (soldering bath) (IEC 60068-2-20) 350 ºC, 3 sek. (soldering iron) (IEC 60068-2-20) 260ºC, 5 sec. (soldering bath) (IEC 60068-2-20) Conductor - 2.5mm 2 Soldering Heat Resistance Minimum Cross Section Marking 803, 500 V, Approvals 4.9 g (803) / 2.0 g (816) Unit Weight Order Information Qty. OrderNumber Series 0000 00 Packaging 0 Specifications are subject to change without notice Note: 1.00 means the number one with two decimal places. 1,000 means the number one thousand. 0 50906 In our continuing strategy to deliver unparalleled circuit protection solutions, technical expertise and application leadership, we proudly introduce the WICKMANN Group and its products to the Littelfuse portfolio. WebSite www.littelfuse.com
